Baby Jogger city turn Manual

Convertible car seat
Hide thumbs Also See for city turn:
Table of Contents

Advertisement

Quick Links

city turn
TM
CONVERTIBLE CAR SEAT
CONVERTIBLE CAR SEAT
©2021 baby jogger NWL0001151803C 7/21
babyjogger.com
KEEP INSTRUCTIONS FOR FUTURE USE
Do not install or use this child restraint until you read and understand
the instructions in this manual.
FAILURE TO PROPERLY USE THIS CHILD RESTRAINT INCREASES THE RISK OF
SERIOUS INJURY OR DEATH IN A SUDDEN STOP OR CRASH.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the city turn and is the answer not in the manual?

Questions and answers

Related Manuals for Baby Jogger city turn

Summary of Contents for Baby Jogger city turn

  • Page 1 CONVERTIBLE CAR SEAT CONVERTIBLE CAR SEAT ©2021 baby jogger NWL0001151803C 7/21 babyjogger.com KEEP INSTRUCTIONS FOR FUTURE USE Do not install or use this child restraint until you read and understand the instructions in this manual. FAILURE TO PROPERLY USE THIS CHILD RESTRAINT INCREASES THE RISK OF...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safe Use Checklist ......................................3 Registration ..........................................5 Recall Information ......................................6 Certification ..........................................6 Warnings ............................................7 Features .............................................10 • Car Seat Rotation • Recline Foot • Rapidlock • Cup Holder Rear-Facing Installation ....................................21 • Rear-Facing Safe Use Checklist • Install Rear-Facing With Vehicle Seat Belt •...

  • Page 3: Safe Use Checklist

    SAFE USE CHECKLIST Your child’ s safety depends on you. No car seat can guarantee protection from injury in every situation, but proper use helps reduce the risk of serious injury or death. Even if this car seat seems easy to figure out on your own, you must follow the detailed instructions in this instruction manual to ensure the steps below are performed correctly.
  • Page 4 AAP, these infants may suffer breathing issues if improperly reclined in a car seat. When rear-facing, use the corrected age for preemies. Baby Jogger advises that you have your physician or hospital staff evaluate your infant and recommend the proper car seat or car bed before you and your infant leave the hospital.

  • Page 5: Registration

    Child restraints could be recalled for safety reasons. You must register this restraint to be reached in a recall. Send your name, address, email address if available and the restraint’ s model number and manufacturing date to: Baby Jogger, LLC P.O. Box 169, Elverson, PA 19520-9901 or call 1-800-241-1848 or register online at www.babyjogger.com/carseatregistration...

  • Page 6: Recall Information

    Note: To prevent damage to the seat, lower the headrest when checking the car seat at the airport. IF YOU NEED ASSISTANCE OR HAVE ANY QUESTIONS If you have any questions regarding installation of your seat, please contact consumer care: Baby Jogger, LLC 4110 Premier Drive High Point, NC 27265 1-800-241-1848 www.babyjogger.com For information regarding child restraints: www.NHTSA.gov...

  • Page 7: Warnings

    WARNING • Read this Owner’ s Manual completely BEFORE first use of your restraint system! • Keep instructions for future use. • Even if using this child restraint seems easy to figure out on your own, it is very important to READ, UNDERSTAND AND FOLLOW THE OWNER’S MANUAL.
  • Page 8 • Your child can be injured in a vehicle even if you are not in a crash. Sudden braking and sharp turns can injure your child if the child restraint is not properly installed or if your child is not properly secured in the child restraint.
  • Page 9 • Never use this child restraint if it has been damaged or broken or any component is missing. Do not use a cut, frayed or damaged child restraint harness, vehicle seat belt or lower anchor attachment belt. • It is not intended to be used in low-speed vehicles such as golf carts, ATV’ s or any other non- certified vehicles.

  • Page 10: Features

    FEATURES 1 Headrest/Harness Adjustment Lever 8 Cup Holder 2 Headrest 9 Harness Release Lever (under seat pad) 3 Head and Body Support 10 Harness Adjustment Strap 4 Harness Covers 11 Rotation Lever 5 Chest Clip 12 Seat Base 6 Lumbar Support 13 Lower Anchor Storage 7 Buckle...
  • Page 11 1 Seat Shell 4 Rear-Facing Belt Path 2 Tether 5 Seat Base 3 Forward-Facing Belt Path 6 Recline Foot...
  • Page 12 1 Tether Strap 3 Tether Strap Storage 2 Instruction Manual Storage 4 Recline Lever...
  • Page 13 WITH SEAT ROTATED 1 Forward-Facing RAPIDLOCK lock-off Release 5 Rear-Facing Level Indicator Button 2 Forward-Facing RAPIDLOCK lock-off 6 Rear-Facing Shoulder Belt Guide 3 Rear-Facing RAPIDLOCK lock-off Release 7 Lower Anchor Storage Button 4 Rear-Facing RAPIDLOCK lock-off...

  • Page 14: Car Seat Rotation

    CAR SEAT ROTATION The car seat can be rotated for rear-facing installtion and easy securing of your child in rear-facing mode. To rotate the car seat, squeeze the lever at the front of the car seat and rotate the seat. For rear-facing installation the car seat MUST be rotated to access rear facing belt path marked with a blue stripe.
  • Page 15 With your child secured, rotate the seat to the rear-facing position. The seat is secure when you hear a “CLICK!” Pull on the sides of the seat to make sure it is locked. CLICK • This car seat can ONLY be rotated in rear-facing mode. DO NOT rotate the seat when securing the child in forward-facing mode.

  • Page 16: Recline Foot

    RECLINE FOOT The recline foot on the bottom of the seat has two positions. The foot MUST be in the rear- facing position when the seat is being used in rear-facing mode. When the seat is being used in forward-facing mode, the foot MUST be in the forward-facing position. REAR-FACING POSITION FORWARD-FACING POSITION The correct position is marked with a label on the side of the foot.
  • Page 17 Unsnap the foot from base by pulling on the foot. Swing the foot forward or back to change positions. The recline foot is secure when it “clicks” into place. Recline Lever : The height of the recline foot is also adjustable. Squeeze the recline lever on the front of the foot and lift the base to extend the foot.

  • Page 18: Rapidlock

    RAPIDLOCK This seat comes with a lock-off feature called RAPIDLOCK. The RAPIDLOCK lock-off makes tightening the seat belt or lower anchor strap quick and easy. There are two RAPIDLOCK lock-offs on this seat, one for rear-facing mode, and one for forward-facing mode. The rear-facing RAPIDLOCK is located on the base and can only be found by rotating the seat.
  • Page 19 When installing the seat with the vehicle seat belt, BOTH the lap portion and the shoulder portion of the vehicle seat belt MUST be routed under the RAPIDLOCK arm. If your vehicle seat belt only has a lap belt, then route the lap belt under the RAPIDLOCK. When installing the seat with the lower anchor attachment system, the lower anchor strap is routed under the RAPIDLOCK.

  • Page 20: Cup Holder

    CUP HOLDER Cup holder MUST be installed. 1. From the left side of the seat, pull the seat pad out of the lower ribs and the lower clip to fully expose the cup holder slot. 2. Align the tabs on the cup holder with the slots in the shell and insert the cup holder until you hear a “Click!”...

  • Page 21: Rear-Facing Installation

    REAR-FACING SAFE USE Rear-Facing: 4-50 lb (1.8-22 kg) and whose head is at least 1 inch (2.5 cm) below the headrest adjustment handle* • Place the car seat rear-facing in the vehicle back seat. • Make sure lower anchor strap or vehicle seat belt is routed through the rear-facing belt path, marked with a blue stripe.

  • Page 22: Install Rear-Facing With Vehicle Seat Belt

    INSTALL REAR-FACING WITH VEHICLE SEAT BELT Make sure the cup holder is installed before installing the seat in your car. See the “Features” section on page 20 to install the cup holder. 1. Store the tether strap by attaching the tether hook to the slot on the back on the car seat.
  • Page 23 4. Extend the recline foot. The recline foot has 3 recline positions. Squeeze the recline lever and lift the base to extend the foot. Squeeze the recline lever and lower the base to retract the foot. Check the level indicator for appropriate install. •...
  • Page 24 6. Check the level indicator. Vehicle MUST be on level ground. Bubble must be completely under the blue lines. Adjust the recline until the bubble is completely under the blue lines. For infants 3 months and under, the bubble must be entirely under the light blue line.
  • Page 25 Review your vehicle’ s owner manual for vehicle seat belt use. 9. Route both vehicle lap and shoulder belt along the blue stripe across the base and under the RAPIDLOCK lock- off arm. Slide the vehicle shoulder belt though the slit near the edge of the base.
  • Page 26 10. Remove vehicle seat belt slack. Press down firmly near the front of the base. Pull on the shoulder belt to tighten while feeding the slack back in the retractor. Do not pull on the belt with excessive force. If the belt is too tight, you will not be able to close the RAPIDLOCK.
  • Page 27 13. Place your child in the seat and secure the child with the 5-point harness. See page 46 “Securing Child With 5-Point Harness” 14. With your child secured, rotate the seat to the rear-facing position. The seat is secure when you hear a “CLICK!” CLICK Pull on the sides of the seat to make sure it is locked.

  • Page 28: Install Rear-Facing With Lower Anchor Attachment

    INSTALL REAR-FACING WITH LOWER ANCHOR ATTACHMENT Make sure the cup holder is installed before installing the seat in your car. See the “Features” section on page 20 to install the cup holder. Review your vehicle’ s owner’ s manual for LATCH location and use.
  • Page 29 4. From the front of the car seat, open the lower anchor storage door. Remove the lower anchor strap and connectors from the storage compartment. Close the lower anchor storage door 5. Place car seat rear-facing in back seat of the vehicle. Place the base flat on the vehicle seat.
  • Page 30 7. Squeeze the rotation lever at the front of the car seat and rotate the seat. The seat may be rotated towards or away from you. The seat MUST be rotated to install in rear-facing mode. Tip! You may find it easier to install the seat with it rotated away from you.
  • Page 31 10. Route the lower anchor strap along the blue stripe across the base and under the RAPIDLOCK lock-off arm. The lower anchor strap should not be twisted. If twisted, you will not be able to tighten the strap. CORRECT: The lower anchor strap is routed along the blue stripe and under the RAPIDLOCK arm.
  • Page 32 11. Attach the lower anchor connectors to the vehicle’ s lower anchors. Make sure the arrows are pointing up. Lower anchor attachment can only be used if the vehicle lower anchor spacing is 11” (28 cm) from the center of one lower anchor to the center of the other lower anchor.
  • Page 33 14. Test for tightness. Grab the sides of the base where the lower anchor strap is and slide the base side to side and front to back. If the base moves less than 1” (2.5 cm), it is tight enough. 15 Place your child in the seat and secure the child with the 5-point harness.

  • Page 34: Forward-Facing Installation

    FORWARD-FACING SAFE USE Forward-Facing: 22-65 lb (10-30 kg) and 49” (125 cm) or less. * • Place the car seat forward-facing in the vehicle back seat. • Make sure lower anchor strap or vehicle seat belt is routed through the forward-facing belt path, marked with a orange label.

  • Page 35: Install Forward-Facing With Vehicle Seat Belt And Tether

    INSTALL FORWARD-FACING WITH VEHICLE SEAT BELT AND TETHER Make sure the cup holder is installed before installing the seat in your car. See the “Features” section on page 20 to install the cup holder. 1. Store the lower anchor connectors inside the lower anchor storage compartment.
  • Page 36 4. Unhook the tether from the storage location on the back on the seat, and lay it over the front of the seat. 5. Place car seat forward-facing in back seat of the vehicle. Place the base flat on the vehicle seat. Push it back firmly until the back of the car seat touches the vehicle seat back.
  • Page 37 8. Open the RAPIDLOCK lock-off by pushing the gray button and lifting the lock-off arm. Review your vehicle’ s owner manual for vehicle seat belt use. 9. Thread vehicle seat belt through the orange forward-facing belt path, through the RAPIDLOCK lock-off, and out the other side.
  • Page 38 11. When the slack is removed, close the RAPIDLOCK lock-off until you hear a “Click”. Make sure the vehicle seat belt is under CLICK the RAPIDLOCK Lock-Off. Keep hands away from the RAPIDLOCK lock-off area when closing the RAPIDLOCK lock-off. 12.
  • Page 39 15. Replace the seat pad. Move the headrest back to its proper position for your child. See page 46 “Securing Child With 5-Point Harness”...

  • Page 40: Install Forward-Facing With Latch

    INSTALL FORWARD-FACING WITH LATCH Make sure the cup holder is installed before installing the seat in your car. See the “Features” section on page 20 to install the cup holder. Review your vehicle’ s owner manual for LATCH location and use. Do not install by this method for a child weighing more than 40 lb (18 kg) 1.
  • Page 41 3. Unhook the tether from the storage location on the back on the seat, and lay it over the front of the seat. 4. Place car seat forward-facing in back seat of the vehicle. Place the base flat on the vehicle seat. Push it back firmly until the back of the car seat touches the vehicle seat back.
  • Page 42 7. Lift the headrest pad flap up out of the way. 8. Open the RAPIDLOCK lock-off by pushing the gray button and lifting the lock-off arm. 9. For easier installation, extend the lower anchor strap to its maximum length by pressing the gray button and pulling out on the strap.
  • Page 43 11. Attach lower anchor connectors to vehicle’ s lower anchors. Make sure the arrows are pointing up. Lower anchor attachment can only be used if the vehicle lower anchor spacing is 11” (28 cm) from the center of one lower anchor to the center of the other lower anchor.
  • Page 44 13. When the slack is removed, close the RAPIDLOCK Lock-Off until you hear a “Click”. Make sure the lower anchor strap is under the RAPIDLOCK Lock-Off. CLICK Keep hands away from the RAPIDLOCK lock-off area when closing the RAPIDLOCK lock-off. 14.
  • Page 45 17. Replace the seat pad. Move the headrest back to its proper position for your child. See page 46 “Securing Child With 5-Point Harness”...

  • Page 46: Securing Child With 5-Point Harness

    SECURING CHILD WITH 5-POINT HARNESS WARNING! In cold weather, do not put snowsuits or bulky garments on your child when placing them in the car seat. Bulky clothing can prevent the harness straps from being tightened properly. To keep child warm, buckle your child in the car seat and place a blanket around the child or place the child’...
  • Page 47 4. Be sure the harness straps are at the proper 1” (2.5 cm) 1” (2.5 cm) height. Rear-facing: harness straps must be at or just below the child’ s shoulders and top of head must be at least 1” (2.5 cm) below the headrest/ harness adjustment handle.
  • Page 48 Turn buckle strap sideways and slide to desired slot. Make sure buckle strap is in one of the two positions. 6. Replace seat pad, making sure the buckle goes through the same slot in the seat pad as in the plastic shell 7.
  • Page 49 8. Pull all the slack out from around the waist. Pull up on the harness strap while pushing the chest clip down. Do this to both sides. 9. Tighten the harness by pulling the harness adjustment strap. A snug harness should not allow any slack. It lies in a relatively straight line without sagging.

  • Page 50: Accessories

    ACCESSORIES (on select models) All infant support pieces (Head and Body Support, Lower-Seat Pad, and Lumbar Support) can be used Rear-Facing up to 15 lbs (7 kg). This may vary slightly depending on child’ s stature. Use the infant support pieces to ensure the child is secure, comfortable, and their head does not tilt forward.

  • Page 51: Lumbar Support

    Lumbar Support • When the seat is used in forward-facing mode, the lumbar support MUST be used with a child weighing less than 25 lb (11 kg). • Never allow lumbar support to bunch or fold behind child. To remove, pull the lumbar support out from behind the head and body support.

  • Page 52: Choosing A Seat Location

    CHOOSING VEHICLE SEAT LOCATION WARNING! • NEVER place this child restraint rear-facing in a vehicle seating location that has an active front airbag. DEATH or SERIOUS INJURY can occur. • Failure to place the child restraint in the correct seating positions increases the risk of serious injury or death.

  • Page 53: Latch / Lower Anchor Attachment System

    LATCH / LOWER ANCHOR ATTACHMENT SYSTEM LATCH stands for Lower Anchors and Tethers for CHildren. LATCH consists of lower anchors and tether anchors, which are built-in to your vehicle, and connecting hooks that are built-in to your car seat. Lower anchors are used INSTEAD of the vehicle’...
  • Page 54 UNSAFE VEHICLE SEAT BELTS In some vehicles you may WARNING! The following types of vehicle seat belts not get a secure fit. Read both your vehicle and car are NOT compatible with this child seat. If any of the belt seat manuals.

  • Page 55: Vehicle Seat Belts

    Switchable. If it can still be pulled out freely, it is ELR. Note: Most vehicles manufactured after 1996 will have switchable retractors in the back seat. If you have any questions about your retractor type, consult your vehicle owner’ s manual or call Baby Jogger for assistance.
  • Page 56 HOW TO LOCK YOUR LAP/SHOULDER VEHICLE SEAT BELT Sliding Latch Plate and Switchable Retractor A latchplate that slides freely on the belt webbing and cannot, by itself, hold the belt snug around a car seat. When installing the car seat, route the vehicle seat belt through the proper belt path and buckle it in.
  • Page 57 Sliding Latch Plate and ALR Retractor A latchplate that slides freely on the belt webbing and cannot, by itself, hold the belt snug around a car seat. Slowly pull the shoulder belt all the way out. Route the vehicle seat belt through the proper belt path and buckle it in.
  • Page 58 LAP BELT INSTALLATION Always review your vehicle owner’ s manual for specific information about your vehicle seat belts. Locking Latch Plate and No Retractor When installing the car seat, route the lap seat belt through the proper path and buckle it in.
  • Page 59 CLEANING SEAT PAD Clean the seat pad with a damp sponge using mild soap and cool water. Refer to seat pad care tag for washing instructions. Headrest Pad If needed, headrest pad may be removed for cleaning. To remove, first raise the headrest to its highest position. Then unsnap the two snaps under the headrest Undo the two snaps behind the headrest.
  • Page 60 Seat Pad If needed, the seat pad may be removed for cleaning. To remove, unsnap the two snaps in the seat. Then, pull out the two plastic buttons on the front of the car seat. Note: You may have to rotate the seat to access the two buttons. Lower the headrest to its lowest position.
  • Page 61 Remove the edges of the pad fabric from the 4 clips found inside the car seat shell lip Remove the edges of the pad fabric from the ribs on lower sides of the seat. Pull the pad off. Machine wash cover in cold water on delicate cycle and drip-dry. DO NOT USE BLEACH.

  • Page 62: Care And Maintenance

    CARE AND MAINTENANCE Cleaning the Seat Pad: Refer to the care tag on your seat pad for washing instructions. NEVER use carrier without the seat pad attached. Cleaning the Shell: Spot clean using warm water and mild soap. Do not use any other cleaning agents or bleach. Cleaning the Harness Straps: Spot clean with mild soap and damp cloth.

  • Page 63: Warranty

    Attorney General. Note: When contacting Baby Jogger regarding your product, please have the serial number and manufacturing date ready. It can be found on the back of the car seat.

  • Page 64: Replacement Parts

    To purchase parts or accessories in the United States, please contact us at the following: www.babyjogger.com 1-800-241-1848 Store instruction manual in the slot with the instruction book icon as shown. Baby Jogger, LLC 6655 Peachtree-Dunwoody Rd. NE • Atlanta, GA 30328 www.babyjogger.com...
