Klipsch KL-6502-THX Specification Sheet

In-Wall LCR Loudspeaker
The KL-6502-THX delivers effortless
dynamic range and brings superior sound
to larger areas thanks to its highly regarded
THX Select2 certification.
It employs dual 5.25-inch woven fiberglass
woofers for amazingly accurate sound, as
well as a titanium tweeter mated to an
exclusive Tractrix® Horn for flat in-room
frequency response with high efficiency and
low distortion. The speaker's precision-
voiced crossover networks further ensure
that the high and low frequencies are faith-
fully reproduced.
This in-wall speaker also consistently deliv-
ers thrilling, realistic sound, whether it's
installed horizontally or vertically. It fea-
tures all-new sure-grip mounting dogs that
provide even pressure against drywall for
long-term installation reliability, and includes
a paintable grille that blends in perfectly with
any décor.
Furthermore, the KL-6502-THX offers
unlimited flexibility. It is timbre matched to
all of our THX-certified products, so you
can mix and match to create an unbeatable,
discreet stereo or home theater system
that's just right for you.
KL-6502-THX
• THX Select2-certified for superior sound
• Horn-loaded for high efficiency and low distortion
• Easily mounts horizontally or vertically
• Maximum installation reliability
• Mix and match with our other THX products
S p e c i f i c a t i o n S
Frequency response
Power handling
Recommended amplifier power
Sensitivity
Nominal impedance
High frequency drivers
High freq crossover
Low frequency drivers
Enclosure material
Enclosure type
Dimensions
Mounting depth
Cutout dimensions
Installation kit
Weight
Finishes
All specifications are subject to change without notice. ©2008
46Hz-20kHz +/-3dB
100W continuous / 400W peak
150W
92dB @ 2.83V / 1m
8 ohms compatible
1" (2.5cm) Titanium diaphragm
compression driver mated to
90° x 90° square Tractrix
2100Hz & 1200Hz
Dual 5.25" (13.3cm) high-output,
fiberglass cone woofers
MDF & Aluminum motorboard /
ABS frame
Infinite baffle, front flush with wall
17.75" (45.1cm) H x 8" (20.3cm) W
3.75" (9.5cm)
16.5" (41.9cm) H x 6.5" (16.5cm) W
IK-502-W (sold seperately)
9.6lbs (4.4kg)
White paintable frame and grille
www.klipsch.com
1-800-KLIPSCH
