Assembly Instructions
402B/402W OROBLANCO
A
B
C
D
O
E
F
G
Item
A
B
C
D
E
F
G
H
J
K
L
M
N
N
O
Warning
1. Product is for single person use only.
2. Do not use this chair unless all bolts and knobs are securely tightened.
3. Check that all bolts and knobs are tightened every six months
or as needed.
4. Dispose of packing material properly. Do not use plastic cover as a head
covering. Suffocation may result.
5. Do not use this chair as a stepladder.
* Arm Pad Lock Kit (L & M) & Arm Cap Kit (N, & O) are included.
For assistance, call (888) 471-1616, or www.youtube.com/user/ideskInc1
Part Name
Part #
Back Frame
G00021/G00038
Left Arm
G00059/G00060
Right Arm
G00061/G00062
Seat Pan
G00063/G00064
Gas Cylinder
G00025
Base
G00026
Caster
G00008
Hex Wrench
G00028
Short Bolt
G00030
Long Bolt
G00065
Pivot Lock Bracket
G00067
Slide Lock Bracket
G00068
Left Arm Cap
G00069/G00071
Right Arm Cap
G00070/G00072
Qty
1
1
1
1
1
1
5
1
4
2
2
2
1
1
Advertisement
Related Manuals for idesk OROBLANCO 402B
Summary of Contents for idesk OROBLANCO 402B
- Page 1 Item Part Name Part # Back Frame G00021/G00038 Assembly Instructions Left Arm G00059/G00060 402B/402W OROBLANCO Right Arm G00061/G00062 Seat Pan G00063/G00064 Gas Cylinder G00025 Base G00026 Caster G00008 Hex Wrench G00028 Short Bolt G00030 Long Bolt G00065 Pivot Lock Bracket G00067 Slide Lock Bracket G00068...
- Page 2 Install items in order of red numbers Align Back Frame mounting holes on both sides For armless chair...
- Page 3 Instructions Arm Pad Lock Kit 402B/402W OROBLANCO 1) Bracket A & Bracket B 2) Slide the arm pad back 3) Slide the arm pad and take a screwdriver forward and remove and pop off the cover screws 4) Remove the arm pad 5) Remove four screws that 6) Remove part 7) Make sure the angle...
- Page 4 Assembly Instructions Slip Cover 402B/402W OROBLANCO 1) Assemble chair 2) Remove old slip cover and foam 3) Unzip old slip cover and remove from seat pan by unfastening from foam the velcro fasteners on the back and front of seat. Remove the back fasteners first 2”...
- Page 5 IMPORTANT ADDITIONAL INSTALLATION INFORMATION (idesk Seating) Model 402 Installation tip for installing adjustable arm. Bolted Cap (Item L) must be aligned with the Long Bolt (Item M). (Armrests for future shipment will be fully assembled.) Bolted Cap L Long Bolt M...
- Page 6 IMPORTANT ADDITIONAL INSTALLATION INFORMATION (idesk Seating) Model 402 To ensure the bolted cap does not rotate out of alignment, place a thin piece of tape over bolted cap prior to installation. (Armrests for future shipment will be fully assembled.) Thin tape...
- Page 7 IMPORTANT ADDITIONAL INSTALLATION INFORMATION (idesk Seating) Model 402 Installation tip for installing slip cover. 2) Assemble chair. 2) Remove old slip cover and foam 3) Unzip old slip cover and remove from seat pan by unfastening from foam. the velcro fasteners on the back and front of seat.
