Title Page
UM-20769-R
DT9812,
DT9813, and
DT9814 Series
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Data Translation DT9812 Series

Summary of Contents for Data Translation DT9812 Series

  • Page 1 Title Page UM-20769-R DT9812, DT9813, and DT9814 Series User’s Manual...
  • Page 2 Information furnished by Data Translation, Inc. is believed to be accurate and reliable; however, no responsibility is assumed by Data Translation, Inc. for its use; nor for any infringements of patents or other rights of third parties which may result from its use.
  • Page 3 Changes or modifications to this equipment not expressly approved by Data Translation could void your authority to operate the equipment under Part 15 of the FCC Rules.

  • Page 5: Table Of Contents

    Table of Contents Table of Contents About this Manual ............9 Intended Audience.
  • Page 6 Contents Chapter 4: Verifying the Operation of a Module ......43 Running the Quick DataAcq Application ........45 Testing Single-Value Analog Input .
  • Page 7 Contents Data Format ............. . 68 Converting a Voltage into a Binary Code .
  • Page 8 Using the DT9812 Series Calibration Utility ........

  • Page 9: About This Manual

    If the information applies to a specific module, this manual uses the specific product name, such as DT9812-10V. Otherwise, the series name, such as DT9812 Series, is used. Intended Audience This document is intended for engineers, scientists, technicians, or others responsible for using and/or programming the modules for data acquisition operations in the Microsoft®...

  • Page 10: Conventions Used In This Manual

    DT9814 Series modules: • Benefits of the Universal Serial Bus for Data Acquisition. This white paper describes why USB is an attractive alternative for data acquisition. It is available on the Data Translation web site (www.datatranslation.com). • Measure Foundry Manual (UM-19298) and online help. These documents describe how to use Measure Foundry™...

  • Page 11: Where To Get Help

    • Microsoft Windows XP, Windows Vista, or Windows 7 documentation. • USB web site (http://www.usb.org). Where To Get Help Should you run into problems installing or using a module, the Data Translation Technical Support Department is available to provide technical assistance. Refer to Chapter 7...
  • Page 12 About this Manual...

  • Page 13: Chapter 1: Overview

    Overview Key Hardware Features............Supported Software .

  • Page 14: Key Hardware Features

    Chapter 1 Key Hardware Features The DT9812, DT9813, and DT9814 Series modules are economy, multifunction mini-instruments. Table 1 lists the key features of each module. Table 1: Key Features of the DT9812, DT9813, and DT9814 Series Modules Analog Input Analog Output Module Analog Inputs Analog Outputs...

  • Page 15: Supported Software

    Microsoft Visual Basic or Visual C++; DTx-EZ complies with the DT-Open Layers standard. • DAQ Adaptor for MATLAB – Data Translation’s DAQ Adaptor provides an interface between the MATLAB Data Acquisition (DAQ) subsystem from The MathWorks and Data Translation’s DT-Open Layers architecture.

  • Page 16: Getting Started Procedure

    Chapter 1 Getting Started Procedure The flow diagram shown in Figure 1 illustrates the steps needed to get started using the modules. This diagram is repeated in each chapter; the shaded area in the diagram shows you where you are in the getting started procedure. Set Up and Install the Module (see Chapter 2...

  • Page 17: Part 1: Getting Started

    Part 1: Getting Started...

  • Page 19: Chapter 2: Setting Up And Installing The Module

    Setting Up and Installing the Module Unpacking ..............Attaching Modules to the Computer.
  • Page 20 Chapter 2 Set Up and Install the Module (this chapter) Wire Signals to the Module (see Chapter 3 starting on page Verify the Operation of the Module (see Chapter 4 starting on page...

  • Page 21: Unpacking

    • USB cable (not provided with OEM versions of a module) If an item is missing or damaged, contact Data Translation. If you are in the United States, call the Customer Service Department at (508) 481-3700, ext. 1323. An application engineer will guide you through the appropriate steps for replacing missing or damaged items.

  • Page 22: Attaching Modules To The Computer

    Chapter 2 Attaching Modules to the Computer This section describes how to attach a module to the host computer. Note: The DT9812-10V-OEM module contains a 5-pin USB header instead of a standard USB connector (see page 118 for the pin assignments of this header). To connect to the DT9812-10V-OEM module, you need to purchase the Bulgin USB cable (part#14193).

  • Page 23: Connecting To An Expansion Hub

    Setting Up and Installing the Module 3. For Windows Vista: a. Click Locate and install driver software (recommended). The popup message "Windows needs your permission to continue" appears. b. Click Continue. The Windows Security dialog box appears. c. Click Install this driver software anyway. The LED on the module turns green.
  • Page 24 Chapter 2 For Windows XP: a. Click Next and/or Finish as required in the wizard. Once the firmware is loaded, the wizard restarts to initiate the firmware to accept commands. b. Click Next and/or Finish again. The LED on the module turns green. Note: Windows 7 finds the device automatically.

  • Page 25: Changing The Name Of A Module (Optional)

    Setting Up and Installing the Module Changing the Name of a Module (Optional) To change the name of a module, configure the device driver as follows: 1. From the Windows Start menu, select Settings|Control Panel. 2. From the Control Panel, double-click Open Layers Control Panel. The Data Acquisition Control Panel dialog box appears.
  • Page 26 Chapter 2...

  • Page 27: Chapter 3: Wiring Signals To The Module

    Wiring Signals to the Module Preparing to Wire Signals ............Connecting Analog Input Signals .
  • Page 28 Chapter 3 Set Up and Install the Module (see Chapter 2 starting on page Wire Signals to the Module (this chapter) Verify the Operation of the Module (see Chapter 4 starting on page...

  • Page 29: Preparing To Wire Signals

    Wiring Signals to the Module Preparing to Wire Signals This section provides information about wiring signals to a DT9812, DT9813, or DT9814 Series module. Wiring Recommendations Keep the following recommendations in mind when wiring signals to a DT9812, DT9813, or DT9814 Series module: •...
  • Page 30 Chapter 3 Table 2: DT9812-2.5V, DT9812-10V, DT9812A Screw Terminal Assignments (cont.) Screw Screw Terminal Signal Terminal Signal DAC 0 Return Digital Output 1 2.5 V Reference Digital Output 0 Analog Ground Ground Analog Input CH7 Digital Input 7 Analog Input CH6 Digital Input 6 Analog Input CH5 Digital Input 5...
  • Page 31 Wiring Signals to the Module Table 3: DT9813-10V and DT9813A Screw Terminal Assignments (cont.) Screw Screw Terminal Signal Terminal Signal Analog Input CH4 Analog Input CH12 Analog Input CH3 Analog Input CH11 Analog Input CH2 Analog Input CH10 Analog Input CH1 Analog Input CH9 Analog Input CH0 Analog Input CH8...

  • Page 32: Wiring Signals To The Dt9812-10V-Oem Module

    Chapter 3 Wiring Signals to the DT9812-10V-OEM Module The DT9812-10V-OEM module provides two 20-pin connectors (Analog I/O connector and Digital I/O connector) for wiring signals. Figure 4 shows the location of these two connectors: Connector 20 1 20 1 Analog I/O Digital I/O Connector Connector...
  • Page 33 Wiring Signals to the Module Table 6 lists the pin assignments for the Digital I/O connector on the DT9812-10V-OEM module. Table 6: Digital I/O Connector Pin Assignments on the DT9812-10V-OEM Module Signal Signal Ext Trigger Ext Clock Ground Digital Output 7 Digital Output 6 Digital Output 5 Digital Output 4...

  • Page 34: Connecting Analog Input Signals

    Chapter 3 Connecting Analog Input Signals The DT9812 Series modules support 8 single-ended analog input channels. The DT9813-10V and DT9813A module support 16 single-ended analog input channels; the DT9814-10V and DT9814A support 24 single-ended analog input channels. Figure 5 shows how to connect single-ended voltage input signals (channels 0 and 1, in this case) to the module.

  • Page 35: Connecting Analog Output Signals

    Wiring Signals to the Module Connecting Analog Output Signals The DT9812, DT9813, and DT9814 Series modules support two analog output channels (DAC0 and DAC1). Figure 6 shows how to connect an analog output voltage signal (DAC0, in this case) to one of these modules. DT9812, DT9813, or DT9814 Series Module DAC0...

  • Page 36: Connecting Digital I/O Signals

    Chapter 3 Connecting Digital I/O Signals The DT9812 Series modules support eight fixed digital input lines and eight fixed digital output lines. The DT9813-10V and DT9813A modules support four fixed digital input lines and four fixed digital output lines. (The DT9814-10V and DT9814A modules do not support digital I/O operations.) The following sections describe how to connect digital input and...

  • Page 37: Connecting Digital Output Signals

    Digital Output 0 Figure 10: Connecting Digital Outputs to the DT9812-2.5V, DT9812-10V, DT9812A, DT9813-10V, or DT9813A Module Note: While the DT9812 Series modules have 8 digital outlines, the DT9813-10V module has only four digital output lines (screw terminals 30 through 33).
  • Page 38 Chapter 3 Figure 11 shows how to connect a digital output signal to a DT9812-10V-OEM module. DT9812-10V-OEM Module Ground Out = LED On  Digital Output 0 Digital I/O Connector Figure 11: Connecting Digital Outputs to the DT9812-10V-OEM Module...

  • Page 39: Connecting Counter/Timer Signals

    Wiring Signals to the Module Connecting Counter/Timer Signals DT9812, DT9813, and DT9814 Series modules provide one counter/timer that you can use for the following operations: • Event counting • Frequency measurement • Edge-to-edge measurement • Continuous pulse output (rate generation) This section describes how to connect counter/timer signals for these operation modes.

  • Page 40: Frequency Measurement

    Chapter 3 DT9812, DT9813, or DT9814 Series Module Ground Signal Source Counter 0 In Figure 13: Connecting Counter/Timer Signals for an Event Counting Operation Without Using a Gate Frequency Measurement One way to measure frequency is to connect a pulse of a known duration to the Counter 0 Gate signal, as shown in Figure 14.

  • Page 41: Edge-To-Edge Measurement

    Wiring Signals to the Module Edge-to-Edge Measurement Figure 15 shows how to connect counter/timer signals to the module to perform an edge-to-edge measurement operation on one signal source. The counter measures the number of counts between the start edge (in this case, a rising edge on the Counter 0 Gate signal) and the stop edge (in this case, another rising edge on the Counter 0 Gate signal).

  • Page 42: Rate Generation

    Chapter 3 Rate Generation Figure 16 shows how to connect counter/timer signals to the module to perform a rate generation (continuous pulse output) operation; in this example, an external gate is used. DT9812, DT9813, or DT9814 Series Module Ground Heater Controller Counter 0 Out Counter 0...

  • Page 43: Chapter 4: Verifying The Operation Of A Module

    Verifying the Operation of a Module Running the Quick DataAcq Application......... Testing Single-Value Analog Input .
  • Page 44 Chapter 4 Set Up and Install the Module (see Chapter 2 starting on page Wire Signals to the Module (see Chapter 3 starting on page Verify the Operation of the Module (this chapter)

  • Page 45: Running The Quick Dataacq Application

    For information on each of the features provided, use the online help for the Quick DataAcq application by pressing F1 from any view or selecting the Help menu. If the system has trouble finding the help file, navigate to C:\Program Files\Data Translation\Win32\ dtdataacq.hlp, where C: is the letter of your hard disk drive.

  • Page 46: Testing Single-Value Analog Input

    Chapter 4 Testing Single-Value Analog Input To verify that the module can read a single analog input value, do the following: 1. Connect a voltage source, such as a function generator, to analog input channel 0 (single-ended mode) on the DT9812, DT9813, or DT9814 Series module. Refer to page 34 for an example of how to connect a single-ended analog input.

  • Page 47: Testing Single-Value Analog Output

    Verifying the Operation of a Module Testing Single-Value Analog Output To verify that the module can output a single analog output value, do the following: 1. Connect an oscilloscope or voltmeter to DAC0 on the module. Refer to page 35 for an example of how to connect analog output signals.

  • Page 48: Testing Continuous Analog Input

    Chapter 4 Testing Continuous Analog Input To verify that the module can perform a continuous analog input operation, do the following: 1. Connect known voltage sources, such as the outputs of a function generator, to analog input channels 0 and 1 on the DT9812, DT9813, or DT9814 Series module (using the single-ended configuration).

  • Page 49: Testing Single-Value Digital Input

    Verifying the Operation of a Module Testing Single-Value Digital Input To verify that the module can read a single digital input value, do the following: 1. Connect a digital input to digital input line 0 of port A on the DT9812 or DT9813 Series module.

  • Page 50: Testing Single-Value Digital Output

    Chapter 4 Testing Single-Value Digital Output To verify that the module can output a single digital output value, do the following: 1. Connect a digital output to digital output line 0 of port B on the DT9812 or DT9813 Series module.

  • Page 51: Testing Frequency Measurement

    Verifying the Operation of a Module Testing Frequency Measurement To verify that the module can perform a frequency measurement operation, do the following: 1. Wire an external clock source to counter/timer 0 on the DT9812, DT9813, or DT9814 Series module. Refer to page 40 for an example of how to connect signals to a counter/timer for a frequency measurement operation.

  • Page 52: Testing Pulse Output

    Chapter 4 Testing Pulse Output To verify that the module can perform a pulse output operation, do the following: 1. Connect a scope to counter/timer 0 on the DT9812, DT9813, or DT9814 Series module. Refer to page 42 for an example of how to connect a scope (a pulse output) to counter/timer 0.

  • Page 53: Part 2: Using Your Module

    Part 2: Using Your Module...

  • Page 55: Chapter 5: Principles Of Operation

    Principles of Operation Analog Input Features ............Analog Output Features .
  • Page 56 Chapter 5 Figure 17 shows a block diagram of the DT9812-2.5V, DT9812-10V, DT9812-10V-OEM, and DT9812A modules. Power +5 V Supply +2.5 V Reference* C/T Out 0 From USB 32-Bit 8-Channel Multiplexer C/T Gate 0 Port Counter/Timer C/T In 0 A/D Ch7 A/D Ch6 External Clock A/D Clock...
  • Page 57 Principles of Operation Figure 18 shows a block diagram of the DT9813-10V and DT9813A modules. Power +5 V Supply +2.5 V Reference C/T Out 0 From USB 32-Bit 16-Channel Multiplexer C/T Gate 0 Port Counter/Timer C/T In 0 A/D Ch15 A/D Ch14 External Clock A/D Clock...
  • Page 58 Chapter 5 Figure 19 shows a block diagram of the DT9814-10V and DT9814A modules. Power +5 V Supply +2.5 V Reference C/T Out 0 From USB 32-Bit 24-Channel Multiplexer C/T Gate 0 Port Counter/Timer C/T In 0 A/D Ch23 A/D Ch22 External Clock A/D Clock A/D Ch21...

  • Page 59: Analog Input Features

    Principles of Operation Analog Input Features This section describes the following features of analog input (A/D) operations on the DT9812, DT9813, and DT9814 Series modules: • Input resolution, described below • Analog input channels, described below • Input ranges and gains, described on page 60 •...

  • Page 60: Input Ranges And Gains

    Chapter 5 Using software, specify the channels in the order you want to sample them. You can enter up to 32 entries in the channel list. The channels are read in order from the first entry in the list to the last entry in the list.

  • Page 61: Input Sample Clock Sources

    Principles of Operation Input Sample Clock Sources You can use one of the following clock sources to pace an analog input operation: • Internal clock – Using software, specify the clock source as internal and the clock frequency at which to pace the operation. For the DT9812-2.5V, DT9812-10V, DT9812-10V-OEM, DT9813-10V, and DT9814-10V, the minimum frequency of the internal clock is 30 Hz;...

  • Page 62: Analog Input Conversion Modes

    Chapter 5 Analog Input Conversion Modes The DT9812, DT9813, and DT9814 Series modules support the following conversion modes: • Single-value operations • Continuous scan operations Single-Value Operations Single-value operations are the simplest to use. Using software, you specify the range, gain, and analog input channel.

  • Page 63: Input Triggers

    Principles of Operation Input Triggers A trigger is an event that occurs based on a specified set of conditions. Acquisition starts when the module detects the initial trigger event and stops when the buffers on the queue have been filled or when you stop the operation. Note that when you stop the operation, the module completes the reading of the channel list.

  • Page 64: Converting A Twos Complement Code To A Voltage

    Chapter 5 For example, if the software returns a code of 3072 for the analog input operation, determine the analog input voltage as follows: Voltage = (2.44 * 3072) / 4096 = 1.83 V Converting a Twos Complement Code to a Voltage To convert a twos complement code into a voltage on the DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813-10V, DT9813A, DT9814-10V, or DT9814A module, use the following formula:...

  • Page 65: Analog Output Features

    Principles of Operation Analog Output Features This section describes the following features of analog output operations: • Output resolution, described below • Analog output channels, described below • Output ranges and gains, described on page 66 • Output trigger, described on page 66 •...

  • Page 66: Output Ranges And Gains

    Chapter 5 Output Ranges and Gains The DT9812-2.5V module provides a fixed output range of 0 to 2.44. The DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813-10V, DT9813A, DT9814-10V, and DT9814A modules provide a fixed output range of ±10 V. Through software, specify the range for the entire analog output subsystem (0 to 2.44 V for the DT9812-2.5 V module or 10 V for the DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813-10V, DT9813A, DT9814-10V, and DT9814A modules), and specify a gain of 1 for each channel.

  • Page 67: Single-Value Operations

    Principles of Operation Single-Value Operations Single-value operations are the simplest to use but offer the least flexibility and efficiency. Use software to specify the analog output channel, and the value to output from the analog output channel. Since a single-value operation is not clocked, you cannot specify a clock source, trigger source, or buffer.

  • Page 68: Data Transfer

    Chapter 5 Data Transfer If you are using continuous output mode, you specify whether to allocate and fill a single buffer (WrapSingleBuffer is True) or multiple buffers (WrapSingleBuffer is False). If you are using multiple buffers, data is written from multiple output buffers continuously; when no more buffers of data are available, the continuous output operation stops.

  • Page 69: Converting A Voltage To A Twos Complement Code

    Principles of Operation Converting a Voltage to a Twos Complement Code To convert a voltage into a twos complement code on the DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813-10V, DT9813A, DT9814-10V, or DT9814A module, use the following formula: Code = Voltage (20 / 4096) where, •...

  • Page 70: Digital I/O Features

    (0) is output from each of the digital output lines. Resolution The resolution of the digital ports on the DT9812 Series modules is fixed at 8-bits. The resolution of the digital ports on the DT9813 Series modules is fixed at 4-bits.

  • Page 71: Counter/Timer Features

    Principles of Operation Counter/Timer Features This section describes the following features of counter/timer (C/T) operations: • C/T channels, described below • C/T clock sources, described on page 71 • Gate types, described on page 72 • Pulse types and duty cycles, described on page 72 •...

  • Page 72: Gate Types

    Chapter 5 Gate Types The edge or level of the Counter 0 Gate signal determines when a counter/timer operation is enabled. Using software, you can specify one of the following gate types: • None – A software command enables any counter/timer operation immediately after execution.

  • Page 73: Counter/Timer Operation Modes

    Principles of Operation Counter/Timer Operation Modes The modules support the following counter/timer operation modes: • Event counting • Frequency measurement • Edge-to-edge measurement • Rate generation Event Counting Use event counting mode if you want to count the number of falling edges that occur on Counter 0 In when the gate is active (high-level gate or software gate).

  • Page 74: Edge-To-Edge Measurement

    Chapter 5 Edge-to-Edge Measurement Use edge-to-edge measurement mode if you want to measure the time interval between a specified start edge and a specified stop edge. The start edge can occur on the rising edge or the falling edge of the Counter 0 Gate signal, and the stop edge can occur on the rising edge or the falling edge of the Counter 0 Gate signal.
  • Page 75 Principles of Operation To specify rate generation mode, use software to specify the counter/timer mode as rate, the C/T clock source as either internal or external, the clock divider (2 to 65536), and the active gate type (high-level or software gate). Refer to page 72 for more information about gate types.
  • Page 76 Chapter 5...

  • Page 77: Chapter 6: Supported Device Driver Capabilities

    Supported Device Driver Capabilities Data Flow and Operation Options..........Buffering .
  • Page 78 Total Subsystems on Module a. The DIN subsystem contains eight digital input lines (0 to 7) on the DT9812 Series modules and four digital input lines (0 to 3) on the DT9813 Series modules. There is no DIN subsystem on the DT9814 Series modules.

  • Page 79: Data Flow And Operation Options

    Supported Device Driver Capabilities Data Flow and Operation Options Table 9: DT9812, DT9813, and DT9814 Series Data Flow and Operation Options DT9812, DT9813, and DT9814 Series DOUT QUAD Single-Value Operation Support SupportsSingleValue Simultaneous Single-Value Output Operations SupportsSetSingleValues Continuous Operation Support SupportsContinuous Continuous Operation until Trigger SupportsContinuousPreTrigger...

  • Page 80: Buffering

    Chapter 6 Buffering Table 10: DT9812, DT9813, and DT9814 Series Buffering Options DT9812, DT9813, and DT9814 Series DOUT QUAD Buffer Support SupportsBuffering Single Buffer Wrap Mode Support SupportsWrapSingle Inprocess Buffer Flush Support SupportsInProcessFlush Triggered Scan Mode Table 11: DT9812, DT9813, and DT9814 Series Triggered Scan Mode Options DT9812, DT9813, and DT9814 Series DOUT QUAD...

  • Page 81: Channels

    DT9814A modules provide 24 single-ended analog input channels. b. DT9812 Series modules support one DIN subsystem of 8 digital input lines. The DT9813 Series modules support one DIN subsystem, consisting of 4 digital input lines. The DT9814 Series modules do not support the DIN subsystem.

  • Page 82: Ranges

    DT9812 Series modules and 4-bits for the DT9813 Series modules. The resolution of the digital output port (port A) is fixed at 8-bits or eight digital output lines for the DT9812 Series modules and 4-bits for the DT9813 Series modules.

  • Page 83: Thermocouple And Rtd Support

    Supported Device Driver Capabilities Thermocouple and RTD Support Table 17: DT9812, DT9813, and DT9814 Series Thermocouple and RTD Support Options DT9812, DT9813, and DT9814 Series DOUT C/T QUAD Thermocouple Support SupportsThernocouple RTD Support SupportsRTD Resistance Support ReturnsOhms Voltage Converted to Temperature in Hardware SupportsTemperatureDataInStream Supported Thermocouple Types ThermocoupleType...

  • Page 84: Triggers

    Chapter 6 Triggers Table 19: DT9812, DT9813, and DT9814 Series Trigger Options DT9812, DT9813, and DT9814 Series DOUT QUAD Software Trigger Support SupportsSoftwareTrigger External Positive TTL Trigger Support SupportsPosExternalTTLTrigger External Negative TTL Trigger Support SupportsNegExternalTTLTrigger External Positive TTL Trigger Support for Single-Value Operations SupportsSvPosExternalTTLTrigger External Negative TTL Trigger Support for...

  • Page 85: Clocks

    Supported Device Driver Capabilities Clocks Table 20: DT9812, DT9813, and DT9814 Series Clock Options DT9812, DT9813, and DT9814 Series DOUT QUAD Internal Clock Support SupportsInternalClock External Clock Support SupportsExternalClock Simultaneous Input/Output on a Single Clock Signal SupportsSimultaneousClocking Base Clock Frequency BaseClockFrequency 24 MHz 24 MHz...

  • Page 86: Counter/Timers

    Chapter 6 Counter/Timers Table 21: DT9812, DT9813, and DT9814 Series Counter/Timer Options DT9812, DT9813, and DT9814 Series DOUT QUAD Cascading Support SupportsCascading Event Count Mode Support SupportsCount Generate Rate Mode Support SupportsRateGenerate One-Shot Mode Support SupportsOneShot Repetitive One-Shot Mode Support SupportsOneShotRepeat Up/Down Counting Mode Support SupportsUpDown...
  • Page 87 Supported Device Driver Capabilities Table 21: DT9812, DT9813, and DT9814 Series Counter/Timer Options (cont.) DT9812, DT9813, and DT9814 Series DOUT QUAD Gate-Rising Edge Type SupportsGateRising Interrupt-Driven Operations SupportsInterrupt a. The pulse width (duty cycle) if fixed at 50% when rate generation mode is used. b.
  • Page 88 Chapter 6...

  • Page 89: Chapter 7: Troubleshooting

    Troubleshooting General Checklist ............. Technical Support .

  • Page 90: General Checklist

    7. Search the DT Knowledgebase in the Support section of the Data Translation web site (at www.datatranslation.com) for an answer to your problem. 8. Visit the product’s page on the Data Translation web site for the latest tips, white papers, product documentation, and software fixes.
  • Page 91 Troubleshooting Table 22: Troubleshooting Problems (cont.) Symptom Possible Cause Possible Solution Device failure error The module cannot Check your cabling and wiring and tighten any loose reported. communicate with the Microsoft connections; see the instructions in Chapter bus driver or a problem with the bus driver exists.

  • Page 92: Technical Support

    Chapter 7 Technical Support If you have difficulty using a module, Data Translation’s Technical Support Department is available to provide technical assistance. To request technical support, go to our web site at http://www.datatranslation.com and click on the Support link. When requesting technical support, be prepared to provide the following information: •...

  • Page 93: If Your Module Needs Factory Service

    Troubleshooting If Your Module Needs Factory Service If your module must be returned to Data Translation, do the following: 1. Record the module’s serial number, and then contact the Customer Service Department at (508) 481-3700, ext. 1323 (if you are in the USA) and obtain a Return Material Authorization (RMA).
  • Page 94 Chapter 7...

  • Page 95: Chapter 8: Calibration

    Calibration Using the DT9812 Series Calibration Utility........
  • Page 96 DT9814A modules are calibrated at the factory and should not require calibration for initial use. We recommend that you check and, if necessary, readjust the calibration of the analog input and analog output circuitry on these modules every six months using the DT9812 Series Calibration Utility.

  • Page 97: Using The Dt9812 Series Calibration Utility

    Using the DT9812 Series Calibration Utility Start the DT9812 Series Calibration Utility as follows: 1. From Windows Task Bar, select Start | Programs | Data Translation, Inc | ECONseries | Calibration | DT9812 Series Calibration Utility. The main menu appears.

  • Page 98: Calibrating The Analog Input Subsystem

    Chapter 8 Calibrating the Analog Input Subsystem This section describes how to use the DT9812 Series Calibration Utility to calibrate the analog input subsystem of a DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813-10V, DT9813A, DT9814-10V, or DT9814A module. Connecting a Precision Voltage Source To calibrate the analog input circuitry, you need to connect an external precision voltage source to Analog In 0 (AD Ch0) of the module.
  • Page 99 Calibration 2. Adjust the gain as follows: a. Verify that 9.375V is applied to AD Ch0, and that A/D Channel Select is set to Channel 0. The current voltage reading for this channel is displayed in the A/D Value window. b.

  • Page 100: Calibrating The Analog Output Subsystem

    This process will undo any D/A calibration settings. Once you have finished this procedure, the analog output circuitry is calibrated. To close the DT9812 Series Calibration Utility, click the close box in the upper right corner of the window.

  • Page 101: Appendix A: Specifications

    Specifications Analog Input Specifications ........... Analog Output Specifications.

  • Page 102: Analog Input Specifications

    Appendix A Analog Input Specifications Table 23 lists the analog input specifications for the DT9812, DT9813, and DT9814 Series modules. Table 23: Analog Input Specifications DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813A, DT9812-2.5V DT9813-10V, DT9814-10V DT9814A Feature Specifications Specifications Specifications Number of analog input channels 8 single-ended DT9812-10V: 8 single-ended DT9812-A: 8 single-ended...
  • Page 103 Specifications Table 23: Analog Input Specifications (cont.) DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813A, DT9812-2.5V DT9813-10V, DT9814-10V DT9814A Feature Specifications Specifications Specifications Sample-and-hold Aperture uncertainty: 2 ns 2 ns 2 ns Aperture delay: 200 ns 200 ns 200 ns Throughput 50 kHz 50 kHz 100 kHz ESD protection (per spec) Arc:...

  • Page 104: Analog Output Specifications

    Appendix A Analog Output Specifications Table 24 lists the analog output specifications for the DT9812, DT9813, and DT9814 Series modules. Table 24: Analog Output Specifications DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813A, DT9812-2.5V DT9813-10V, DT9814-10V DT9814A Feature Specifications Specifications Specifications Number of waveform analog output channels Resolution 12-bit...
  • Page 105 Specifications Table 24: Analog Output Specifications (cont.) DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813A, DT9812-2.5V DT9813-10V, DT9814-10V DT9814A Feature Specifications Specifications Specifications Monotonicity Output Clock Internal: External: Trigger Source Internal: External: a. To avoid overrun and underrun errors, it is recommended that you do not run both the A/D and D/A subsystems at the same time using the maximum frequencies.

  • Page 106: Digital I/O Specifications

    Table 25: Digital I/O Specifications DT9812 Series, DT9813 Series Feature Specifications Number of digital I/O lines DT9812 Series: 16 (8 in/8 out) DT9813 Series: 8 (4 in/4 out) Number of ports DT9812 Series: 2, 8-bit DT9813 Series: 2, 4-bit Input termination...

  • Page 107: Counter/Timer Specifications

    Specifications Counter/Timer Specifications Table 26 lists the counter/timer specifications for the DT9812, DT9813, and DT9814 Series modules. Table 26: Counter/Timer Specifications DT9812 Series, DT9813 Series, DT9814 Series Feature Specifications Number of counter/timers Counter/timer modes Event counting, frequency measurement, edge-to-edge measurement,...

  • Page 108: External Trigger Specifications

    External Trigger Specifications Table 27 lists the external A/D trigger specifications for the DT9812, DT9813, and DT9814 Series modules. Table 27: External A/D Trigger Specifications DT9812 Series, DT9813 Series, DT9814 Series Feature Specifications Input type Low-level or falling edge sensitive...

  • Page 109: External Clock Specifications

    Specifications External Clock Specifications Table 28 lists the external A/D clock specifications DT9812, DT9813, and DT9814 Series modules. Table 28: External A/D Clock Specifications DT9812-10V, DT9812-10V-OEM, DT9813-10V, DT9814-10V DT9812A, DT9813A, DT9814A Feature Specifications Specifications Input type Rising-edge sensitive Rising-edge sensitive Logic family Inputs Input logic load:...

  • Page 110: Power, Physical, And Environmental Specifications

    Appendix A Power, Physical, and Environmental Specifications Table 29 lists the power, physical, and environmental specifications for the DT9812, DT9813, and DT9814 Series modules. Table 29: Power, Physical, and Environmental Specifications DT9812-10V, DT9812-10V-OEM, DT9812A, DT9813-10V, DT9813A, DT9814-10V, DT9814A Feature DT9812-2.5V Specifications Specifications USB +5 V out (pin 20) 100 mA maximum...

  • Page 111: Regulatory Specifications

    Regulatory Specifications Table 30 lists the regulatory specifications for the DT9812, DT9813, and DT9814 Series modules. Table 30: Regulatory Specifications DT9812 Series, DT9813 Series, DT9814 Series Feature Specifications Emissions (EMI) FCC Part 15, Class A EN55011:2007 (Based on CISPR-11, 2003/A2, 2006)

  • Page 112: Mating Connector Specifications

    Appendix A Mating Connector Specifications Table 31 lists the mating connector specifications for the DT9812-10V-OEM module. Table 31: Mating Connector Specifications for the DT9812-10V-OEM Module Connector on Module Mating Connector Specifications USB Connector Bulgin part#14193 USB cable Analog I/O Connector (J3) Tyco part# 1658622-4 Digital I/O Connector (J4) Tyco part# 1658622-4...

  • Page 113: Appendix B: Screw Terminal And Connector Pin Assignments

    Screw Terminal and Connector Pin Assignments...

  • Page 114: Screw Terminal Assignments

    Appendix B Screw Terminal Assignments This section lists the screw terminal assignments for the DT9812-2.5V, DT9812-10V, DT9812A, DT9813-10V, DT9813A, DT9814-10V, and DT9814A modules. DT9812-2.5V, DT9812-10V, and DT9812A Screw Terminal Assignments Table 32 lists the screw terminals for the DT9812-2.5V, DT9812-10V, and DT9812A modules. Table 32: DT9812-2.5V, DT9812-10V, and DT9812A Screw Terminal Assignments Screw Screw...

  • Page 115: Dt9813-10V And Dt9813A Screw Terminal Assignments

    Screw Terminal and Connector Pin Assignments DT9813-10V and DT9813A Screw Terminal Assignments Table 33 lists the screw terminals for the DT9813-10V and DT9813A modules. Table 33: DT9813-10V and DT9813A Screw Terminal Assignments Screw Screw Terminal Signal Terminal Signal USB +5 V Out Ext Trigger Ground Ext Clock...

  • Page 116: Dt9814-10V And Dt9814A Screw Terminal Assignments

    Appendix B DT9814-10V and DT9814A Screw Terminal Assignments Table 34 lists the screw terminals for the DT9814-10V and DT9814A modules. Table 34: DT9814-10V and DT9814A Screw Terminal Assignments Screw Screw Terminal Signal Terminal Signal USB +5 V Out Ext Trigger Ground Ext Clock Counter 0 In...

  • Page 117: Dt9812-10V-Oem Connector Pin Assignments

    Screw Terminal and Connector Pin Assignments DT9812-10V-OEM Connector Pin Assignments Table 35 lists the pin assignments for the Analog I/O connector on the DT9812-10V-OEM module. Table 35: Analog I/O Connector Pin Assignments on the DT9812-10V-OEM Module Signal Signal USB +5 V Out Ground Counter 0 In Counter 0 Out...
  • Page 118 Appendix B Table 37 lists the pin assignments for the USB 5-pin header. Table 37: USB 5-Pin Header Signal +5 V D– Ground Shield...

  • Page 119: Index

    Index Index event counting frequency measurement A/D subsystem specifications pulse output aliasing Analog I/O connector pin assignments, DT9812-10V-OEM analog input base clock frequency calibrating BaseClockFrequency channel list binary data encoding channels analog input conversion modes analog output data format buffers data transfer inprocess flush error conditions...
  • Page 120 Index maximum external clock divider counting events maximum throughput customer service minimum external clock divider minimum throughput simultaneous D/A, see analog output specifications data encoding configuring the device driver binary connecting a module twos complement using an expansion hub data flow modes connecting signals continuous C/T analog inputs...
  • Page 121 Index errors analog input hardware features analog output header, USB connector event counting help, online wiring high-edge gate type external clock high-level gate type external clock divider hot-swapping maximum minimum external digital trigger negative inprocess buffers positive input channels ranges sample clock sources factory service internal...
  • Page 122 Index number of Quick Data Acq differential channels running gains quickDAQ I/O channels resolutions scans per trigger ranges single-ended channels analog input voltage ranges analog output NumberOfChannels number of NumberOfRanges rate generation NumberOfResolutions recommendations for wiring NumberOfSupportedGains resolution Nyquist Theorem analog input analog output available...
  • Page 123 Index clocks triggered scan counter/timer number of scans per trigger digital I/O retrigger frequency environmental triggers mating connector analog input physical external power external negative digital regulatory external positive digital triggers software stopping an operation specifications SupportedGains troubleshooting SupportedResolutions procedure SupportedVoltageRanges service and support procedure SupportsBinaryEncoding...
  • Page 124 Index writing programs in C/C++ Visual Basic Visual Basic .NET Visual C# Visual C++...

This manual is also suitable for:

Dt9813 seriesDt9814 seriesDt9812-2.5vDt9812-10vDt9812-10v-oemDt9812a ... Show all

Table of Contents
