PCB Piezotronics ICP 261B02 Manual page 11

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
8X 5/16-24 UNF - 2B THRU
.14 [3.5]
(.387 [9.83])
[ ]
2.358  .006 59.89  .15
(.387 [9.83])
A
4
3
  [  ]
2X 2.165 .001 54.99 .03
  [  ]
2X 1.654 .001 42.01 .03
Z
X
1/4-28 UNF - 2A
Y
4-PIN ELECTRICAL CONNECTOR
A
A
3
2
NOTCH
X-AXIS
GROUND
Z-AXIS Y-AXIS
PIN OUT
SCALE 4.5X
 1.00 [25.4] WASHER
(SUPPLIED)
SECTION A-A
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DRAWN
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
JJF
[ IN BRACKETS ]
DECIMALS XX ±.03 DECIMALS X ± 0.8
XXX ±.010 XX ± 0.25
TITLE
ANGLES  2 DEGREES ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH CABLE TOLERANCES IN METRIC
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
1
REVISIONS
REV DESCRIPTION
NR RELEASED TO DRAFTING
1/2-20 UNF-2B NUT
(SUPPLIED)
081M180 MOUNTING STUD
(SUPPLIED)
083M18 BUSHING
(SUPPLIED)
NON-CONDUCTIVE
CERAMIC COATING
CHECKED ENGINEER
10/26/21 JJF 10/26/21 EDB 10/26/21
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
OUTLINE DRAWING
DWG. NO.
MODEL 261B02 CODE
74524
IDENT. NO.
TRIXIAL FORCE SENSOR
52681
SCALE: 1.25X
1
DIN
52099
B
A
SHEET 1 OF 1
