Memorex MSBW101 Quick Start Manual

Air Cushion Bluetooth Speaker
Features
• Waterproof
• Shock absorbing cover
• Bluetooth wireless 5.0: range 60 ft. (18m)
• Party Plus Mode
• Built-in rechargeable battery: approximately 18hrs
playtime at 50% volume
• USB-C port for battery recharge
Includes
• USB-C to USB charging cable
• User manual
• Wrist Strap
Overview
1
5
1. Micro SD Port
2. Aux In
3. DC Power Input
4. Charging/Bluetooth Indicator LED: Light will turn solid
red when charging and will turn off when fully charged.
Flashing blue when in Bluetooth mode. Solid Blue light
when paired to a device.
5. Power/Source: Press and hold to power ON/OFF. Press
to change sources between Bluetooth, Aux in and SD
modes.
6. Play/Pause: Press to play/pause audio. When powered
ON, quickly press twice to pair to enter into pairing
mode. Press and hold to activate Party Plus mode.
7. Volume/Skip+/Prev- : Press to adjust volume level. Press
and hold to change to previous/next track.
8. LED Lights: When first powered ON repeatedly press to
change flashing speed (once for slow, twice for medium,
three times for fast). Continually press to change the
lights to a specific color (white, blue, red,green, yellow,
purple, light blue and OFF).
MSBW101-2777-01-IB - 21Apr2021.indd 1
2 3
4
6 8
7
Battery Charging
To charge the internal battery, plug the USB charging cable
into the DC Power Input on the speaker and a powered on
computer or USB power adapter (not included) and standard
power outlet. Charging time is approximately 4 hours. Battery
life is approximately 18 hours at 50% volume.
While the unit is charging it will display a solid red light. When
the battery is fully charged the light will turn off.
Aux In & Micro SD
Aux In
Requires a 3.5mm audio cable (not included).
1. Connect a 3.5mm audio cable to the Aux In on the unit
and the audio output on an audio device. The unit will
automatically change to Aux in mode.
2. Use the controls on the connected device to select and
play audio. Be sure the volume on your connected device
is audible when you begin playing.
Micro SD
1. Load a Micro SD memory card into the Micro SD port.
2. The speaker will automatically switch to SD mode.
3. Use the controls on the speaker to select and play audio
from the connected drive.
I'm Here to Party
MSBW101 v2777-01
4/21/2021 9:30:57 AM
