INFLATE-IT
COMPRESSOR KIT
1100 W
INSTRUCTION MANUAL
SPECIFICATIONS
Power supply:
230 – 240V ~ 50Hz
Motor:
1100W
(S3:15%)
No Load Speed:
3,550/min
Max. Pressure:
8bar (116psi)
Max. Flow Rate:
140 l/min
IP Rating:
IP20
Product weight:
5.7 kg
ozito.com.au
WHAT'S IN THE BOX
Air Compressor
Air Gun
Air Nozzle
Inflation Adaptors x 3
ACK-0015
Advertisement
Table of Contents
Related Manuals for Ozito ACK-0015
Summary of Contents for Ozito ACK-0015
- Page 1 Power supply: 230 – 240V ~ 50Hz Motor: 1100W (S3:15%) No Load Speed: 3,550/min Air Gun Max. Pressure: 8bar (116psi) Max. Flow Rate: 140 l/min IP Rating: IP20 Product weight: 5.7 kg ozito.com.au Air Nozzle Inflation Adaptors x 3 ACK-0015...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION AIR COMPRESSOR 1. ASSEMBLY AND STARTING 1. Supporting Foot 4. Transport Handle 2. Housing 5. Quick-release Nitto Coupling Pre Setup Checks 3. ON/OFF Switch 6. Compressed Air Hose • Examine the machine for signs of transit damage. If damaged, do not use, return to place of purchase •... -
Page 3: Operation
OPERATION 2. OPERATION Connecting to the Compressed Air Hose Switching On and Off Note: It is recommended to use in conjunction with this appliance a IMPORTANT!: BEFORE CONNECTING OR DISCONNECTING Residual Current Device (RCD) of rating not exceeding 30mA. ACCESSORIES, ALWAYS MAKE SURE THAT THE COMPRESSOR IS OFF. -
Page 4: Inflating Tyres
3. INFLATING Inflating Tyres 5. To inflate the tyre, hold down the trigger of the air gun. 1. Attach the air gun to the compressed air hose. 6. After a short time, release the trigger and check the tyre pressure by referring to the 2. - Page 5 It is also useful for cleaning soiled 2. Once it is inserted, release equipment. the hose tab. WARNING!: DO NOT DIRECT THE JET OF COMPRESSED AIR TOWARDS PEOPLE OR ANIMALS. 3. Turn the adaptor in a clockwise direction to secure it in place. ACK-0015...
-
Page 6: Troubleshooting
OPERATION MAINTENANCE 5. TROUBLE SHOOTING 6. CLEANING & MAINTENANCE Problem Cause Solution IMPORTANT! BEFORE CLEANING YOUR COMPRESSOR OR CARRYING OUT ANY MAINTENANCE PROCEDURE, The compressor No supply voltage Check the supply MAKE SURE THAT THE MOTOR IS OFF AND THE TOOL does not start voltage, the power plug and the socket-... -
Page 7: Description Of Symbols
Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. For further information, or any parts not listed here, visit www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486... -
Page 8: Air Nozzle
Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Gun with Gauge & Hose 402052101001 Air Nozzle... -
Page 9: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 10: Warranty
Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1113...
