Do not use alcohol or drugs when using the J-Dream II. The elderly, the infirm, and children should not use the J-Dream II unattended. Pregnant women and people with heart conditions should consult their physicians before using the steamer.
Once the J-Dream II has been removed from the carton and before it is permanently installed, check the parts completely for damage resulting from shipping or handling. All Jacuzzi Whirlpool Bath products are factory tested for proper operation and watertight connections prior to shipping.
General Assembly Information The J-Dream II shower unit is installed into a niche with the drain towards the left hand side of the unit as you face the shower door. This manual details the assembly, installation and operation. After the drain, water supply stub-out, and electrical supply are provided, the shower unit should be assembled freestanding away from the walls of the room.
Page 6
Lighting and electrical receptacles must be located at least 5 feet (1.5 meters) from the J-Dream II. Lighting located between 5 feet and 10 feet (1.5 meters and 3 meters) from the J-Dream II must be on a circuit protected by a GFCI. Do not use electrically connected devices, such as television, radio, telephones, stereo speakers, lights or cooking devices within 5 feet of the J- Dream II while it is in use.
J-Dream II Owner's Manual J-Dream II Packaging 6 cartons packed together on a wooden crate. Contents of cartons: • Wall Panels • Door Frame • Base/Cover (includes product accessory pack and owners manual) • Back Wall • Seat Wall • Equipment/Seat Wall...
J-Dream II Owner's Manual Letters (A) are used in the illustrations of the assembly procedure. CLIP SCREW WASHER SCREW SCREW BOLT BOLT WASHER U-CLIP 10-24 PAN HEAD SCREW #10-24 x 3/4" WASHER SCREW FLAT WASHER 1/4" LOCK NUT 10-24 SIDE...
J-Dream II Owner's Manual Rough-in HOSE BIBB (2) (2) 1/2 " HOT & COLD WATER SUPPLY LINES IMPORTANT: This is the installed position of the waste stub-out when connected to the shower drain. If the stub-out is installed before the shower unit, leave enough flex in the waste...
J-Dream II Owner's Manual Locate Base to provide assembly access to all sides Remove Base from carton labeled Base/Top. Place Clear Top in carton to prevent damage. (The Clear Top will not be installed until the unit has been fully assembled and plumbed).
Page 11
J-Dream II Owner's Manual Drain Fitting (provided with unit) Leave enough flexibility in the waste line to allow the end of the stub-out to be blocked temporarily in a position under flush with the floor surface. This will allow the shower unit to slide across the floor into position without having to lift the shower unit.
J-Dream II Owner's Manual Attach Seat Walls to Base Bolts (8) Washers (8) Nuts (8) (J-Dream II with stereo shown) Align four holes on seat wall frame over base and insert bolts and tighten nuts from underneath. Non-Equipment Seat Wall...
Page 13
J-Dream II Owner's Manual Attach Panel #2 to Seat Wall Frame Slide in panel feeding between frame and edge of seat wall. Align to frame and fasten panel to frame. Important: do not caulk panel to seat wall as the seat wall is hinged and designed to swing open.
Page 14
J-Dream II Owner's Manual Attach Panel #3 to Seat Wall Frame Slide in panel feeding between frame and edge of seat wall. Align to frame and fasten panel to frame. Important: do not caulk panel to seat wall as the seat wall is hinged and designed to swing open.
Page 15
J-Dream II Owner's Manual Install Back Wall Caulk the bottom and sides of back wall where indicated in the illustrations below. Install fasteners. Now align the back wall parallel to the pan lip to center the back wall between the seat walls.
Page 16
J-Dream II Owner's Manual Attach Panels #1 and #4 to Seat Walls Remove 4 bolts from seat walls to attach panels # 1 and #4. Caulk along surface of seat walls. Caulk Nut (3) Washer (10) Screw (3) Seat wall attaches to panel #1 and #4 in two places.
Page 17
J-Dream II Owner's Manual Attach Brackets to Seat Wall Frames and L Bracket to left Angle Bracket Side Bracket Nut (2) Frame Screw (2) Bolt (remove top bolt from seat wall bracket and reinstall). See below dimensions for bolt locations.
Page 18
J-Dream II Owner's Manual Attach Painted Angle Brackets to Panels #1 and #4 Note that each angle bracket has a notch on the top and bottom. This notch does not get screwed against the side panels but faces out as shown in the side view for both left and right sides.
J-Dream II Owner's Manual Attach Door Frame to Angle Brackets and Base Frame Before proceeding, make sure the seat walls are closed and fastened. See detail B on page 15. Align door frame over tabs on base frame and pan lip. Pan lip is to fit into corner posts of door frame. Align holes along sides of door frame with angle brackets and mark this position of the angle brackets.
J-Dream II Owner's Manual Attach Top Frame to Door Frame, Back Wall and Seat Wall Frames Press/tap top frame into door frame, aligning notch in door frame with corner of top of frame while aligning with corners of enclosure. Frame snaps down into door frame and back snaps over back wall. Install bolts (4) through top frame and into left and right seat wall frames.
Feed the four hoses and controller cable from the back wall and connect them as shown. The steam hose connection uses a hose clamp while the other hoses use spring clamps that are on the hoses. Also feed the CD/Radio wire bundle to the back wall. (J-Dream II with stereo only.) From Backwall...
Page 22
J-Dream II Owner's Manual Back Wall Use cable ties to attach the CD/Radio wire bundle to the cascade hose. The hoses from valves 1 and 3 and the steam hose are loosely attached to their mounting brackets to allow the slack when connecting them and when the hinged seat wall is swung open (like a door) to access equipment.
Page 23
J-Dream II Owner's Manual Right Seat Wall (Equipment Wall) Connect the hoses routed from the back wall as below (grayed lines are pre-attached). Connect the controller line. The red and black leads in the CD/Radio wire bundle must be hooked up to the corresponding colored leads of the power supply.
J-Dream II Owner's Manual Bonding (top left hand side of right hand equipment seat wall) Connect a #8 guage (10mm 2 ) minimum solid copper bond wire to the house electrical pannel or an approved local ground. An approved ground may be an 8 foot long ground rod (3 meter long earth rod), a plate electrode or ther acceptable bond location.
Move the assembled J-Dream II into final position. Connect 2" shower drain (see page 9). Adjust the levelling screws in the J-Dream II base feet and lock them in position. Recheck fit of drain plumbing. Secure J-Dream II in position using clamps provided as shown in Figure 1.
J-Dream II Owner's Manual Attach Front Panels to Unit Attach both left and right front panels with pre-installed Velcro®. On the left front panel, install 2 screws through the top of the panel. Connect the CD/radio ground wire, speaker/power connector and antenna wire before installing left front panel.
J-Dream II Owner's Manual Turn On Electric Power at Main Breaker Operate Unit and Check for Leaks Attach Bottom Front Panel to Unit Take the bottom panel at an angle and insert under the bottom of the enclosure frame. Rotate backwards till it is up...
Part II: Operating Instructions CONTROL PANEL System control is provided by the electronic display located inside the shower cabin (see Figure 1) The display is used to start up the five functions of the unit: the shower, the cascade waterfall, the hydromassage (all jets), hydromassage (pulsed jets), and the steam bath.
Page 30
If power to the unit is interrupted, the CD Receiver will have to be reset. Note:For units with AM/FM radios, the quality of AM reception will vary by locality. Jacuzzi Whirlpool Bath is not responsible for the quality of AM reception.
Page 31
Care and Maintenance of SteamPros Maintenance of the Steampros includes flushing and visually inspecting for water leaks. To flush the units: 1. Turn OFF power to the unit. 2. To gain access to the SteamPros, the seat wall (equipment wall) must be swung open. To do so, remove the three screws from door frame (refer to page 17, diagram A).
Page 32
Jacuzzi Whirlpool Bath has obtained applicable code (standards) listings generally available on a national basis for products of this type. It is the responsibility of the installer/owner to determine specific local code compliance prior to installation of this product. Jacuzzi Whirlpool Bath makes no representation or warranty regarding, and will not be responsible for any code compliance.
NOTICE: This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. There are no warranties applicable to Jacuzzi Whirlpool Bath products except as expressly stated herein or as implied by applicable state and federal laws. The Company will not be responsible for any statements or representations made in any form that go beyond, are broader than or are inconsistent with any authorized literature or specifications furnished by the Company.
Page 36
The Company will provide the warranty service described above when the following conditions have been met: the failure is of the nature or type covered by the warranty; the user has informed an Authorized Jacuzzi Whirlpool Bath Service Agent or Warranty Service Department Representative of the nature of the problem during the warranty period;...
