- Page 1 SEDONA ™ Steam & Shower Base INSTALLATION/OPERATING INSTRUCTIONS...
-
Page 2: Important Safety Information
READ ALL INSTALLATION INSTRUCTIONS Jacuzzi Whirlpool Bath does not recommend prolonged periods of use of the steamer. Prolonged use of the steam system can raise excessively the internal human body temperature and impair the body’s ability to regulate its internal temperature (hyperthermia). -
Page 3: Table Of Contents
Specifications _________________________________________________________________________ 2 Roughing-in Reference _________________________________________________________________ 2 Framing and Support ___________________________________________________________________ 3 Steam Enclosure _____________________________________________________________________ 4 SteamPro™ Drain Down Configurations Digital Control & Temperature Sensor Rough-in Drain Information ______________________________________________________________________ 6 Plumbing and Water Supply ______________________________________________________________ 6 Electrical Connections ___________________________________________________________________ 6 Digital Controller Mounting _______________________________________________________________ 7 Temperature Sensor Mounting ____________________________________________________________ 8 Flange Mounting _______________________________________________________________________ 8... -
Page 4: Specifications
Refer any claims for damage to the carrier. For definitions of warranty coverage and limitations, refer to the published warranty information packaged with the product. Jacuzzi Whirlpool Bath is not responsible for any defect that could have been discovered, repaired, or avoided by following this inspection and testing procedure. -
Page 5: Framing And Support
Before installation, remove liner to inspect for any defects, reapply and do not remove until final cleanup. FRAMING AND ROUGH-IN DETAILS (FOR LEFT HAND UNIT) HEIGHT OF UNIT WITH JACUZZI WHIRLPOOL BATH STEAM ENCLOSURE: 83-3/8" ±1/4". WITH DOME ADD 2" ±1/4" 17-7/8" 10-1/2" x 5"... -
Page 6: Steam Enclosure
85-3/8" UNIT WITH JACUZZI WHIRLPOOL BATH OPTIONAL STEAM ENCLOSURE Drain Down Locations There are several locations (left hand unit shown) where the optional automatic valve may be located when connecting to a drain line as shown in illustration. Right hand unit is mirror image. Exact location to be determined by installer. -
Page 7: Digital Control & Temperature Sensor Rough-In
Minerals in the water or poor water quality can shorten the life of the steam generator or cause erratic operation if the tank is not drained regularly. Drain the tank frequently. Jacuzzi Whirlpool Bath also strongly recommends purchasing and installing the optional automatic drain down valve. The tank will be drained automatically after each use after the water temperature lowers. -
Page 8: Drain Information
NOTE: Watertight installation of the drain is the installer's responsibility. Drain leakage is excluded from the Jacuzzi Whirlpool Bath warranty of this product. Slide the shower base into the framed opening and attach the shower base flange to the stud wall and blocking with screws provided. -
Page 9: Digital Controller Mounting
Controller Mounting Finished Wall Mounting The low voltage control can be mounted directly to a finished wall either inside or outside the steam room. Using a 2" hole saw, drill a hole in the finished wall where the control is to be mounted (the control cable should already be roughed-in to this location). -
Page 10: Temperature Sensor Mounting
Temperature Sensor Mounting The temperature sensor should be mounted 6" below the ceiling or dome, inside the steam room, but not directly over the steam dispersion head or more than 7 feet above the floor. Using a 7/8" hole saw, drill a hole in the finished wall where the sensor is to be mounted (the sensor cable should already be roughed-in to this location). -
Page 11: Finish Materials
Meguiar's #10 Mirror Glaze. If that is not available, use automotive rubbing compound followed by an application of automotive paste wax. Major scratches and gouges which penetrate the acrylic surface will require refinishing. Ask your Jacuzzi Whirlpool Bath dealer for special instructions. ACCESS PANEL... -
Page 12: Operation
Operation The digital control features an adjustable 60 minute time and temperature control with digital display. The actual room temperature and time remaining are alternately displayed every 5 seconds. The temperature can be adjusted in a range between 100 degrees and 125 degrees Fahrenheit with an initial default of 120 degrees. Once the set temperature is reached the ‘’soft steam’’... -
Page 13: Troubleshooting
Troubleshooting There are no user serviceable parts in the Generator. All repair should be performed by a qualified service person. For additional assistance or the factory authorized service person nearest you call the Service Department at 1-800- 363-0251 (This number is only for service for the steam generator.). The Trouble Shooting Guide below is meant as a general aid only. -
Page 14: Troubleshooting
Troubleshooting... -
Page 15: Steampro™ Wiring Diagram
Wiring Diagram... - Page 16 It is the responsibility of the installer/owner to determine specific local code compliance prior to installation of the product. Jacuzzi Whirlpool Shower base makes no representation or warranty regarding, and will not be responsible for any code compliance.
-
Page 17: Steampro™ Warranty
Steam Generator Products Jacuzzi Whirlpool Bath, warrants that its Steam Generators (warranted products) are free of manufacturing defects both as to workmanship and material for 5 years and it will replace or repair defective parts or equipment for the period of time and in accordance with the conditions set forth below. - Page 18 Repair or replacement shall be the exclusive remedy available to the purchaser. Under no circumstances shall Jacuzzi Whirlpool Bath be liable by virtue of this warranty or otherwise for any special, indirect, secondary, incidental, or consequential damage of any nature to any person or property arising directly or indirectly out of the use or inability to use a warranted product.
-
Page 19: Base Warranty
NOTICE: This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. There are no warranties applicable to Jacuzzi Whirlpool Bath products except as expressly stated herein or as implied by applicable state and federal laws. The Company will not be responsible for any statements or representations made in any form that go beyond, are broader than or are inconsistent with any authorized literature or specifications furnished by the Company. - Page 20 The Company will provide the warranty service described above when the following conditions have been met: the failure is of the nature or type covered by the warranty; the user has informed an Authorized Jacuzzi Whirlpool Bath Service Agent or Warranty Service Department Representative of the nature of the problem during the warranty period;...
