Controls

Control Panel
2
1
1
Start Button
2
Cancel Button
3
Oven Light Button
4
Settings Button
5
Convection Fan Button
Control Display
A
Temperature Display
Displays the selected oven temperature or number of
slices.
B
Time Display
Displays the cook time remaining or selected shade level.
C
Cooking Mode Display
Displays the selected cooking mode.
D
Convection Indicator
Illuminates when convection fan is active.
E
WiFi Indicator
Illuminates when the appliance is connected to a WiFi
network.
F
Remote Enable Indicator
Illuminates when Remote Enable setting has been
activated.
3
4
A
C
L
E
F G H
7
6
Crisp Finish Button
7
Control Display
8
Cook Mode Knob
9
Cooking Settings Knob
I
G
Oven Light Indicator
Illuminates when the Oven light is turned on.
H
Control Lock Indicator
Illuminates when the Control Lock feature is activated.
I
Preheating Indicator
Illuminates when oven is preheating to selected
temperature.
J
Press Start Reminder
Illuminates to prompt user to start oven cooking cycle.
K
Crisp Finish Indicator
Illuminates when oven is in Crisp Finish mode.
L
Progress Bar
Shows progress of the current cooking cycle.
9
8 9
5
6
B
D
K
J
