BIXOLON XT3-40 Series User Manual

BIXOLON XT3-40 Series User Manual

Industrial label printer
Hide thumbs Also See for XT3-40 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
XT3-40 Series
Industrial Label Printer
Ver. 1.00
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT3-40 Series and is the answer not in the manual?

Questions and answers

Related Manuals for BIXOLON XT3-40 Series

Summary of Contents for BIXOLON XT3-40 Series

  • Page 1 User’s Manual XT3-40 Series Industrial Label Printer Ver. 1.00 http://www.bixolon.com...

  • Page 2: Table Of Contents

    XT3-40 Series Table of Contents Copyright ..........................4 WARNING & CAUTION ....................... 8 Manual Introduction ....................... 10 Printer Introduction ......................11 1. Content Confirmation ....................12 2. Product Part Names ....................13 2-1 Printer Part Names ......................13 2-2 Major Control Part Names ....................17 2-2-1 Control Panel ......................
  • Page 3 XT3-40 Series 4-7 Files Menu Explanation ....................65 4-7-1 Saved File ........................65 4-7-2 Twin Function ......................66 4-7-3 Firmware Update ....................... 71 4-8 Tools Menu Explanation ....................72 4-9 Info Menu Explanation ....................74 5. Detailed Features ......................75 5-1 Pause/Cancel ........................

  • Page 4: Copyright

    It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product.
  • Page 5 XT3-40 Series Warning Hazardous moving parts Keep fingers and other body parts away Pull the print head lever can be stop all moving parts. IEC 60417-6057 (2011-05) for other moving parts. Mise en garde Les appareils électroniques, tels que les imprimantes, risquent d'être endommagés par l'électricité...
  • Page 6 XT3-40 Series Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 7 XT3-40 Series Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

  • Page 8: Warning & Caution

    Do not connect multiple products to one Use only authentic products from single power outlet. Do not connect the BIXOLON. The company will not provide product to a loose power outlet. post-sale support for damage or other Use only power outlets that meet the quality issues that any fake standard.
  • Page 9 If there is a problem with the enter the product. Do not place heavy product, please contact the place of objects, liquids, or metals on the purchase. In addition, Bixolon product. It may start a fire. website (http://www.bixolon.com) It may damage the product.

  • Page 10: Manual Introduction

    XT3-40 Series Manual Introduction This manual provides basic information on printers and provides ways to install, use, and check them. In order to protect the safety of users and prevent property damage, be fully familiar with this manual before using the product. Please use it.

  • Page 11: Printer Introduction

    XT3-40 Series Printer Introduction XT3-40 series printers have been designed to be connected to various types of electronic devices such as computer peripheral devices. The main features of the printer are as follows 1. Industrial Label Printer 2. Thermal Transfer / Direct Thermal Printing 3.

  • Page 12: Content Confirmation

    XT3-40 Series 1. Content Confirmation The following items should all be contained in the printer package. Contact the dealer from which the purchase was made if any item is damaged and/or missing. Product Basic Components Power Cord Quick Manual Option Components...

  • Page 13: Product Part Names

    XT3-40 Series 2. Product Part Names 2-1 Printer Part Names Front Control Panel Media Cover Ver. 1.00 - 13 -...
  • Page 14 XT3-40 Series Back Ethernet Port Rear Access Slot(Media) USB Port Power Connector USB Host Port Power Switch Serial(RS-232C) Port Ver. 1.00 - 14 -...
  • Page 15 XT3-40 Series Internal Printer Head Pressure Ribbon Take-up Spindle Adjustment Cover STD Ribbon Supply Spindle Printer Head Lever Media Holder Rear Media Guide Media Fixing Guide Ribbon Sensor Front Media Guide Platen Roller Black Mark Sensor (Green LED) Printer Head Gap &...
  • Page 16 XT3-40 Series Printer Option Auto Cutter Peeler Peeler + Rewinder Ver. 1.00 - 16 -...

  • Page 17: Major Control Part Names

    XT3-40 Series 2-2 Major Control Part Names 2-2-1 Control Panel Description Printer status LED Interface status icon Date, Time Model name Firmware version Printer status Main icon Ethernet IP, WLAN IP Function button Direction button, Selection button Printer operation button Ver.

  • Page 18: Detailed Descriptions

    XT3-40 Series 2-2-2 Detailed Descriptions 2-2-2-1 Printer Status LED List Status Explanation Printer power on Printer power off Waiting for data reception BLINK Receiving data BLINK Print error In normal operation 2-2-2-2 Interface Status Icon List Status Explanation Ethernet is connected...
  • Page 19 XT3-40 Series 2-2-2-4 Model Name List Explanation XT3-40 Model name 2-2-2-5 Firmware Version List Explanation V01.00 Firmware version 2-2-2-6 Printer Status List Explanation READY Ready for print Standing by for user input button: Switch to Print Standby Mode without feeding any...
  • Page 20 XT3-40 Series 2-2-2-7 Main Icons List Explanation Printer settings Interface settings Sensor settings File settings Additional and other functions settings Providing printer information 2-2-2-8 Ethernet IP, WLAN IP List Explanation LAN: 192.168.100.123 Ethernet IP WLAN IP WLAN: 192.168.100.123 (displayed only when WLAN is supported)
  • Page 21 XT3-40 Series 2-2-2-11 Printer Operation Button List Explanation Softly press and release the button to feed one label Press the button for 2 seconds during printing to pause printing Press the button for 2 seconds during printing to cancel printing Ver.

  • Page 22: Installation & Usage

    XT3-40 Series 3. Installation & Usage 3-1 Printer Installation Placings • Install the printer in a location that meets the following conditions. - Allow sufficient space around the printer for proper ventilation. - Do not place objects close to the back or bottom of the printer, which may hinder the air circulation.

  • Page 23: Power Connection

    XT3-40 Series 3-2 Power Connection • Connect power to the printer as shown below. Power Switch Power Cord 1) Turn off the printer power switch. 2) Connect the power cord to the printer. 3) Connect the power cord to a power source/outlet.

  • Page 24: Interface

    XT3-40 Series 3-3 Interface Shielded cables must be used to prevent radiation and reception of electrical noise. Use the shortest possible communication cable to minimize the detection of electrical noise in the cable. - Serial(RS-232C) Cable (1.8m or less recommended) - Parallel(IEEE1284) Cable (1.8m or less with ferrite core recommended)

  • Page 25: Standard Interface

    XT3-40 Series 3-3-1 Standard Interface This printer can use the following types of communication. - LAN (Ethernet) Cable / USB B-Type & USB A-Type Cable / Serial (RS-232C) Cable LAN(Ethernet) Cable USB B-Type Cable USB A-Type Cable Serial (RS-232C) Cable 1) Turn off the power switch.

  • Page 26: Option Interface

    XT3-40 Series 3-3-2 Option Interface This printer can use the following types of communication. - LAN (Ethernet) Cable / USB B-Type & USB A-Type Cable / Serial (RS-232C) Cable - WLAN / Bluetooth / Parallel(IEEE1284) Cable WLAN or Bluetooth LAN(Ethernet) Cable...

  • Page 27: Media Installation

    XT3-40 Series 3-4 Media Installation 3-4-1 Media Installation Method of Standard Model For standard models, install media in the following ways: 1) Open the media cover. 2) Open the printer head lever. Flip down the media fixing guide and place the media in the media holder with print side up.
  • Page 28 XT3-40 Series 3) After flip up the media fixing guide, push the holder so that it is close to the media. Push the front and rear media guides to the right. - Push rear media guide by hand to move it...
  • Page 29 XT3-40 Series 5) Please make sure the sensor position where media gap/black mark will pass through for sensing. Sensor (gap & notch sensor, black mark sensor) can be moved by the sensor lever. Check the sensor position with LED color.

  • Page 30: Media Installation Method Of Auto Cutter (Optional) Model

    XT3-40 Series 3-4-2 Media Installation Method of Auto Cutter (optional) Model Use the autocutter to cut the printed media. For Auto Cutter Model, install media in the following ways: 1) Refer to '3-4-1 Media Installation Method of Standard Model' to install media, adjust media guide and sensor position.

  • Page 31: Media Installation Method Of Peeler (Optional) Model

    XT3-40 Series 3-4-3 Media Installation Method of Peeler (Optional) Model Use a peeler to automatically separate the printed media from the liner. For Peeler (Optional) Model, install media in the following ways: 1) Refer to '3-4-1 Media Installation Method of Standard Model' to install media, adjust media guide and sensor position.
  • Page 32 XT3-40 Series 4) Remove several sheets of label media and insert liner as in the picture. 5) Close the peeler cover until it clicks. Peeler Sensor Be careful that the media does not cover the peeler sensor Ver. 1.00 - 32 -...
  • Page 33 XT3-40 Series 6) Close the print head lever, the rewinder cover, and the media cover. - When opening or closing the cover, be careful not to pinch your fingers. - Do not open the print head levers while the printer is printing.

  • Page 34: Media Installation(Remove) Method Of Rewinder(Optional-Liner Take-Up Only) Model

    XT3-40 Series 3-4-4 Media Installation(Remove) Method of Rewinder(optional-Liner Take-up only) Model Use the rewinder to automatically separate the printed media from the liner and rewind the printed media. For rewinder model, install media in the following ways: 〮 Media Installation Method 1) Refer to '3-4-1 Media Installation Method of Standard Model' to install media, adjust media guide and sensor position.
  • Page 35 XT3-40 Series 3) Press the left and right peeler levers to open the peeler cover. Peeler Cover Peeler Lever 4) Move the peeler switch to ON. Please make sure that the LED has turned on. Peeler Switch 5) Remove several sheets of label media and insert liner as in the picture.
  • Page 36 XT3-40 Series 6) After installing the media in the same way as the picture, fix the media on rewinder media guide. Insert Media Rewinder Media Guide 7) Close the peeler cover until it clicks. Be careful that the media does not cover the...
  • Page 37 XT3-40 Series 〮 Media Liner Removal Method 1) Open the peeler cover, the media cover, the rewinder cover and the print head lever. 2) Rotate the rewinder holder counter-clockwise to wind the media liner. Rewinder Holder Ver. 1.00 - 37 -...
  • Page 38 XT3-40 Series 3) Pull the Rewinder Holder Handle and remove installed media liner. Rewinder Holder Handle When removing the media, please work to avoid damaging the surrounding parts. - When opening or closing the cover, be careful not to pinch your fingers.

  • Page 39: How To Install Media Externally

    XT3-40 Series 3-4-5 How To Install Media Externally Install media from outside the printer as follows. 1) Insert the media through the rear access slot of the printer. Insert media 2) Adjust the media fixing guide to the media width.

  • Page 40: Ribbon Installation

    XT3-40 Series 3-5 Ribbon Installation 3-5-1 Ribbon Type 1) Type by film coating position - This printer can be used with both Outside and Inside Ribbon. Coated side (print side) Coated side (print side) Outside Ribbon Inside Ribbon Perform an adhesion test to determine which side of the ribbon is coated.

  • Page 41: Ribbon Installation Method

    XT3-40 Series 3-5-2 Ribbon Installation Method Install ribbon as follows. 1) Insert the ribbon core into the ribbon 2) Open the print head lever and install the take-up spindle and insert the ribbon into ribbon as shown below. the ribbon supply spindle.

  • Page 42: Load Adjustment By Ribbon Length

    XT3-40 Series 3-5-3 Load Adjustment by Ribbon Length The printer can use all 1 to 4 inch wide ribbons. Adjust the ribbon supply spindle load according to the ribbon width. 1) When using ribbon of 3 inch or 4 inch width, pull in the direction of UP marked on the...

  • Page 43: Ribbon Remove Method

    XT3-40 Series 3-5-4 Ribbon Remove Method Remove the ribbons as follows. 1) Open the print head lever. 2) Cut the Ribbon and pull the Ribbon Take-up spindle. Ribbon Take-up Spindle Remove the ribbon and ribbon core to outside. Ribbon Core Clip - Don’t remove the ribbon and ribbon core while the printer is...

  • Page 44: Printer Head Load Control Method

    XT3-40 Series 3-6 Printer Head Load Control Method • Adjust the print head load by turning the left and right knobs depending on the media width and thickness. The left and right knobs are set to level 3 when shipped from the factory.

  • Page 45: Ribbon Guide Control Method

    XT3-40 Series 3-7 Ribbon Guide Control Method • Wrinkles can be improved by adjusting A and B on the ribbon guides. 1) How to adjust ribbon guide A - Slightly loosen or fasten the screw attached to the ribbon guide B using a cross-tip screwdriver to adjust it forward and backward.
  • Page 46 XT3-40 Series 2) How to adjust ribbon guide B - Slightly loosen the screws fastened to the ribbon guide A using a cross-tip screwdriver to adjust it up and down. Media Printing Status Adjustment Method Screw Wrinkles on the Right 1) Lower the right side of the ribbon guide B.

  • Page 47: Setting

    XT3-40 Series 4. Setting 4-1 Menu Composition Explanation Print Width Print Length Print Direction Print Speed Print Density Print Method Media Type Tear Off Print Offset Left Position Print Mode Power Up Action Print Head Close Explanation Baud Rate Data Bits...
  • Page 48 XT3-40 Series Device Name Pincode Pairing SSP (Secure Simple Pairing) MAC Address Bluetooth Bluetooth Low Energy Connect Mode Mode Auth&Enc Standard Mode (Authentication & Encryption) Interface Info Explanation Gap Calibration Black Mark Calibration Sensor Sensitivity Explanation Template Image Saved File...
  • Page 49 XT3-40 Series Password Enable Security Password Setting Demo Print Explanation Printer Info Media Installation Media Installation (Peel Off) Media Installation (Rewinder) Ribbon Installation Installation & Peel off Installation Usage Auto Cutter Installation Replace Media Replace Ribbon Replace Print Head Troubleshooting Contact US Ver.

  • Page 50: Menu Select Method

    XT3-40 Series 4-2 Menu Select Method This is print ready status LCD output screen. Press function button, direction button or OK button. The setting menu is selected. Use direction buttons to move to the desired menu. Ver. 1.00 - 50 -...
  • Page 51 XT3-40 Series Press OK or the right function button to enter the sub menu. If there are no input for 5 seconds, it returns to main screen Ver. 1.00 - 51 -...

  • Page 52: Setting Confirm Method

    XT3-40 Series 4-3 Setting Confirm Method 1) How to use the up and down buttons (1) Select the desired setting value using button (2) After selecting the setting value, save it with button (3) If you want to exit the menu without setting,...
  • Page 53 XT3-40 Series 3) How to input characters (1) Select the desired input value using button (2) Enter the desired value using button (3) With , you can delete the input value (4) With , you can move the cursor (5) With...

  • Page 54: Setting Menu Explanation

    XT3-40 Series 4-4 Setting Menu Explanation List Explanation Explanation Setting media width[dots] Function to adjust image buffer size according to print width Default Value Print Width 203dpi: 864dots 300dpi: 1248dots Maximum Value 203dpi: 864dots 300dpi: 1248dots Explanation Setting media length[dots]...
  • Page 55 XT3-40 Series Explanation Setting printing direction Top to bottom: Printing from top to bottom Bottom to Top: Printing from bottom to top Default Value Bottom to Top Variable Value Bottom to Top, Top to Bottom Print Direction Printing Direction Top to bottom...
  • Page 56 XT3-40 Series Explanation Setting print method Default Value Print Method Transfer Variable Value Transfer, Direct Explanation Setting media type Default Value Media Type Variable Value Gap, Black Mark, Continuous Explanation Setting media position[dots] for tear off after printing or feed...
  • Page 57 XT3-40 Series Tear Off Variable Value Tear Off, Auto Cutter, Rewinder Explanation Setting the action for the printer after the power-up sequence. Default Value Power Up Action No Feed Variable Value No Feed, Set Label Length, Media Calibration, Feed Explanation...

  • Page 58: Interface Menu Explanation

    XT3-40 Series 4-5 Interface Menu Explanation 4-5-1 Serial List Explanation Explanation Setting the baud rate Default Value Baud Rate 115200 Variable Value 9600,19200,38400,57600,115200 Explanation Setting the data bit Default Value Data Bits Variable Value 7, 8 Explanation Setting the parity...

  • Page 59: Ethernet

    XT3-40 Series 4-5-2 Ethernet List Explanation Explanation Setting IP assignment method Default Value IP Protocol DHCP Variable Value DHCP, Static IP Explanation Setting IP Address method Default Value IP Address Static IP: 192.168.192.123 DHCP: 0.0.0.0 Variable Value 0 ~ 255...

  • Page 60: Wlan

    XT3-40 Series 4-5-3 WLAN List Explanation Explanation Setting channel when creating Adhoc network Default Value Channel Variable Value 1 ~ 14 Explanation Setting WLAN operation mode Default Value Network Soft AP Variable Value Soft AP, Infrastructure, Adhoc, P2P Explanation Setting the ID of AP to be accessed...
  • Page 61 XT3-40 Series Explanation PSK Password Setting PSK password Explanation Setting IP assignment method Default Value IP Protocol DHCP Variable Value Static IP, DHCP Explanation Setting IP address Default Value IP Address Static IP: 192.168.1.1 DHCP: 0.0.0.0 Variable Value 0 ~ 255...
  • Page 62 XT3-40 Series Explanation After searching a Smart Connection Act Enabled printer with the smart phone app, enable or disable the function synchronizing Wi-Fi login information connected to the smart phone. Smart Connection active Default Value Disable Variable Value Disable, Enable Ver.

  • Page 63: Bluetooth

    XT3-40 Series 4-5-4 Bluetooth List Explanation Explanation Device Name Name of Device Explanation Pincode Changes required pin code to connect Explanation Secures simple pairing Pairing Default Value Disable Variable Value Disable, Just Works, Numeric Comparison, Passkey Entry Explanation MAC Address...

  • Page 64: Sensor Menu Explanation

    XT3-40 Series 4-6 Sensor Menu Explanation List Explanation Explanation Gap Calibration Detect media gap and calibrate automatically Black Mark Explanation Calibration Detect media black mark and calibrate automatically Explanation Adjusts the sensitivity of the gap sensor Default Value Sensor Sensitivity...

  • Page 65: Files Menu Explanation

    XT3-40 Series 4-7 Files Menu Explanation List Explanation Template Image Refer Download Fonts Saved File 4-7-1 Saved File E Drive (Flash Memory) A Drive (USB Memory ) Printer Setting Refer Files Template Twin Function 4-7-2 Twin Image Function Download Fonts...

  • Page 66: Twin Function

    XT3-40 Series 4-7-2 Twin Function Saves the current printer settings, save files (templates, images, download fonts) to another printer using USB, or loads the settings of another printer and saves files to the current printer. List Explanation Explanation Saves printer settings to a USB storage device, or loads the print settings from USB storage.
  • Page 67 XT3-40 Series List Explanation Explanation Saves printer settings to a USB storage device, or loads the print settings from USB storage. File path F:\configuration • Save Function Explanation - Connect a USB storage to the printer. - Select Save on the menu using the up and down buttons.
  • Page 68 XT3-40 Series List Explanation Explanation Saves template file to a USB storage device, or load the template from USB storage. File path F:\ USER_AREA_TEMPLATES • Save Function Explanation - Connect a USB storage to the printer. - Select Save on the menu using the up and down buttons.
  • Page 69 XT3-40 Series List Explanation Explanation Saves image file to a USB storage device, or load the image from USB storage (*.pcx) File path F:\ USER_AREA_Images • Save Function Explanation - Connect a USB storage to the printer. - Select Save on the menu using the up and down buttons.
  • Page 70 XT3-40 Series List Explanation Explanation Saves download font file to a USB storage device, or load the download font from USB storage. File path F:\ USER_AREA_FONTS • Save Function Explanation - Connect a USB storage to the printer. - Select Save on the menu using the up and down buttons.

  • Page 71: Firmware Update

    XT3-40 Series 4-7-3 Firmware Update Firmware can be updated through USB storage. Explanation Printer firmware update available using the USB storage directly without any communication. File path F:\ FW_DOWNLOAD File name “XT3-4x_Vxx.xx_STD_mmddyy.fls” in F:\ FW_ DOWNLOAD folder. FirmWare • Download process explanation - Check firmware file(*.fls) is in FW_ DOWNLOAD folder...

  • Page 72: Tools Menu Explanation

    XT3-40 Series 4-8 Tools Menu Explanation List Explanation Explanation Self Test Prints for self-test Explanation Factory Reset Initializes the printer settings to factory default Explanation Diagnoses communication status when printing is not normal Dump Mode Default Value Disable Variable Value...
  • Page 73 XT3-40 Series Explanation Setting language to be displayed on the LCD Default Value Language Setting English Variable Value English, Korean, German, French, Spanish Explanation Setting printer emulation Default Value Emulation AUTO Variable Value AUTO(SLCS, BPL-Z, BPL-E), BPL-D USB Serial Explanation...

  • Page 74: Info Menu Explanation

    XT3-40 Series 4-9 Info Menu Explanation List Explanation Explanation Printer Info Checking the printer usage information Explanation Installation & Usage Site linking(QR code) for installation and usage instructions Explanation Troubleshooting Site linking(QR code) for troubleshooting Explanation Contact US Site linking(QR code) for technical support Ver.

  • Page 75: Detailed Features

    XT3-40 Series 5. Detailed Features 5-1 Pause/Cancel • During multiple-page print jobs, the Pause and Cancel button can be used to pause printing and cancel the print job altogether, respectively. Pause button Cancel button 5-1-1 Pause/Resume Function When printing, press...

  • Page 76: Print Cancellation

    XT3-40 Series 5-1-2 Print Cancellation The following processes occur in the print cancellation mode. - All label printing cancelled - All data received in the printer communications buffer deleted. - All received data deleted. 1) During printing and/or pause mode, press...

  • Page 77: Smart Media Detection

    XT3-40 Series 5-2 Smart Media Detection • Media with gap and black mark can be identified without additional settings. • 3~5 pages of media will be used depending on the types of media. • Smart Media Detection function is executed in the followings cases...

  • Page 78: Gap Sensor Auto Calibration Mode

    XT3-40 Series 5-3 Gap Sensor Auto Calibration Mode • Gap sensor auto calibration mode is used when the printer does not detect a gap on the media correctly. Generally a printer is set to detect most types of gap but sometimes it fails to detect and keep feeding the media without a stop when special media used.

  • Page 79: Black Mark Sensor Auto Calibration Mode

    XT3-40 Series 5-4 Black Mark Sensor Auto Calibration Mode • Black mark sensor auto calibration mode is used when the printer does not detect a black mark on the media correctly. Generally a printer is set to detect most types of black mark but sometimes it fails to detect and keep feeding the media without a stop when special media used.

  • Page 80: Media Sensor Manual-Calibration

    Users can calibrate sensor parameters in detail by using the Unified Label Utility-II program provided by the manufacturer. The Unified Label Utility-II can be downloaded from the Internet via the BIXOLON website. (www.bixolon.com) Please make sure the printer is connected and execute the Unified Label Utility-II program.
  • Page 81 XT3-40 Series 1) Select the sensing type and input the label length by millimeter and click “Check Sensing Value” button. Then printer starts calibration. 2) Printer will print the scanned values after calibration and the values will appear on the Screen.

  • Page 82: Sensor Sensitivity

    XT3-40 Series 5-6 Sensor Sensitivity • Use this mode when paper is not detected correctly. You can adjust the strength of the sensor to fix the paper sensing problem. Turn the printer off and on to recover to the print ready mode.

  • Page 83: Factory Reset

    XT3-40 Series 5-8 Factory Reset • This function is used to factory reset the printer settings. 1) Make sure that media roll has been installed properly. 2) In print ready mode the setting menu and move to Tools → Reset and press button to reset the printer to Factory default.

  • Page 84: Maintenance

    XT3-40 Series 6. Maintenance 6-1 Cleaning Printer • Due to dust, foreign substances, adhesives, and other contaminants on or inside print head, print quality may be reduced. In this case, clean the printer using the cleaning tools for each area as indicated in the following table.

  • Page 85: Cleaning Printer Head

    XT3-40 Series 6-2 Cleaning Printer Head 1) Open the media cover and print head levers and remove the media and ribbon. 2) Clean the print head toward both sides from the center using a cotton swab dipped in medical alcohol.

  • Page 86: Cleaning Platen Roller

    XT3-40 Series 6-3 Cleaning Platen Roller 1) Open the media cover and print head levers and remove the media and ribbon. 2) While rotating the roller, remove dust or foreign substances using a dry cloth or cotton swab. 3) In case that adhesive substances or other contaminants remain, remove it using a cloth or cotton swab dipped in medical alcohol solution while rotating the roller.

  • Page 87: Cleaning Peeler Module (Optional)

    XT3-40 Series 6-4 Cleaning Peeler Module (optional) 1) Open the media cover, print head levers, and peeler cover and remove the media and ribbon. 2) While rotating the roller, remove dust or foreign substances using a dry cloth or cotton swab.

  • Page 88: Specifications

    XT3-40 Series 7. Specifications 7-1 Printer Specifications Item Description Printing Method Thermal transfer Printing XT3-40: 203dpi (8 dot/mm) Dot Density XT3-43: 300dpi (11.8 dot/mm) Printer XT3-40: Max 108mm (Max 4.25”) Print Width XT3-43: Max 105.7mm (Max 4.16”) XT3-40: Max 8ips (Max 203mm/sec)
  • Page 89 XT3-40 Series Revision History Rev. Date Page Description 1.00 2021-11-26 Ver. 1.00 - 89 -...

This manual is also suitable for:

Xt3-40Xt3-43
