Machine description – quick overview
Front view / side view from the right
Item Symbol
1
2
3
4
5
6
7
8
9
10
11
12
16
Description 0
Carrying handle
Protective cap, welding machine control > see 5.2.3 chapter
Welding torch connection (Euro or Dinse torch connector)
Welding current, shielding gas and torch trigger integrated
Turning mandrel support
The wire feeder is placed onto the power source turning mandrel using this support to
enable horizontal pivoting of the machine.
Sliding rails
Intermediate hose package strain relief > see 5.2 chapter
Slide latch, lock for the protective cap
Welding current connection socket (depending on variant)
Welding current potential of the torch connector for MMA welding or gouging
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
Quick connect coupling (red)
coolant return
Quick connect coupling (blue)
coolant supply
Machine control (see the relevant control operating instructions)
