7. AUDIO CONNECTIONS

You will need a large number of cables for different applications.

The illustrations below show how the connectors should be wired.

Be sure to use only high-grade cables.

The microphone input of the BCD2000 is electronically balanced

to avoid hum problems.

Of course, you can also connect unbalanced microphones to the

balanced input. In this case, connect pin 1 and pin 3.

Fig. 7.1: XLR connector
