- Page 1 Owner’s Manual Wearable Air Purifier Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH AP551A Series www.lg.com MFL71829810 Rev.00_011322 Copyright © 2022 LG Electronics Inc. All rights reserved.
-
Page 2: Table Of Contents
MAINTENANCE Replacing the PuriCare Filter and Inner Cover ........16 Cleaning the Product ................. 17 USING THE SMART FUNCTION Using the LG PuriCare Wearable Air Purifier App ......20 TROUBLESHOOTING Before Calling for Service ..............22 APPENDIX Product Specifications ............... 24 Open Source Software Notice Information ........ -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user mainte- nance shall not be made by children without supervision. Operation • This product is an Air Purifier that protects the respiratory organs from harmful particulate substances such as fine dust. Do not use this product for other purposes. • This product is a wearable air purifier, not a standard mask. Check for rele- vant regulations before using on air or sea transport vehicles (planes, ships). • If you experience dizziness, headache, dry skin, or any skin problems, stop using the product immediately and consult a doctor before reusing it. • Since a person taking a drug for the respiratory system may experience in- creased sensitivity of the respiratory system, he/she should consult a doctor before using the product. • Do not use the product in a poorly ventilated area where oxygen is not continually supplied. • Do not use the product without a filter in an area with airborne dust, salt, or sulfur particulates. • To avoid the risk of infection, do not share the product with other users or transfer use to another person. • Do not use disinfectant or sanitizer on the product. • Do not exercise strenuously while wearing the product. • Prevent the penetration of foreign substances, water, or beverages into the product or suction fan. If foreign substances such as dust or fungi accumu- late on the suction fan, stop using the product and contact an LG Electronics Customer Information Center.
- Page 5 • Do not insert a body part, such as a finger, into the product while the suction fan is operating. • Do not disassemble or damage the product, battery or parts. Do not use the product if the product, battery or any part has been damaged. • If you detect any strange sound, smell, or smoke from the product or suction fan, stop using the product and contact the an LG Electronics Customer Information Center. • The appliance must only be supplied at safety extra low voltage correspond- ing to the marking on the appliance. Maintenance • Do not place the product near a car window where it is exposed to direct sunlight or on top of an electric pad or heater. • Do not store or use the product in temperatures above 50 °C or below -20°C. Charging • Do not drop the charging adapter into a tub or sink. Do not place or store it in an area where it can fall into water or other liquids. If the charging adapter or cable falls into water, stop using the product and pull out the charging adapter immediately. • Make sure that the charging cable is not pressed or bent by a heavy object or damaged by pets. Battery • This product uses an integrated battery. Do not separate or replace the battery. If the battery is faulty, be sure to contact the LG Electronics Customer Informa- tion Center to replace the product and charging accessories. • Do not dispose of the battery in a fire. • If the battery leaks fluid or gives off an odor, stop using it and contact the LG Electronics Customer Information Center.
-
Page 6: Caution
• Do not turn the product by holding the ear strap. • Do not step on or exert strong pressure on the product. • Use only LG Electronics approved accessories. Using unapproved accesso- ries may cause performance problems and malfunctions that are not covered by the warranty. -
Page 7: Unpacking
UNPACKING Components Main unit Face guard PuriCare Filters Inner cover Charging cable (2 filters) (15 filters) Strap Extender Portable pouch Plastic Pack Owner’s manual/ Warranty card... -
Page 8: Appliance Overview
Appliance Overview Front View Ear strap Speaker Rear View Inside the Inner cover Respiratory sensor and Mic Exhaust unit Face guard PuriCare filter Filter case Suction fan Inner cover... - Page 9 Control and Status Display Panel Bluetooth indicator light • LED turns on when paired with a Bluetooth device. Power button • Start and stop operation: Press Power for at least 2 seconds. • Use voice unit: Press Power while product is turned on. • Activate Bluetooth: Press Power for at least 7 seconds. • Turn product completely off: Press Power for at least 10 seconds. Turn product completely off if storing for more than 6 months. Battery indicator light • When the charging cable is connected, the charging status is displayed. • When the product is turned on, the remaining battery level is displayed. Charging unit...
-
Page 10: Assembly
ASSEMBLY Installing the PuriCare Filters Hold the groove marked in the figure and open the filter case. Push the filter into the opened filter case. To close the case, push the filter case inward until it clicks into place. PuriCare filter NOTE • As long as you replace the PuriCare filters regularly according to the re- placement schedule, the direction of the PuriCare filters does not affect their... -
Page 11: Installing The Inner Cover And Face Guard
Installing the Inner Cover and Face Guard Secure the bottom of the inner cover by sliding the holes over the low- er guide tabs inside the main unit. Arrange the top of the inner cover to fit within the upper guide tabs as shown. Guide tab Hole Attach the metal prongs on the back of the face guard to the magnets on the inside surface of the main unit. -
Page 12: Charging
CHARGING Charging the Battery This product has a built-in battery. Charge the battery fully before using the product by connecting the provided charging cable to an AC adapter (not included). The adapter is sold separately • To begin charging, connect the charging cable to the AC adapter, plug the adapt- er in, and connect the cable to the product. - Page 13 CAUTION • The appliance must only be supplied at safety extra low voltage corresponding to the marking on the appliance from an AC adapter (5 V, 1.8 A or higher). The AC adapter must be purchased separately. Using an unapproved charger may cause failure or variation in the charging time.
-
Page 14: Operation
If you find the ear straps uncomfortable, use the strap extender to reduce he tension around your ears. • Attach the strap extender so that the LG PuriCare logo and the hooks face out. • Adjust the ear straps as needed to keep the product comfortably in place. -
Page 15: Starting Operation
Power button Starting Operation Press and hold the power button for at least 2 seconds to turn the product on. • The product adjusts the inhaling intensity according to the user’s breathing. • To turn the product off, press and hold the power button for at least 2 seconds. • The product beeps once when it is turned off or on. -
Page 16: Maintenance
• The filter and inner cover replacement period may vary depending on the operat- ing environment. • To purchase replacement face guards, strap extenders, ear straps, PuriCare fil- ters, inner covers, or cover bands, call an LG Electronics Customer Information Center or visit the LG Electronics website at www.lg.com. -
Page 17: Cleaning The Product
Cleaning the Product Cleaning the Face Guard Pull the lower section of the face guard to separate it from the product. After removing the face guard from the product, clean it with clean water. • If the surface is very dirty, clean it with a neutral detergent. Dry the face guard completely after cleaning and reassemble it on the product. - Page 18 Cleaning the Exhaust Unit Wipe the exhaust unit with a cotton swab soaked with water or alcohol and then wipe it dry using a dry cotton swab. NOTE • For best results, clean the exhaust unit after each use. Cleaning the Product Surface Use a soft, damp cloth to wipe the surface of the product clean.
- Page 19 Cleaning the Ear Straps Fold the ear straps and ear strap hooks toward the inside of the product. Lift one side of the ear strap hook up to separate the ear strap. Wash the separated ear strap in water and a mild detergent. Allow the ear straps to dry completely before reassembling.
-
Page 20: Using The Smart Function
Using the LG PuriCare Wearable Air Purifier App Installing the LG PuriCare Wearable Air Purifier App Search for the LG PuriCare Wearable app in the Google Play or Apple App Store and install it on your smart device. Refer to the application’s Help page for more detailed instructions. - Page 21 • The Bluetooth indicator light on the product shows the status of the Bluetooth connection. The indicator light turns on when Bluetooth is connected. • Android 5.0 or higher, iOS 11.0 or higher is recommended for the LG PuriCare Wearable Air Purifier app.
-
Page 22: Troubleshooting
TROUBLESHOOTING Before Calling for Service If a failure occurs in the product, check the following before contacting an LG Elec- tronics Customer Information Center for service. Symptoms Causes and solutions • The battery is discharged. See Charging the Battery. The appliance does not operate. - Page 23 Symptoms Causes and solutions • Restart the smart device’s Bluetooth feature and try again. • Check if the smart device’s Bluetooth is enabled. • The connection may not be optimal if there is an obstacle or a person between the product and the smart device or if there are other nearby devices such as medical equipment, microwave ovens, or Trouble pairing the...
-
Page 24: Appendix
APPENDIX Product Specifications Appearance and specifications may vary without notice in order to improve the quality of this product. Product 1.8 A (AC adapter) Power Built-in rechargeable battery Power Input 2.0 W Dimensions (W*D*H) 142 mm x 52 mm x 109 mm Recommended operating -20 °C ~ 50 °C temperature range... -
Page 25: Open Source Software Notice Information
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, ship- ping, and handling) upon email request to opensource@lge.com. -
Page 26: Disposal Of Your Old Appliance (As Per E-Waste Rules)
Toll Free No. 1800-315-9999 / 1800-180-9999 for details. All col- lection centre and pick up facilities are done by third parties with LG Electronics India Pvt. Ltd. Merely as a facilitator. For more detailed information , please visit : http://www.lge.com/in... -
Page 27: अपने पु र ाने निपटान के उपकरण (ई-अपशिष् ट नियम के अनु स ार)
315-9999 / 1800-180-9999 पर कॉल करे ं . सभी सं ग ् र हण के ं द ् र व पिक-अप की सु व िधाएं किसी थर् ड - पार् ट ी जो “LG Electronics India Pvt. Ltd. “को अपनी से व ाएं प् र दान कर रही हों , से करवाएं ।... -
Page 28: Warranty
WARRANTY The LG Air Purifier comes with 12 months warranty from the date of purchase of the product, provided always that the warranty card bears the rubber stamp, date and signature of our Authorized Dealer. Terms & Condition The warranty is confined to the first purchaser of the Wearable Air Purifier only &... - Page 29 The 12 months warranty is applicable on the product only, except the re- placeable filter. This warranty shall not cover any consequential or resulting liability, damage or loss to property or life arising directly or indirectly out of any defect in the Wearable Air Purifier.The company’s obligation under this warranty shall be limited to repair or providing replacement of defective parts only under the warranty period.
- Page 30 This Warranty is not applicable in any of the following cases: The warranty card is not completed properly at the time of purchase. The completed warranty card is not presented to authorized service personnel at the time of service of the product. The product is not operated according to instructions given in the Operating Instruction Booklet.
- Page 31 Customer’s Copy Name of Purchaser : Invoice No. and Date : Model : Sr.No.Unit : Name & Address of the Seller (LG & Authorized Dealer) : Customer’s Copy Name of Purchaser : Invoice No. and Date : Model : Sr.No.Unit :...
