- Page 1 INSTALLATION AND OPERATION MANUAL Synapse 2GF100 - 2GF110 Dual Channel 3Gb/s, HD and SD Frame Synchronizer with Optional Audio Shuffler Version 1.00 | November 2021...
- Page 3 You will find the full list of addresses and phone numbers on the following webpage: https://evs.com/contact/offices. User Manuals on EVS Website The latest version of the user manual, if any, and other user manuals on EVS products can be found at the EVS download center, on the following webpage: https://download-area.evs.com. Synapse 2GF100 - 2GF110 | Disclaimer |...
-
Page 4: General Information
NEVER bypass any fuse. NEVER replace any fuse with a value or type other than those specified. NEVER attempt to repair this product. If a problem occurs, contact your local EVS distributor. NEVER expose this product to extremely high or low temperatures. -
Page 5: Table Of Contents
5. Settings Menu 5.1. Introduction 5.2. System Settings 5.3. Inserter 5.4. Video-Proc 5.5. Audio Proc Amp 5.6. Embedder 5.7. GPI Mode 5.8. Network 6. Status Menu 6.1. Introduction 6.2. System Status 6.3. Net Status 7. Events Menu Synapse 2GF100 - 2GF110 | Contents |... - Page 6 8. LED Indication 9. Block Schematic 10. Connector Panels Appendices Appendix 1: GPIs Explained Appendix 2: Card Dip Switches for BHX and Fiber Configurations GNU Public License ICONOGRAPHY Warning Note iv | November 2021 | Issue 1.00.E...
-
Page 7: What's New
The changes linked to new features in version 1.00 of 2GF100 - 2GF110-110 are listed below. SMPTE ST 352 Payload Identifier • See section "Inserter" on page 13. Synapse 2GF100 - 2GF110 | What's New? |... -
Page 9: Introduction
Synapse is a modular system designed for the broadcast industry. High density, intuitive operation and high-quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the EVS website at www.evs.com to obtain the latest information on our new products and updates. -
Page 10: Unpacking And Placement
2. Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 11: Quick Start
Move up within a menu, or increase the value of a parameter. Move down through a menu or decrease the value of a parameter. When editing parameters, pressing ► twice will reset the value to its default setting. Synapse 2GF100 - 2GF110 | 3. Quick Start |... - Page 12 How to Change Parameters Using the Front Panel Control With the display as shown below: Pressing selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated.
-
Page 13: Using Cortex With Synapse
For operation of Cortex, please refer to the Cortex help files. Further information about Front Panel Control and Cortex can be obtained from the ERC, ERS, RRC and RRS operational manuals and the Cortex help files. Synapse 2GF100 - 2GF110 | 3. Quick Start |... -
Page 14: The 2Gf100-110 Card
4. The 2GF100-110 Card Introduction The 2GF100-110 is a dual channel frame synchronizer with backup inputs and 8 channel audio transparency and color correcting capabilities. The powerful matrix multiplexer can feed audio from the embedded domain into the Synapse bus to an ADD-ON card like the DIO48. This matrix multiplexer also allows for audio to be inserted from the ADD-ON bus into the embedded domain of the 2GF100-110. - Page 15 To ensure correct operation, the F-delay of the card needs to be 1 or higher to allow enough time to mask the error. Synapse 2GF100 - 2GF110 | 4. The 2GF100-110 Card |...
- Page 16 Applications 2GF100 / 2GF110: • Transmission output frame synchronizer with backup input. 2GF110 only: • Combining embedded audio channels of 2 inputs into 1 (see image below) Block Schematic 8 | November 2021 | Issue 1.00.E...
-
Page 17: Settings Menu
Can be SDI-1 (SDI input 1), SDI-2 (SDI input 2) or Analog (CVBS in). You can also choose a Zoneplate or Colorbar as input. Can also be set to Off to switch off channel B entirely. The default for this setting is SDI-2. Synapse 2GF100 - 2GF110 | 5. Settings Menu |... - Page 18 #CVBS-Frmt With this item you can set the format of the CVBS input. Possible formats to select here are (default is Auto): • PAL-M • PAL-N • NTSC-M • NTSC-4.43 • NTSC-J • SECAM • PAL-60 • PAL-BGHID • Auto (automatic detection and selection between NTSC-J and PAL- BGHID) #Out-Frmt With Out-Frmt you can set what the output should be of channel A as...
- Page 19 2 (only for SFR08 and SFR18 frames and only when ref2 offers the same ref format as ref 1). When ref 1 is back up again, it will only automatically switch back to ref 1 when ref 2 fails. Synapse 2GF100 - 2GF110 | 5. Settings Menu |...
- Page 20 Ref-Type Sets the type of incoming reference. Can be either Bi-Level (default) or Tri- Level. P60-P50_Sync With this setting you can choose to synchronize each one frame or each two frames. Default is One Frame. The two-frame-synchronize mode only works for 720p60, 720p50, 1080p50 and 1080p60 standards. ANC_BlankA With this setting you can Blank the vertical ancillary data only (V-Only), blank the horizontal ancillary data only (H-only) or blank both vertical and...
-
Page 21: Inserter
With this setting you select a line in the VBI to where the AFD (SMPTE 2016) data should be written. Lines 0 till 31 are selectable. By default it is set to line 17. Synapse 2GF100 - 2GF110 | 5. Settings Menu |... - Page 22 Timecode_ins Here you can set if the timecode on the inputs should be copied to the outputs (On), or to copy the timecode from input 1 to input 2 (Copy 1 => 2), or to copy the timecode from input 2 to input 1 (Copy 2 => 1). You can also turn Off timecode insertion.
- Page 23 You can choose which type of WSS data you want to insert in Channel B with this setting, or switch WSS insertion entirely off (default value). You can set it to Standard or Extended. Synapse 2GF100 - 2GF110 | 5. Settings Menu |...
-
Page 24: Video-Proc
With the #WSS-InsertB setting set to Extended, you can select WSS extended values from the #VI-DataB setting, which you want to be inserted in Channel B. All VI settings between 4:3_0 and 4:3_7 are possible and the settings between 16:9_0 and 16:9_7. Default is 4:3_0. #WSS-StndB With the #WSS-InsertB setting set to Standard, you can select WSS standard values with this setting, which you want to be inserted in Channel... - Page 25 127 bits in steps of 1 bit The default setting is 0 bit. CVBS-Hue This item adjusts the HUE of the CVBS input. Can be set between -90 and +90 degrees. Default is 0 degrees. Synapse 2GF100 - 2GF110 | 5. Settings Menu |...
-
Page 26: Audio Proc Amp
5.5. Audio Proc Amp Setting Description Audio-Phase If this setting is set to Align, the card ensures audio-phase alignment between multiple audio channels and audio groups, which is necessary for multi-channel (surround) purposes. If errors in the signal-chain occur the de-embedder blocks reset synchronously to maintain audio-phase-alignment. -
Page 27: Embedder
5.6. Embedder Setting Description #Emb-AB-Mode With Emb-AB-Mode you select how the audio in groups A and B should be embedded into the video: overwrite the existing audio, or Append. Default is Overwrite. Synapse 2GF100 - 2GF110 | 5. Settings Menu |... - Page 28 #EmbA_Grp With this setting you select into which audio group (= 4 audio channels) of the outputs you want to embed the first 4 forwarded audio channels coming from the de-embedders/add-on bus. Can be group1, group2, group3 or group4. You can also choose to not use these 4 audio channels for anything by setting this item to off.
- Page 29 Adjusts the gain for the corresponding audio channel between -60 and 12dB. #EmbD4_Gain Everything below -999 dB means the audio will be muted. (2GF110 only) #EmbA1_Phase ~ Adjusts the audio phase of the corresponding to 0 deg or 180 deg. #EmbD4_Phase (2GF110 only) Synapse 2GF100 - 2GF110 | 5. Settings Menu |...
-
Page 30: Gpi Mode
5.7. GPI Mode Setting Description GPI-Ctrl You can set the GPI to be triggered in a latching manner or in a non-latching manner. Default for this is Latch. GPI_1 ~ GPI_5 In this card it is possible to make the 5 available GPI triggers part of a GPI pool that can control the various functions in the card separately (all Xx_Ctrl items of the menu). -
Page 31: Network
0.0.0.0 NetwPrefix0 Here you can set the specific network prefix if required. mNM0 With IP_Conf0 set to manual, with this setting you can set a Netmask. Default is 0.0.0.0 Synapse 2GF100 - 2GF110 | 5. Settings Menu |... -
Page 32: Status Menu
6. Status Menu 6.1. Introduction The Status menu provides information about the current status of each item listed below. 6.2. System Status Item Description ActiveA This status item indicates which input is active on outputs A1 and A2. Can be SDI-1,SDI-2 or Analog. - Page 33 • AFD5 • AFD13 • AFD6 • AFD14 • AFD7 • AFD15 • NA (no S2016 detected) sInp1_CRC_EDH This item indicates CRC and EDH errors on input 1. Can be: • • Error • Synapse 2GF100 - 2GF110 | 6. Status Menu |...
- Page 34 sInp1_Map This item indicates whether the 3Gb/s input on input 1 is Level A or Level B. When the input is not 3Gb/s, NA is indicated. This indicates the mapping of the 3Gb/s input 1 when the input format is 1080p50 or 1080p60.
-
Page 35: Net Status
This item displays the MAC address of the card. This item displays the current IP address of the card. This item displays the current Netmask of the card. This item displays the current Standard Gateway of the card. Synapse 2GF100 - 2GF110 | 6. Status Menu |... -
Page 36: Events Menu
7. Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of an Event? The goal of events is to inform the environment about a changing condition on the card. - Page 37 Card Address Together with the message string or the tag, the slot number or address of the card is relevant to be able to assign the event to a certain card. Synapse 2GF100 - 2GF110 | 7. Events Menu |...
-
Page 38: Led Indication
8. LED Indication Indicator Description Error LED The error LED indicates an error if the internal logic of the card is not configured correctly or has a hardware failure. Input_A LED This LED indicates the presence of a valid SDI video signal on input A. Input_B LED This LED indicates the presence of a valid SDI video signal on input B. -
Page 39: Block Schematic
INSTALLATION AND OPERATION MANUAL Block Schematic Synapse 2GF100 - 2GF110 | 9. Block Schematic |... -
Page 40: Connector Panels
HD/SD-SDI PROCESSED OUTPUT B1 HD/SD-SDI PROCESSED OUTPUT B2 CVBS INPUT For fiber connectivity, see www.evs.com Unused inputs and outputs must be terminated with the correct impedance. Please refer to "Card Dip Switches for BHX and Fiber Configurations" in the Appendices before connecting any backpanel. - Page 41 INSTALLATION AND OPERATION MANUAL GPI Pinning Pin Function GPI in 1 GPI in 2 GPI in 3 GPI in 4 GPI in 5 Frame Sync 1 Tracking Frame Sync 2 Tracking Ground Synapse 2GF100 - 2GF110 | 10. Connector Panels |...
-
Page 42: Appendices
Appendices Appendix 1: GPIs Explained GPI Pools This card has 5 GPI contacts. Since there are several functions you can control by using GPIs (for instance: outmode and up/down/cross-presets and audio presets), you can add each individual GPI contact to certain GPI pools. Each pool can then be assigned to control a specific setting. Binary Mode or Priority Mode In the GPI_1 through GPI_5 settings, you can assign each GPI contact to one of the 3 available pools. - Page 43 Pool A now consists of GPI 1, GPI 2 and GPI 3 (as take), in a binary mode, controlling the Up converter preset. Pool B now consists of GPI 4 and GPI 5 in a priority mode, controlling the audio presets. Synapse 2GF100 - 2GF110 | Appendix 1: GPIs Explained |...
- Page 44 Pool A now works as follows: GPI 1_Status GPI_2 Status Set Value (when GPI_3 (take) is closed) Up-conv Preset 1 Up-conv Preset 2 Up-conv Preset 3 Up-conv Preset 4 Pool B now works as follows: GPI_4 Status GPI_5 Status Set Value Audio Preset 1 Audio Preset 2 Audio Preset 3 Audio Preset 3 (because highest takes priority)
- Page 45 Set Value Audio Preset 1 Audio Preset 2 Audio Preset 3 Audio Preset 3 (because highest takes priority) Pool C now works as follows: GPI_5 Status Set Value A out only B out only Synapse 2GF100 - 2GF110 | Appendix 1: GPIs Explained |...
-
Page 46: Appendix 2: Card Dip Switches For Bhx And Fiber Configurations
Appendix 2: Card Dip Switches for BHX and Fiber Configurations There are dip switches on the circuit board of the card itself. With these dip switches you can change the power voltages that is put on the backpanel. By default the switches are set to off, putting no power on the backpanel. - Page 47 NOT have a delayed trigger signal onboard. In case of power failure or when the Synapse board is extracted from the frame, the bypass is immediately active. Synapse 2GF100 - 2GF110 | Appendix 2: Card Dip Switches for BHX and Fiber Configurations |...
-
Page 48: Gnu Public License
Under this license, you are eligible to receive a copy of the source code of this software, including any changes. EVS Broadcast Equipment SA shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs.
