DLP Based Projector
PT-D5700U
PT-D5700E
PT-D5700UL
PT-D5700EL
PT-DW5100U
PT-DW5100E
PT-DW5100UL
PT-DW5100EL
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO. VED0706378C0
D10
Unauthorized
copying
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-D5700U and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic PT-D5700U

Summary of Contents for Panasonic PT-D5700U

  • Page 1 All manuals and user guides at all-guides.com ORDER NO. VED0706378C0 DLP Based Projector PT-D5700U PT-D5700E PT-D5700UL PT-D5700EL PT-DW5100U PT-DW5100E PT-DW5100UL PT-DW5100EL © 2007 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying distribution is a violation of law.
  • Page 2 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL CONTENTS Page Page 1 Safety Precautions 11.6. Removal of R-P.C.Board 1.1. General Guidelines 11.7. Removal of S-P.C.Board 1.2. Leakage Current Check 11.8.

  • Page 4: Safety Precautions

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 1 Safety Precautions 1.1. General Guidelines · For continued safety, no modification of any circuit must be attempted.

  • Page 5: Specifications

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 2 Specifications...
  • Page 6 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...

  • Page 7: Function For Safety

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 3 Function for Safety 3.1. Interlock Switch To ensure safety, the protection circuit of the main unit functions, and this projector becomes operation halt condition (a part of circuit is energizing) when the lamp unit cover is removed or installed incorrectly.

  • Page 8: Resetting To User Mode

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Press the MENU button. Note: · "SERVICEMAN" will appear in a few seconds, then appear the MENU display as shown in right.

  • Page 9: Functions In Serviceman Mode

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Note: · "USER" will appear in a few seconds, then appear the MENU display as shown in right.
  • Page 10 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 2. SELF CHECK Displays SELF CHECK. 3. CW INDEX When the color wheel is replaced, adjusts it with buttons.
  • Page 11 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL e. Set the mean value (omission below decimal point) of "A" and "B" to the CW INDEX setting value.
  • Page 12 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 1. The left side is adjusted straight by KEYSTONE. 2. The right side is adjusted straight by SUB KEYSTONE.

  • Page 13: Using The Serial Terminals

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 3. HPLL When non-standard signal of VIDEO/S-VIDEO is inputted (VTR, VHD, etc.), horizontal synchronization might be disordered according to connected equipment. In this case, set HPLL to OFF.

  • Page 14: Procedure Of Communication Condition Settings

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 5.4. Procedure of Communication Condition Settings Press the MENU button. The MAIN MENU screen will be displayed. Press the buttons to select “OPTION2”.

  • Page 15: Cable Specifications

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 5.6. Cable specifications Note To connect the computer to the SERIAL terminal, prepare an adequate communication cable that fits to your personal...

  • Page 16: Using A Wired Remote Control

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 6 Using a Wired Remote Control 6.1. Connection Example When multiple main units are connected in the system, connect the units with the M3 stereo mini jack cable available in the market to simultaneously control the multiple main units with a single remote control unit through the REMOTE1 IN/OUT terminal.
  • Page 17 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Note: · Do not press the ID SET button accidentally or carelessly because the ID number on the remote control can be set even when no projector is around.

  • Page 18: Support For Service

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 7 Support for Service 7.1. Supporting Methods We will support according to the following methods. Supporting methods Applied parts Replaced by module or block FM-Module (For specified components, supplies them discretely.)

  • Page 19: Parts Location

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 9 Parts Location 9.1. Electrical Parts Location 9.2. Electromechanical Parts Location...

  • Page 20: Replacement Of Lamp Unit

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 10 Replacement of Lamp Unit 10.1. Before replacing the Lamp Unit WARNING! · When replacing the lamp, allow it to cool for at least one hour before handling it.

  • Page 21: Indication Of Lamp Monitor

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 10.3. Indication of Lamp Monitor...

  • Page 22: Disassembly Instructions

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 11 Disassembly Instructions 11.1. Flowchart for Disassembly To assemble, reverse the disassembly procedures.

  • Page 23: Removal Of Upper Case

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 11.2. Removal of Upper Case Unscrew the 8 screws and remove the top plate. Remove the filters (R, L). (Pull them horizontally out.) Unscrew the 1 screw and remove the lamp unit cover while sliding it horizontally.

  • Page 24: Removal Of J-P.c.board

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Unscrew the 5 screws and remove the A-P.C.Board block. Pull out the flexible cable connected to the J-P.C.Board. (The reverse side of A-P.C.Board)

  • Page 25: Removal Of R-P.c.board

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Unscrew the 3 screws and remove the power module. 11.6. Removal of R-P.C.Board Remove the upper case according to the section 11.2. "Removal of Upper Case".
  • Page 26 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Loosen the 2 screws until they idle and open the exhaust fan unit 1 and 2. Loosen each of 2 screws fixing the lamp units until they idle, remove the lamp units 1 and 2.
  • Page 27 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL (13) Unscrew the 2 screws and remove the ballast fan. (14) Disconnect the connectors to the ballast-1 and ballast-2 units.

  • Page 28: Removal Of Lamp Unit

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 11.9. Removal of Lamp Unit Unscrew the 1 screw fixing the lamp unit cover and slightly slide the cover horizontally and remove it.

  • Page 29: Removal Of Analysis Block

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 11.11. Removal of Analysis Block Remove the upper case according to the section 11.2. "Removal of Upper Case".

  • Page 30: Removal Of Synthesis Mirror

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Unscrew the 3 screws and remove the analysis block. 11.12. Removal of Synthesis Mirror Remove the upper case according to the section 11.2. "Removal of Upper Case".

  • Page 31: Removal Of Color Wheel Block (Analysis Block)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Unscrew the 3 screws and remove the synthesis mirror. Notes: · When the synthesis mirror is removed, be careful not to deform or damage the component (shading plate) of the rod (complete).

  • Page 32: Removal Of Rod (Complete)

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 11.14. Removal of Rod (complete) Remove the upper case according to the section 11.2. "Removal of Upper Case".

  • Page 33: Removal Of Full Reflection Mirror (Complete)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Disconnect connectors and flexible cable from/to the color wheel block. Unscrew the 1 screw and remove the color wheel block.

  • Page 34: Removal Of Dmd Block (Complete)

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Unscrew the 3 screws and remove the full reflection mirror (complete). 11.16. Removal of DMD Block (complete) Remove the projection lens according to the section 11.10.

  • Page 35: Removal Of Mechanical Shutter Unit

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 11.17. Removal of Mechanical Shutter Unit Remove the upper case according to the section 11.2. "Removal of Upper Case".

  • Page 36: Troubleshooting

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 12 Troubleshooting The alphabets (A, FM, etc.) in the left box of the inspection items indicate the names of P.C.Boards or modules to be checked.
  • Page 37 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...
  • Page 38 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...
  • Page 39 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...
  • Page 40 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...
  • Page 41 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...
  • Page 42 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...
  • Page 43 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...
  • Page 44 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...
  • Page 45 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...
  • Page 46 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...

  • Page 47: Interconnection Block Diagram

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 13 Interconnection Block Diagram 13.1. Interconnection Block Diagram (1/2) Interconnection Block Diagram (1/2) A-P.C.Board J-P.C.Board S-P.C.Board R-P.C.Board...

  • Page 48: Interconnection Block Diagram (2/2)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 13.2. Interconnection Block Diagram (2/2) Interconnection Block Diagram (2/2) A-P.C.Board E-P.C.Board P.C.Board FM-Module Power Module Ballast-1 Module Ballast-2 Module E-P.C.Board...

  • Page 49: Block Diagram

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 14 Block Diagram 14.1. Power Supply Power Supply Igniter Transformer Bridge Driver Current Voltage THERMOFUSE Control Detector Detector From A-P.C.Board A5...

  • Page 50: Signal Processing (1/2)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 14.2. Signal Processing (1/2) Signal Processing (1/2) 33SDA3 DVI-D X3000 IC3034 IC3035 IC3049 EDID EDID SDRAM GENERATOR IC3016...

  • Page 51: Signal Processing (2/2)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 14.3. Signal Processing (2/2) Signal Processing (2/2) CW MOTOR CW-P.C.Board A-P.C.Board FM-Module IC4004 IC4006 IC4203 CW INDEX FLASH...

  • Page 52: Fan/Motor Drive

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 14.4. Fan/Motor Drive Fan/Motor Drive MECHANICAL HIGH CONTRAST LENS SHIFT SHUTTER APERTURE ZOOM/FOCUS A-P.C.Board IC3635 IC3627 IC3636 IC3628...

  • Page 53: Schematic Diagram

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15 Schematic Diagram...

  • Page 54: A-P.c.board (1/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.1. A-P.C.Board (1/9) A-P.C.Board TXN/A2VKE9 (1/9)

  • Page 55: A-P.c.board (2/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.2. A-P.C.Board (2/9) A-P.C.Board TXN/A2VKE9 (2/9)

  • Page 56: A-P.c.board (3/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.3. A-P.C.Board (3/9) A-P.C.Board TXN/A2VKE9 (3/9)

  • Page 57: A-P.c.board (4/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.4. A-P.C.Board (4/9) A-P.C.Board TXN/A2VKE9 (4/9)

  • Page 58: A-P.c.board (5/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.5. A-P.C.Board (5/9) A-P.C.Board TXN/A2VKE9 (5/9)

  • Page 59: A-P.c.board (6/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.6. A-P.C.Board (6/9) A-P.C.Board TXN/A2VKE9 (6/9)

  • Page 60: A-P.c.board (7/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.7. A-P.C.Board (7/9) A-P.C.Board TXN/A2VKE9 (7/9)

  • Page 61: A-P.c.board (8/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.8. A-P.C.Board (8/9) A-P.C.Board TXN/A2VKE9 (8/9)

  • Page 62: A-P.c.board (9/9)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.9. A-P.C.Board (9/9) A-P.C.Board TXN/A2VKE9 (9/9)

  • Page 63: R/S-P.c.board

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.10. R/S-P.C.Board R-P.C.Board TXN/R1VKE9 S-P.C.Board TXN/S2VKE9...

  • Page 64: J-P.c.board

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 15.11. J-P.C.Board J-P.C.Board TXN/J1VKE9...

  • Page 65: Circuit Boards

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 16 Circuit Boards 16.1. A-P.C.Board (Foil Side) A-P.C.Board TXN/A2VKE9 (Foil Side) A-P.C.Board (Foil Side) IC2002 IC3006 IC3614 IC2006...

  • Page 66: A-P.c.board (Component Side)

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 16.2. A-P.C.Board (Component Side) A-P.C.Board TXN/A2VKE9 (Component Side) A-P.C.Board (Component Side) IC2001 IC2523 IC3017 IC2004 IC2524 IC3025 IC2008...

  • Page 67: J-P.c.board

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 16.3. J-P.C.Board J-P.C.Board TXN/J1VKE9 (Foil Side) J-P.C.Board TXN/J1VKE9 (Component Side) J-P.C.Board (Component Side) TRANSISTOR IC9801 Q9801 IC9803 Q9802...
  • Page 68 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...

  • Page 69: Terminal Guide Of Ics And Transistors

    All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL 17 Terminal guide of ICs and transistors...

  • Page 70: Exploded Views

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 18 Exploded Views...
  • Page 71 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...
  • Page 72 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com...
  • Page 73 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL...

  • Page 74: Replacement Parts List

    PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com 19 Replacement Parts List Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks...
  • Page 75 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TKZJ5056-2 VENTILATION FAN METAL...
  • Page 76 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TXJ/P7VKE9 LEAD WIRE (P7-FM2)
  • Page 77 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description Q3002 XP0460100L...
  • Page 78 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description L3041 J0JHC0000078...
  • Page 79 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R2028 ERJ6ENF51R0...
  • Page 80 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R2629 ERJ3GEYJ562 M 5.6KOHM,J,1/16W...
  • Page 81 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R3100 ERJ3GEYJ472 M 4.7KOHM,J,1/16W...
  • Page 82 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R3308 ERJ3GEYJ101...
  • Page 83 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R9967 ERJ3EKF2201...
  • Page 84 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C3025 ECJ1VB1H103K C 0.01UF, K, 50V...
  • Page 85 All manuals and user guides at all-guides.com PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C3238 F1G1C104A077...
  • Page 86 PT-D5700U / PT-D5700E / PT-D5700UL / PT-D5700EL / PT-DW5100U / PT-DW5100E / PT-DW5100UL / PT-DW5100EL All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C9821 ECJ1VF1C104Z C 0.1UF, Z, 16V...
  • Page 87 All manuals and user guides at all-guides.com...
  • Page 88 All manuals and user guides at all-guides.com...
  • Page 89 All manuals and user guides at all-guides.com...
  • Page 90 All manuals and user guides at all-guides.com...
  • Page 91 All manuals and user guides at all-guides.com...
  • Page 92 All manuals and user guides at all-guides.com...
  • Page 93 All manuals and user guides at all-guides.com...
  • Page 94 All manuals and user guides at all-guides.com...
  • Page 95 All manuals and user guides at all-guides.com...
  • Page 96 All manuals and user guides at all-guides.com...
  • Page 97 All manuals and user guides at all-guides.com...
  • Page 98 All manuals and user guides at all-guides.com...
  • Page 99 All manuals and user guides at all-guides.com...
  • Page 100 All manuals and user guides at all-guides.com...
  • Page 101 All manuals and user guides at all-guides.com...
  • Page 102 All manuals and user guides at all-guides.com...
  • Page 103 All manuals and user guides at all-guides.com...
  • Page 104 All manuals and user guides at all-guides.com...
  • Page 105 All manuals and user guides at all-guides.com...
  • Page 106 All manuals and user guides at all-guides.com...
  • Page 107 All manuals and user guides at all-guides.com...
  • Page 108 All manuals and user guides at all-guides.com...
  • Page 109 All manuals and user guides at all-guides.com...
  • Page 110 All manuals and user guides at all-guides.com...
  • Page 111 All manuals and user guides at all-guides.com...
  • Page 112 All manuals and user guides at all-guides.com...
  • Page 113 All manuals and user guides at all-guides.com...
  • Page 114 All manuals and user guides at all-guides.com...
  • Page 115 All manuals and user guides at all-guides.com...
  • Page 116 All manuals and user guides at all-guides.com...
  • Page 117 All manuals and user guides at all-guides.com...
  • Page 118 All manuals and user guides at all-guides.com...
  • Page 119 All manuals and user guides at all-guides.com...
  • Page 120 All manuals and user guides at all-guides.com...
  • Page 121 All manuals and user guides at all-guides.com...
  • Page 122 All manuals and user guides at all-guides.com...
  • Page 123 All manuals and user guides at all-guides.com...
  • Page 124 All manuals and user guides at all-guides.com...
  • Page 125 All manuals and user guides at all-guides.com...
  • Page 126 All manuals and user guides at all-guides.com...
  • Page 127 All manuals and user guides at all-guides.com...
  • Page 128 All manuals and user guides at all-guides.com...
  • Page 129 All manuals and user guides at all-guides.com...
  • Page 130 All manuals and user guides at all-guides.com...
  • Page 131 All manuals and user guides at all-guides.com...
  • Page 132 All manuals and user guides at all-guides.com...
  • Page 133 All manuals and user guides at all-guides.com...
  • Page 134 All manuals and user guides at all-guides.com...
  • Page 135 All manuals and user guides at all-guides.com...
  • Page 136 All manuals and user guides at all-guides.com...
  • Page 137 All manuals and user guides at all-guides.com...

This manual is also suitable for:

Pt-d5700ePt-d5700ulPt-d5700elPt-dw5100uPt-dw5100ePt-dw5100ul ... Show all

Table of Contents
