- Page 1 INSTRUCTION MANUAL Trimmer RT0702C DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: RT0702C Collet chuck capacity 6 mm, 8 mm, or 1/4″ No load speed 10,000 - 34,000 min Overall height 210 mm Net weight 1.8 - 2.8 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. -
Page 3: Ec Declaration Of Conformity
When operating a power tool outdoors, use an WARNING: The vibration emission during actual extension cord suitable for outdoor use. Use of a cord use of the power tool can differ from the declared val- suitable for outdoor use reduces the risk of electric shock. ue(s) depending on the ways in which the tool is used If operating a power tool in a damp location especially what kind of workpiece is processed. -
Page 4: Trimmer Safety Warnings
Trimmer safety warnings Hold the power tool by insulated gripping surfaces only, because the cutter may contact its own cord. Cutting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock. Use clamps or another practical way to secure and support the workpiece to a stable plat- form. -
Page 5: Functional Description
Electronic function FUNCTIONAL DESCRIPTION The tool is equipped with the electronic functions for easy operation. Indication lamp CAUTION: Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Adjusting trimmer bit protrusion To adjust the bit protrusion, open the locking lever and move the base up or down as desired by turning the adjusting screw. - Page 6 Speed adjusting dial ASSEMBLY WARNING: Do not use the speed adjusting CAUTION: Always be sure that the tool is dial during operation. The trimmer bit can be switched off and unplugged before carrying out touched by the operator because of reaction force. any work on the tool.
-
Page 7: Operation
Move the tool forward over the workpiece surface, keeping Changing the collet cone the base flush and advancing smoothly until the cutting is complete. CAUTION: Use the correct size collet cone for the trimmer bit which you intended to use. CAUTION: Do not tighten the collet nut with- out installing a trimmer bit, or the collet cone may... - Page 8 Place the templet guide on the base, and place Base (resin) the base protector again. Then secure the base protec- tor by tightening the screws. Optional accessory Secure the templet to the workpiece. Place the You can use the base (resin) as an optional accessory tool on the templet and move the tool with the templet as shown in the figure.
- Page 9 Attach the guide plate to the straight guide with Circular work the bolt and the wing nut. Circular work may be accomplished if you assemble the straight guide and guide plate as shown in the figures. Min. and max. radius of circles to be cut (distance between the center of circle and the center of trimmer bit) are as follows: Min.: 70 mm Max.: 221 mm...
- Page 10 Drive a nail less than 6 mm in diameter into the When cutting, move the tool with the guide roller center hole to secure the straight guide. riding the side of the workpiece. Pivot the tool around the nail in clockwise direction.
- Page 11 Using the tilt base protector with the Using the tool with the offset base base Before installing the tool on the offset base, remove the collet nut and collet cone by loosening the The tilt base protector (square) removed from the tilt collet nut.
- Page 12 Mount the offset base on the tool. Install the trimmer bit as follows. Lay down the tool with the offset base. Insert the hex wrench into the hole in the offset base. With the hex wrench held in the position as shown in the figure, insert the trimmer bit into the collet cone on the shaft of the offset base from the opposite side and tighten the collet nut firmly with a wrench.
- Page 13 Loosen the screws and remove the upper section With knob type grip from the offset base. Put aside the upper section of the offset base. Fig.39 ► 1. Screw 2. Knob type grip 3. Grip attachment Using the tool with the plunge base Optional accessory Fig.37 CAUTION:...
- Page 14 Adjusting the depth of cut when To use the bar type grip (optional accessory), loosen the screw and remove the knob type grip. using the plunge base (optional accessory) CAUTION: Always hold the tool firmly by both grips during operation. Fig.41 ►...
- Page 15 Lower the tool body and move the tool forward Straight guide for guide holder over the workpiece surface, keeping the base flush and advancing smoothly until the cutting is complete. Optional accessory When doing edge cutting, the workpiece surface The straight guide is effectively used for straight cuts should be on the left side of the trimmer bit in the feed when chamfering or grooving.
- Page 16 Insert the guide bars into the holes in the plunge Loosen the screws on the tool base, insert the base. templet guide and then tighten the screws. Fig.48 Fig.51 ► 1. Guide bar 2. Wing nut 3. Straight guide ► 1. Screw 2. Base 3. Templet guide Adjust the distance between the trimmer bit and Secure the templet to the workpiece.
-
Page 17: Maintenance
Makita Authorized or Factory Service Centers, always using Makita replacement parts. Replacing carbon brushes Fig.56... -
Page 18: Optional Accessories
ACCESSORIES 1/4″ CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other 1/4″ accessories or attachments might present a risk of injury to persons. Only use accessory or attachment Unit:mm for its stated purpose. - Page 19 V-grooving bit Drill point double flush trimming bit θ θ Fig.60 Fig.62 θ 1/4″ 90° Unit:mm 1/4″ Drill point flush trimming bit Unit:mm Corner rounding bit Fig.61 Fig.63 1/4″ 1/4″ Unit:mm 1/4″ Unit:mm 19 ENGLISH...
- Page 20 Chamfering bit Ball bearing flush trimming bit Fig.64 Fig.66 θ 30° 45° 1/4″ 60° Unit:mm Unit:mm Ball bearing corner rounding bit Cove beading bit Fig.67 Fig.65 1/4″ Unit:mm Unit:mm 20 ENGLISH...
- Page 21 Ball bearing chamfering bit Ball bearing cove beading bit Fig.68 Fig.70 θ 45° 1/4″ 60° Unit:mm Unit:mm Ball bearing roman ogee bit Ball bearing beading bit Fig.71 Fig.69 Unit:mm Unit:mm 21 ENGLISH...
- Page 22 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885908-223 www.makita.com 20210609...
