Provisioning; Reviewing System Settings; Accessing The Provisioning Screens; Connecting To A Maintenance Terminal - ADC H2TU-C-202 User Manual

LTPH-UM-1072-03
P
ROVISIONING
To provision the H2TU-C, access the provisioning screens through a maintenance terminal.
R S
EVIEWING YSTEM
To scroll through the current settings of all system parameters, press the MODE pushbutton for 3 or more seconds.
The H2TU-C-202 displays the following parameters:
• Software version number
• List number
• Type of frame pattern received from the DSX-1
• Line code of the signal received from the DSX-1
• All user-configured parameter settings
•
Loop attenuation threshold setting
•
Margin alarm threshold setting
A
CCESSING THE

Connecting to a Maintenance Terminal

The craft port on the front panel allows you to connect the H2TU-C to a maintenance terminal, such as an ASCII
terminal or PC running a terminal emulation program. Once connected to a maintenance terminal, you can access
the maintenance, provisioning, and performance screens.
To connect to a maintenance terminal:
1 Connect a standard 9-pin terminal cable to the RS-232 craft port, as shown in
H2TU-C front panel.
2 Connect the other end of the cable to the serial port on the maintenance terminal.
3 Start a terminal emulation program such as Procomm (emulating a VT100 terminal).
4 Configure the maintenance terminal to the following communication settings:
•
9600 baud
•
No parity
•
8 data bits
•
1 stop bit
• Hardware flow control to OFF
5 If necessary, press
H2TU-C-202 List 2F
S
ETTINGS
P S
ROVISIONING
CTRL + R to refresh the logon screen.
October 25, 2002
CREENS

Provisioning

Figure 1 on page 3, on the
9
