- Page 1 GF 1900 SULFURYL FLUORIDE ANALYZER SULFURYL FLUORIDE MANUAL REV C PAGE 1 OF 23 04/07/11...
- Page 2 SULFURYL FLUORIDE MANUAL REV C PAGE 2 OF 23 04/07/11...
- Page 3 REVISIONS REVISION REVISION BRIEF DESCRIPTION NUMBER DATE 08/04/06 Manual format written for new standard. Included modified warnings and warranty. 08/17/06 Modification of intro.page -RJS 11/19/07 Removal of reference to Dow Agro or Vikane 04/07/11 Update references for setup to 5 ppm calibration. SULFURYL FLUORIDE MANUAL REV C PAGE 3 OF 23 04/07/11...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION…………………………………………………….5 CAUTIONS……………………………………………………………8 OPERATION………………………………………………………….9 CALIBRATION………………………………………………………10 MAINTENANCE…………………………………………………….11 TROUBLE SHOOTING……………………………………………..12 ACCESSORIES………………………………………………………14 WARRANTY…………………………………………………………16 DIAGRAMS, SCHEMATICS, AND PARTS..........17 MAIN CIRCUIT BOARD……………………………………18 WIRING DIAGRAM………………………………………..19 PARTS LIST………………………………………………….20 BATTERY PACK WIRING………………………………….22 RETURN AUTHORIZATION………………………………………23 SULFURYL FLUORIDE MANUAL REV C PAGE 4 OF 23 04/07/11... -
Page 5: Introduction
INTRODUCTION The Interscan GF1900 Sulfuryl Fluoride gas fumigant analyzer is expressly designed for use as a clearance monitoring device to determine safe re-occupation of a structure after aeration only. Use of this device for any purposes other than use as a clearance device will invalidate the warranty. - Page 6 Ready L.E.D. - illuminates when furnace reaches proper preset operating temperature. NOTE: The “Ready” L.E.D. is not an indicator of Sensor stabilization. LO BAT. – illuminates when battery pack or AC power supply is at or below 19.0 V DC. Meter –...
- Page 7 Gas sample inlet PORT. Tubing is pushed into port until seated and then gently pulling back. The pulling back action is performed to properly seal the connection. Teflon tubing ¼ O.D. x 1/8 I.D. is recommended for use. Length should not exceed twelve (12) inches when used with factory calibration.
-
Page 8: Cautions
CAUTIONS Items inside yellow boundary can cause injury. Do not attempt to service until instrument has cooled for one (1) hour. DO NOT attempt to use in areas where gasoline, sulfur compounds, or highly flammable vapors are present. The presence of any of these could produce an EXPLOSION. -
Page 9: Operation
OPERATION 1) Turn the FUNCTION SWITCH knob to the OFF position and connect an AC power supply or battery pack. Tighten the connector completely. NOTE: Turn only the knurled ring to tighten. Tightening the connection by turning any other portion of cable can result in a short, fire, or explosion. 2) Turn the FUNCTION SWITCH to ON or BAT TEST and wait for the READY indicator to light. -
Page 10: Calibration
CALIBRATION Note: Should be done every 3 months or more frequent. Some companies require monthly calibration. The instrument is calibrated by introducing, a known concentration of Sulfuryl Fluoride gas (5 ppm), and adjusting the SPAN control to correspond to the known analysis of the gas. -
Page 11: Maintenance
MAINTENANCE Furnace Replacement Make sure power is disconnected and the analyzer is allowed to cool. Do not attempt to service until cooled for a minimum of one (1) hour. Remove the thermocouple leads at terminals 3 and 6 of the terminal block. For easy access, loosen the sensor clamp screw and lift the sensor out, placing it on the fan. -
Page 12: Trouble Shooting
TROUBLE SHOOTING READY light does not illuminate. Check that the POWER L.E.D. is illuminated. If it is not: 1) Check the main fuse. 2) Check that the rear connector is tight. 3) Check the power source for a nominal 24V. 4) Check that the circuit board connector is tight. - Page 13 Furnace is hot, READY light is not on. Thermocouple may be defective. Check across leads for mV reading. The reading should be greater than 20 mV after 5 minutes. Reverse thermocouple leads if the reading is negative. If thermocouple is okay, R27 may be set incorrectly. With the thermocouple reading approximately 35 mV, adjust R27 to get a READY indication.
-
Page 14: Accessories
ACCESSORIES Figure 1: GFPS1297 AC POWER SUPPLY Figure 2: VKBP 24 VDC BATTERY PACK SULFURYL FLUORIDE MANUAL REV C PAGE 14 OF 23 04/07/11... - Page 15 Figure 3: BC1-24V PATTERY PACK CHARGER SULFURYL FLUORIDE MANUAL REV C PAGE 15 OF 23 04/07/11...
-
Page 16: Warranty
EXCEPTED) to be free from defects in material and workmanship for a period of one year from date of shipment. INTERSCAN CORPORATION warrants furnaces for six (6) months from date of shipment to be free from defects in material and workmanship. No warranty is expressed or implied as to the functional life of the furnace. -
Page 17: Diagrams, Schematics, And Parts
DIAGRAMS, SCHEMATICS & PARTS SULFURYL FLUORIDE MANUAL REV C PAGE 17 OF 23 04/07/11... -
Page 18: Main Circuit Board
SULFURYL FLUORIDE MANUAL REV C PAGE 18 OF 23 04/07/11... -
Page 19: Wiring Diagram
SULFURYL FLUORIDE MANUAL REV C PAGE 19 OF 23 04/07/11... -
Page 20: Parts List
Parts List…Interscan Model GF1900 RESISTORS 6192F 2430F 4992F 1001F 20KΩ Ω Ω Ω 49R9F 51Ω Ω Ω Ω 2492F 4992F 1003F 5.1KΩ Ω Ω Ω 2492F 27KΩ Ω Ω Ω 1.2KΩ Ω Ω Ω 1001F 1273F 10MΩ Ω Ω Ω 2552F R10 47Ω... - Page 21 INTEGRATED CIRCUITS, SEMICONDUCTORS U1, U2 QUAD OPERATIONAL AMPLIFIER LM324N VOLTAGE CONVERTER ICL7660CPA 1.2V REFERENCE DIODE AD589JH CR2, CR3, CR4 LED, RED EBR5704S 5W, ZENER DIODE 1N5347 TRANSISTOR 2N4013 +5VDC VOLTAGE REGULATOR LM340T5 VARIABLE VOLTAGE REGULATOR LM317T MISCELLANEOUS BEZEL, LED (3) 816-1 CIRCUIT BOARD ISSC-2013-2 REV C...
-
Page 22: Battery Pack Wiring
SULFURYL FLUORIDE MANUAL REV C PAGE 22 OF 23 04/07/11... -
Page 23: Return Authorization
Should return of the instrument or part be advised by the Service Department, the "RETURN AUTHORIZATION NUMBER" will expedite prompt return of the repaired unit. For service information please contact: INTERSCAN CORPORATION Service Department (818) 882-2331 (800) 458-6153 (USA & CANADA)
