Introduction...................................................... 2
Important Safety Instructions.................... 3
Normal Sounds................................................12
FCC Statement................................................13
Air Conditioner Features.............................14
Frigidaire.com USA 1-800-944-9044
use
Room Air Conditioner
care
&
Operating Instructions................................ 15
Care And Cleaning.......................................20
Energy Saving Ideas................................... 20
Before You Call.............................................. 21
Major Appliance Limited Warranty....... 23
Frigidaire.ca Canada 1-800-265-8352
Models:
FHTW123WB1
Advertisement
Related Manuals for Frigidaire FHTW123WB1
Summary of Contents for Frigidaire FHTW123WB1
- Page 1 Introduction............2 Operating Instructions........ 15 Important Safety Instructions....3 Care And Cleaning........20 Normal Sounds..........12 Energy Saving Ideas........20 FCC Statement..........13 Before You Call..........21 Air Conditioner Features......14 Major Appliance Limited Warranty..23 Models: FHTW123WB1 Frigidaire.com USA 1-800-944-9044 Frigidaire.ca Canada 1-800-265-8352...
- Page 2 INTRODUCTION family Welcome to our Thank you for bringing Frigidaire into your home! We see your purchase as the beginning of a long relationship together. This manual is your resource for the use and care of your product. Please read it before using your appliance.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS The power cord is equipped with a WARNING three-prong grounding plug for protection against shock hazards. For Your Safety • Your air conditioner must be used in a Do not store or use gasoline or other properly grounded wall receptacle. If the flammable vapors and liquids in the vicinity wall receptacle you intend to use is not of this or any other appliance.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS • Do not direct airflow at fireplaces or other NOTE heat related sources as this could cause flare ups or make units run excessively. The power supply cord with this air • Do not climb on or place objects on conditioner contains a current detection outdoor part of the unit.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS • If the supply cord is damaged, it must be NOTE replaced by the manufacturer, its service agent or similarly qualified persons in order • Do not use this device to turn the unit on or to avoid a hazard. off.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS well-ventilated area where the room size regulations or instructions, whichever is corresponds to the room area as specified more stringent. for operation. 5. Storage of packed (unsold) equipment • Any person who is involved with working Storage package protection should be on or breaking into a refrigerant circuit constructed such...
- Page 7 IMPORTANT SAFETY INSTRUCTIONS associated parts, appropriate fire circuit is being used, the secondary circuit extinguishing equipment shall shall be checked for the presence of available to hand. Have a dry powder or refrigerant; Marking to the equipment CO2 fire extinguisher adjacent to the continues to be visible and legible.
- Page 8 IMPORTANT SAFETY INSTRUCTIONS searching for or detection of refrigerant e) continuously flush or purge with inert leaks. A halide torch (or any other gas when using flame to open circuit; detector using a naked flame) shall not be and; used. f) open the circuit.
- Page 9 IMPORTANT SAFETY INSTRUCTIONS tested with OFN. The system shall be leak equipment are closed off. tested on completion of charging but k) Recovered refrigerant shall prior to commissioning. A follow up leak charged into another refrigeration system test shall be carried out prior to leaving unless it has been cleaned and checked.
- Page 10 IMPORTANT SAFETY INSTRUCTIONS evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant. The compressor body shall not be heated by an open flame or other ignition sources to accelerate this process. When oil is drained from a system, it shall be carried out safely.
- Page 11 IMPORTANT SAFETY INSTRUCTIONS Wiring Diagram DAHT SENSOR OUT E. SENSOR CN10 OUT A. SENSOR TRANSFORMER FAN CAP YELLOW BROWN BLUE WHITE YELLOW FAN MOTOR RY6N P10(OR P7) BLACK P7(OR P10) WHITE P6(P9) BLACK COMP RY6L BLACK GRAY(BLUE) CN11 BLACK CN12 CN13 WHITE (PRIMARY) (SECONDARY)
- Page 12 NORMAL SOUNDS Normal Sounds High pitched Chatter Today’s high e ciency compressors may have a high pitched chatter during the cooling cycle. Vibration Unit may vibrate and make noise because of poor wall or window construction or incorrect installation. Pinging or Swishing Droplets of water hitting condenser during normal operation may cause “pinging or swishing”...
- Page 13 FCC STATEMENT FCC Interference Statement antenna or transmitter unless authorized to do so by the FCC. This equipment has been tested and found to comply with the limits for a Class B digital INDUSTRY CANADA (IC) STATEMENT device, pursuant to part 15 of the FCC Rules. This Class B digital apparatus complies with These limits are designed to provide Canadian ICES-003.
- Page 14 Before you begin, thoroughly familiarize yourself with the control panel and remote control and all its functions (as shown below). The unit can be controlled by the touch pad, or with the remote control, or with the Frigidaire app*. Turns Unit On Or O...
- Page 15 OPERATING INSTRUCTIONS YOU WILL SEE: NOTE The following instructions represent the touch pad. The same instructions can be used for the remote control. TO TURN UNIT ON: Note: The display will show the set temperature during normal operation, press either up ( ) or down ( ) button to adjust the set temperature to the desired setting.
- Page 16 OPERATING INSTRUCTIONS YOU WILL SEE: COOL FEATURE: Note: Fan starts at High Speed and adjusts to a slower speeds the room temperature DO THIS: dictates. For example, if the room doesn't PRESS MODE BUTTON get too warm, it will stay at the slowest CHOOSE COOL speed.
- Page 17 OPERATING INSTRUCTIONS ECO (ENERGY SAVER) MODE: CHECK FILTER FEATURE, YOU WILL SEE: Note: This feature is a reminder to clean the Air Filter (See Care and Cleaning) for more DO THIS: e cient operation. The LED (light) will PRESS MODE illuminate after 250 hours of operation.
- Page 18 OPERATING INSTRUCTIONS TO CHANGE TEMPERATURE DISPLAY: YOU WILL SEE: Note: The control is capable of displaying temperature in degrees Fahrenheit or DO THIS: degrees Celsius. PRESS AND HOLD THE UP/DOWN BUTTONS SIMULTANEOUSLY FOR 3 SECONDS DIMMING DISPLAY: After 60 seconds of control inactivity the display and indicator lights will turn o . Press any button on the control panel or remote control and the display will resume.
- Page 19 OPERATING INSTRUCTIONS ADDITIONAL THINGS YOU SHOULD KNOW Air Directional Louvers Air directional louvers control air flow Now that you have mastered the operating direction. Your air conditioner has the louver procedure, here are more features in your type described below. control that you should become familiar with.
- Page 20 CARE AND CLEANING & ENERGY SAVING IDEAS Cabinet Cleaning Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the • Be sure to unplug the air conditioner to unit before cleaning to prevent shock or prevent shock or fire hazard.
- Page 21 BEFORE YOU CALL Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. OCCURRENCE SOLUTION • Wall plug disconnected. Push plug firmly into wall outlet. •...
- Page 22 • Remote Sensing activated (on some models) and remote control located in Hot Spot - Relocate remote control or deactivate remote sensing. Trouble connecting the smart appliance • Please visit Frigidaire.com and select the Owner Support section to view to your wifi network Frequently Asked Questions. or experiencing an issue with the app.
- Page 23 MAJOR APPLIANCE LIMITED WARRANTY Your appliance is covered by a limited one-year warranty for functional repairs only. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
- Page 24 Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your registration card for more information.) Frigidaire.com 1-800-944-9044 Frigidaire.ca 1-800-265-8352 16120300A34271 (Oct. 2024)
