PCB Piezotronics ICP 261B02 Manual page 10

Model Number
261B02
Performance
Sensitivity(± 20 %)(Z Axis)
Sensitivity(± 20 %)(X or Y Axis)
Measurement Range(Z Axis)
Measurement Range(X or Y Axis)
Maximum Force(z axis)
Maximum Force(x or y axis)
Maximum Moment(z axis)
Maximum Moment(x or y axis)
Broadband Resolution(x or y axis)
Broadband Resolution(x or y axis)
Resonant Frequency
Low Frequency Response(- 5 %)(z-axis)
Low Frequency Response(- 5 %)(x or y axis)
Non-Linearity
Cross Talk(between x and y axis)
Cross Talk(between (x or y axis) and z axis)
Environmental
Temperature Range
Electrical
Full Scale Output(Z Direction)
Full Scale Output(X and Y Direction)
Discharge Time Constant(z axis)
Discharge Time Constant(x or y axis)
Excitation Voltage(all channels)
Constant Current Excitation(all channels)
Output Impedance
Output Bias Voltage
Spectral Noise(1 Hz)(X & Y)
Spectral Noise(10 Hz)(X & Y)
Spectral Noise(100 Hz)(X & Y)
Spectral Noise(1,000 Hz)(X & Y)
Spectral Noise(1 Hz)(X & Y)
Spectral Noise(10 Hz)(Z)
Spectral Noise(100 Hz)(Z)
Spectral Noise(1,000 Hz)(Z)
Output Polarity
Electrical Isolation
Physical
Stiffness(z axis)
Stiffness(x or y axis)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
3-COMPONENT ICP® FORCE SENSOR
EN GLISH SI
2.5 mV/lb 0.56 mV/N
5 mV/lb 1.12 mV/N
1,000 lb 4.45 kN
1,000 lb 4.45 kN
1,320 lb 5.87 kN
1,000 lb 4.45 kN
40 ft-lb 54.23 Nm
70 ft-lb 94.91 Nm
0.006 lb-rms 0.027 N-rms
0.006 lb-rms 0.027 N-rms
13 kHz 13 kHz
0.01 Hz 0.01 Hz
0.001 Hz 0.001 Hz
≤ 1 % FS ≤ 1 % FS
± 3 % ± 3 %
± 5 % ± 5 %
-65 to +250 °F -54 to +121 °C
± 2.5 VDC ± 2.5 VDC
± 5 VDC ± 5 VDC
≥ 50 sec ≥ 50 sec
≥ 500 sec ≥ 500 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
.001 lb/√Hz .0044 N√Hz
.0003 lb/√Hz .00143 N√Hz
.00008 lb/√Hz .000366 N√Hz
.00002 lb/√Hz .000082 N√Hz
.002 lb/√Hz .0104 N√Hz
.0006 lb/√Hz .00256 N√Hz
.0002 lb/√Hz .00074 N/√Hz
.00005 lb/√Hz .000227 N√Hz
Positive Positive
8 8
≥ 10 Ohm ≥ 10 Ohm
7.3 lb/µin 1.28 kN/µm
2.9 lb/µin 0.51 kN/µm
34.40 oz 975 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
4-Pin 4-Pin
Side Side
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
- Metric Mount
M
W - Water Resistant Cable
Electrical Connection Position
[1]
[1]
[1]
[2]
[1]
[1]
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
Entered: ND Engineer: EB
Date: 10/26/2021 Date: 10/26/2021 Date: 10/26/2021 Date: 10/26/2021 74523
3425 Walden Avenue, Depew, NY 14043
Revision: NR
ECN #: 52099
OPTION AL VERSION S
Side Side
Sales: BS Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
