B-CONTROL DEEJAY BCD2000
Fig. 2.2: The WDM/MME window in the BCD2000 control panel
Use the WDM/MME driver if your music software does not support
ASIO (e. g. most software media players).
allows you to select BCD2000 input or
for 2-channel recording.
When you choose IN A, you can determine in the left-hand field
whether the phono or microphone signal will be recorded.
PLAYBACK of this driver type is always stereo (channels 1-2).
For this reason, the MASTER OUT connectors on the rear panel
and the PHONES connector on the front panel always provide
the same music signal.
Fig. 2.3: The MIDI window in the BCD2000 control panel
On the MIDI page no parameters can be set. It only informs you
about the various MIDI modes, depending on the
selected:
In mode, the buttons are “toggle off”, i. e. when you release
a button after pressing, the MIDI command is set back to its
original value (like when you release a key on a keyboard).
In mode, all LEDs can be switched on and off individually
with specific MIDI commands.
In mode, all buttons are “toggle on”, i. e. press =
“switch on”; press again = “switch off” the MIDI function (similar
to a light switch).
In mode, the response of the button LEDs depends
on the respective button, i. e. LED on = “function enabled”, LED
off = “function disabled”.
2. INSTALLATION 7
