3. CONTROL ELEMENTS AND CONNECTIONS

The various control elements of your BCD2000 are described in this chapter. All controls and connections are explained in detail, and
there are several useful tips on their use.
Set the volume of the microphone signal with the MIC LEVEL
control.
The CLIP LED illuminates as soon as the microphone signal
level is too high and could possibly cause audible distortion.
If this happens, slightly turn the MIC LEVEL control counter-
clockwise.
The microphone input section has a 2-band equalizer
(EQ HIGH for high frequencies and EQ LOW for low
frequencies).
Use the TALKOVER button to activate the software’s talk-
over function. The talk-over function reduces the master
output signal and can come in handy when your own voice
needs to be prominently heard. When you want to make an
announcement, also press button
The ON AIR button routes the microphone signal to the
master output signal.
8

3.1 Control surface

Fig. 3.1: The BCD2000’s control elements
.
3. CONTROL ELEMENTS AND CONNECTIONS
These four controls as well as the buttons A to D
have various software functions assigned to them. By default they
are assigned to the two effects sections.
Use the ANALOG INPUT buttons
If the buttons are not pressed, the signals from decks A and B of
the software are played back. When you press a button, the analog
input signal will be added to the corresponding deck in the B-DJ
software. Deck A can play back the phono input A
microphone signal. Deck B plays back the signal applied at
input B (phono or CD). The input source for deck A is chosen in
the control panel (see chapter 2.3), while the input source for
deck B is selected on the rear panel (phono/line switch
The PHONES output (1/4" stereo connector) is used for
connecting headphones.
Use the PHONES control to adjust the volume for the
headphones output .
can
to select the input source.
or the
).
