Ozito ACP-24151 Instruction Manual

AIR
COMPRESSOR
24L 1.5HP
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 230-240V ~50Hz
Motor: 1,100W
No Load Speed: 2,850min
-1
Tank Volume: 24 litres
Max. Pressure: 8 bar (116psi)
Max. Air Delivery: 161 l/min
Free Air Delivery: 67 l/min*
Pump Type: Oil free
Weight: 23kg
*The free air delivery value was
measured in accordance with AS4637
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: Wheels.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
STANDARD EQUIPMENT
Air Compressor
8
6 10
6
100 4
150
4 12 8
100
50
50
200 2
2 14 150 10
0
psi 230 170
psi
0 0 bar
bar 16 12
Wheels x 2, Bolts x
2, Washer x 4, Spring
Washer x 2, Nut x 2
Air Intake Filter
Support Foot
6 8 10
100 6
4 150 12 4 100 8
50 200 2 50 150 10
2 0 psi 230 14 psi 170
0 bar 16 0 bar 12
ACP-24151
0520
