MUST not be disposed of in domestic waste. This humidifier should be returned to the closest steamOvap authorized representative for proper dismantling, recycling and disposition of components according to local regulations.
Risk of burnt, flooding or malfunction. Do not block steam outlet ! Risk of flooding. In order to avoid any risk of flooding steamOvap recommends a Hi limit humidity switch installed in the air duct downstream of the steam distribution ramp.
2. Verify that model of the humidifier matches the purchase order and that all accessories are included. 3. Any missing item should be reported as soon as possible to steamOvap or its representative and within 5 business days after receipt.
O V E R V I E W steamOres Overview Figure 1 – steamOres Overview steamOres product designation & name plate steamOvap technologies inc. Electric resistive steam humidifier RES120-15 MODEL YY-DDDXXX 1.5kW 120Vac POWER VOLTAGE 12.5A CURRENT NB OF PHASE...
Page 7
O V E R V I E W steamOres electrical rating section Steam Model Voltage Power Current Capacity 1.9lb/h RES120-06 0.6kW 5.2A (0.86kg/h) 2.4lb/h RES120-08 0.8kW 6.7A (1.09kg/h) 120Vac 1ph 3.4lb/h RES120-11 1.1kW 9.4A (1.5kg/h) 4.5lb/h RES120-15 1.5kW 12.5A (2.0kg/h) 5.6lb/h RES208-19 1.9kW...
Page 8
O V E R V I E W Figure 3 – steamOres dimensions Dimensions Qty Steam Model Outlet + Ø weight RES120-06 to 15 12in 18in 10in 1x 1-1/2in 22lb RES208-19 to 45 (30cm) (45cm) (25cm) (x1 DN40) (10kg) RES240-25 to 45...
section I N S T A L L A T I O N Installation overview General 1. Installation of this humidifier should be carried out by trained and qualified personnel. 2. Any work related to installation of this humidifier must comply with local code and regulation regarding safety and prevention of accidents.
Page 10
If local is subject to below freezing point temperature, activation of ant freezing function of the steamOres steam humidifier is required. For outdoor installation please contact your steamOvap representative to order and install special outdoor optional enclosure for RES. steamOres maximum ambient conditions: Temperature: 41 to 113°F [+5 to +45°C]...
Page 11
I N S T A L L A T I O N Clearances Left Right side side 24in Front Bottom 12in Figure 5 – minimum clearances Clearance guidelines There is no minimum clearance on both side of the steamOres humidifier, but it is a good practice to have a clearance of 6.8in [17cm] on left hand side and 4in [10cm] on right hand side of the humidifier to ease of installation and service.
Page 12
I N S T A L L A T I O N General guidelines for Mounting CAUTION. Risk of malfunction. steamOres steam humidifier must be levelled in X & Z axis. Installation on wall (with supplied mounting bracket) 1. steamOres is supplied with a wall mounting bracket 2.
Page 13
I N S T A L L A T I O N Installation – step 2 Water supply installation Water supply specification & quality: Water supply pressure: 15 to 80PSI [1 to 5bar] Water supply temperature: 37 to 105°F [3 to 40°C] RES electric steam humidifier can accept a wide range of water quality.
I N S T A L L A T I O N Installation – step 3 - Drain installation Water drained specification: Drained water maximum temperature: 140°F [60°C] (when supplied with cold water supply) Drained water flow rate: 2.6 GPM [10 L/min] Drain outlet dimension: 1in [DN25] Drain Outlet Diam.
I N S T A L L A T I O N Installation – step 4 - Steam distribution Duct humidification steamOres steam humidifier is supplied with 1m of steam hose and steam ramp. Standard steam ramp mounting bracket is designed for installation on rectangular ventilation duct (with flat surface).
Page 16
I N S T A L L A T I O N Verical duct Steam ramp (supplied) Slope 2°minimum steamOres humidifier Figure 11 – vertical rectangular duct Installation steps : 1. Position & mount the steam ramp to the ventilation duct wall by using metal screw 2.
Page 17
I N S T A L L A T I O N Installation – step 5 Power supply installation Electrical Warning Risk of electric shock. Any work related to power supply installation of this humidifier must comply with local code and regulation regarding safety and prevention of accidents.
Page 18
I N S T A L L A T I O N General guidelines for power supply installation Refer to the above current rated to determine the appropriate wire sizes as well as conduit size and fused disconnect requirements based on above electrical rating. The earth must be made by solid metal to metal connections.
Page 19
I N S T A L L A T I O N Installation – step 6 Control installation General guidelines for control installation It is a good practice to install the following safety controls: An air proving switch (APS) (supplied with steamOres) in the same duct as the humidifier’s steam ramp so that it will prevent humidifier from producing steam in case there is no air flow.
Page 20
I N S T A L L A T I O N steamOres humidifier is factory preset for external 0-10Vdc control signal. Control source and signal can be set through the modbus connection or by your local steamOvap representative when ordering.
Risk of flooding. In order to avoid any risk of flooding steamOvap recommends an air proving switch installation in ventilation duct; and a High limit humidistat in the duct downstream the steam ramp if air supply temperature is below 68°F [20°C].
It does not require any configuration on the field unless you want a non-standard configuration. In case a non standard configuration is required, contact your local steamOvap representative for assistance.
Page 23
O P E R A T I O N & S E R V I C E Control configuration Touch pad control allows you to change the mode of control for the humidifier. Push on the ‘’settings mode’’ button on the touch pad controls – When steamOres is in setting mode the blue LED located beside this button will turn ON.
Page 24
O P E R A T I O N & S E R V I C E section Multicolor status LED: Normal operation LED color and state steamOres state Description SteamOres is disabled White (full ON) Stand by (On/Off button is Off) SteamOres is ready to produce steam Lime/green (full ON) Ready...
O P E R A T I O N & S E R V I C E Service Risk of burnt, flooding or malfunction. Make sure that cylinder is empty from water before to open the release latch. Risk of electric shock. Disconnect power supply before to service.
Page 26
O P E R A T I O N & S E R V I C E 6. If temperature is Ok and that there is no water in hose, you can open the fill & drain hose connector located below the cylinder, to do so: ◦...
90 days, whichever is longer. No liability whatsoever shall be attached to steamOvap until said products have been paid for in full and then said liability shall be limited to the original purchase price for the product. Any further warranty must be in writing, signed by an officer of steamOvap.
Page 29
2022 steamOvap technologies inc. 1490 Mazurette Montreal, Qc, H4N 1H2 Canada Tel.: +1-844-357-4477 info@steamOvap.com www.steamOvap.com Information contained in this manual is subject to change without notice. To obtain the latest technical information visit our website at www.steamOvap.com...
