OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions carefully. This
will simplify installation and ensure that the product is installed
correctly and safely. Leave these instructions near the product after
installation for future reference.
EN ENGLISH
FH4G1JCHK(0-9)N
MFL69962058
Rev.00_120717
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Related Manuals for LG FH4G1JCHK Series
Summary of Contents for LG FH4G1JCHK Series
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. EN ENGLISH FH4G1JCHK(0-9)N www.lg.com MFL69962058 Copyright © 2017 LG Electronics Inc. All Rights Reserved. Rev.00_120717...
-
Page 2: Installation
INSTALLATION Parts Transit bolts Power plug Drawer Control panel Drum Door Drain hose Drain plug Drain pump filter Cover cap (Location may vary depending on products) Adjustable feet Power button Accessories Cold supply hose (1 EA) Spanner Caps for covering Anti–slip sheets (2 EA) (Option: Hot (1 EA)) transit bolt holes... -
Page 3: Installation Place Requirements
Installation Place • If it is impossible to avoid positioning the appliance next to a gas cooker or coal burning Requirements stove, an insulation (85x60 cm) covered with aluminum foil on the side facing the cooker Location or stove must be inserted between the two appliances. -
Page 4: Unpacking And Removing Transit Bolts
Unpacking and Removing Install the hole caps. Transit Bolts • Locate the hole caps included in the accessory pack or attached on the back. Lift the appliance off the foam base. • After removing the carton and shipping material, lift the appliance off the foam base. -
Page 5: Using Anti-Slip Sheets (Optional)
• Push or rock the top edges of the appliance gently to make sure that the appliance does not rock. If the appliance rocks, level the appliance again. NOTE • You can obtain anti-slip sheets from the LG Service Centre. -
Page 6: Leveling The Appliance
Leveling the Appliance Connecting the Water Supply Hose If the floor is uneven, turn the adjustable feet as required (Do not insert pieces of wood etc. under • Water pressure must be between 0.1 MPa and the feet). Make sure that all four feet are stable 1.0 MPa (1.0‒10.0 kgf/cm and resting on the floor and then check that the •...
