HOMCOM 820-195V70 Assembly & Instruction Manual page 6

Temperature and serial number display: Normally it displays the room temperature; while setting
the temperature, the setting temperature is displayed; When setting the timer, serial number is
displayed.
Time/ Temperature display: Normally it displays the current time; while setting the timer, the setting
time is displayed. When setting the temperature of the week timer, the setting temperature is
displayed.
Time on and time off: It is displayed while setting the timer, and it is used in combination with serial
number setting.
Flame brightness: It displays the current brightness of the flame, which ranges from one to five
positions.
Manual Operation
This is done by operating the switches located at the front of the fire .The standby rocker switch
must first be switched on, the fire will beep to indicate that it is powered up.
Press the O/I button once to turn the heater and flame effect on. A red indicator light will appear to
indicate that the function is ON. Press the O/I button for 3 seconds this will operate the flame
brightness setting. Hold the button down until the desired flame brightness is obtained and there
will be 5 levels flame brightness available.
Press the POWER button once for the low heat setting 1000W; press twice for the high heat setting
2000W; press three to switch off the heat setting.
Press the BACK LIGHT button to adjust the colors of LED decoration, 7 colors available.
Remote Operation
The standby rocker switch located at the front of the fire must first be switched on; the fire will beep
to indicate that it is powered up.
It takes a little time for the receiver to respond to the transmitter. Do not press the buttons more
than once within two seconds for the fire to operate normally.
1. Boot steps
1 Cursor
2 Day time
3 Timer
4 Standby
Temperature/serial
5 number display
6 Timer off
7 Timer on
Time/Temperature
8 display
Automatic control
9 of heating
10 Heating position
11 Flame brightness
6
