Big League Lawns CheckMate Installation Manual

Lawn striping kit for troy-bolt flex

1125 Mak Tech Dr C

Lansing, MI 48906

800.411.0150

www.bigleaguelawns.com

CheckMate™ Lawn Striping Kit For Troy-Bolt FLEX Installation Guide

Important

Big League Lawns, LLC warrants their products to be free of defects in material and workmanship.

This warranty does not cover defects due directly or indirectly to misuse, abuse, normal wear and tear,

failure to properly maintain the product or used for a purpose other than that for which it is intended.

The duration of this warranty is expressly limited to one year parts and labor beginning from the date

of delivery to the original customer.

The obligation of Big League Lawns, LLC is limited solely to the repair or replacement, at our option,

at its factory or authorized repair agent of any part that should prove deficient. Purchaser must

maintain the product under normal operating conditions at all times. Prior to operation, become

familiar with the attachment and any disconnect features. This product is not intended to be used in a

transport position or to be backed over curbs. When not in use, the product should be removed from

the mower and transported in a safe manner. Failure to follow these instructions will void the

warranty.

Table of Contents

Need help?

Do you have a question about the CheckMate and is the answer not in the manual?

Page 1 The obligation of Big League Lawns, LLC is limited solely to the repair or replacement, at our option, at its factory or authorized repair agent of any part that should prove deficient. Purchaser must maintain the product under normal operating conditions at all times.
Page 2 Congratulations on your new purchase! You are just steps away from creating a beautifully patterned lawn using your new CheckMate™ lawn striping roller. To ensure a long life of both your mower and roller, please be sure to follow the mounting recommendations below.
Page 3 Directions Remove red circled screw from machine. Replace with supplied 5/16" x 1" bolt with the threads pointing to the outside of the machine. Attach 5/16" to 3/8" coupling nut to the 5/16" bolt. Attach 3/8" Pivot bolt to the other side of the coupling nut. Refer to the coupling example below for further assistance.
