UNIT DESCRIPTION & ACCESSORIES INCLUDED
Explanation of symbols displayed on the unit
D
C
B
A Castor
B
Remote Control
C Signal Receiver
D
Air Outlet Grill
E
Control Panel
F Carrying Handle
This symbol shows that this appliance used a flammable
refrigerant. If the refrigerant is leaked and exposed to an
WARNING
external ignition source, there is a risk of fire.
This symbol shows that the operation manual should be
CAUTION
read carefully.
This symbol shows that a service personnel should be
CAUTION
handling this equipment with reference to the installation
manual.
This symbol shows that information is available such as
CAUTION
the operating manual or installation manual.

Unit Description

E
F
G
A
L
K
J
G Air Exhaust
H
Air Intake
Heat Pump Drain Outlet
I
(for heat pump model)
J
Bottom Drain Outlet
K Power Cord
L
Continuous Drain Outlet
7
H
I
