idesk CURVA HI-TASK Assembly Instructions

Advertisement

Assembly Instructions
CURVA HI-TASK
A
C
D
B
F
E
Item
Part Name
A
Alu. Mid Back Shell Mesh
A
Alu. Mid Back Shell Mesh Armless
A
Nylon Mid Back Shell Mesh
A
Nylon Mid Back Shell Mesh Armless
B
Aluminum Task Base
B
Nylon Task Base
C
Aluminum Hi-Task Cylinder
C
Nylon Hi-Task Cylinder
D
Aluminum Foot Ring
D
Nylon Foot Ring
E
Alu. Self-Braking Casters
E
Nylon Self-Braking Casters
Aluminum Cylinder Cap
F
F
Nylon Cylinder Cap
Warning
1. Product is for single person use only.
2. Dispose of packing material properly. Do not use plastic cover as a head covering.
Suffocation may result.
3. Do not use this chair as a stepladder.
For assistance, call (888) 471-1616, or www.youtube.com/user/ideskinc1
Part #
Qty
G00174
1
G00175
1
G00176
1
G00177
1
G00151
1
G00152
1
G00170
1
G00171
1
G00172
1
G00173
1
G00188
5
G00189
5
G00158
1
G00159
1
