EWT G20 Owner's Manual page 26

SERVICE THE EWT G20 CONTROL VALVE
Before Servicing
1. Turn off water supply to conditioner using the bypass tool attached on the bypass.
Bypass Tool
2. Relieve water pressure in the conditioner by stepping the control into the backwash position
momentarily. Return the control to the In Service position.
3. Unplug electrical cord from outlet.
4.Re move the cove r assy
a n d di s c o n n e c t th e w i r e
connection.
Meter Cable
Meter Tube
Communication
wire conncetions
5.Remove the brine tube,
drain tube, meter cable and
meter tube.
7. Disconnect the softener
from the bypass.
Close the inlet
and outlet
Drain Tube
Brine Tube
6. Remove the clips that
connect control valve and bypass.
8. Remove the valve
from the softener.
2×Clips
2×Screws
