- Page 1 INSTALLATION & CONFIGURATION MANUAL 2GF100/110 – 2HF100/110 – 2SF100/110 DUAL CHANNEL 3GB/S, HD AND SD FRAME SYNCHRONIZER WITH OPTIONAL AUDIO SHUFFLER...
- Page 2 (for manuals on hardware products) or on the EVS website on the following page: http://www.evs.com/contacts. User Manuals on EVS Website The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/ The user manuals for other EVS products can be found at the EVS download center, on the following webpage: https://www.evs.com/en/download-area.
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: EVS warrants their products according to the warranty policy as described in the general terms. That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 Table of Contents Table of Contents Introduction to Synapse An Introduction to Synapse Local Control Panel Remote Control Capabilities Unpacking and Placement Unpacking Placing the card A Quick Start ... - Page 5 EVS Broadcast Equipment SA #S2016-DataA #OSD-StyleA #OSD-TextA Ins_CtrlB Ins_Prst_ActB Ins_Prst_EditB #VI-InsertB #VI-DataB #WSS-InsertB #WSS-StndB #WSS-ExtndB #VI-DataB #S2016-InsertB #S2016-DataB #OSD-StyleB #OSD-TextB GainA R-GainA ...
- Page 6 INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 sInp1_WSS-Extd sInp1_S2016 sInp1-Map sInp2 sInp2_VI sInp2_WSS-Stnd sInp2_WSS-Extnd sInp2_S2016 sInp2-Map sInp3_WSS-Stnd sInp3_WSS-Extnd sInpCVBS IODelayA SwitchLnA SwitchLn_LenA SwitchLn_PosA ...
- Page 7 EVS Broadcast Equipment SA Example 1 Example 2 Example 3 GNU Public License version 2 ...
-
Page 8: Introduction To Synapse
Synapse High density, intuitive operation and high quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the EVS Broadcast Equipment Website at www.evs.com to obtain the latest information on our new products and updates. -
Page 9: Unpacking And Placement
EVS Broadcast Equipment SA 2 Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 10: A Quick Start
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 3 A Quick Start When Powering- On powering up the Synapse frame, the card set will use basic data and default initialisation settings. All LED’s will light during this process. After initialisation, several LED’s will remain lit – the exact number and configuration is dependant upon the number of inputs connected and the status of the inputs. -
Page 11: Example Of Changing Parameters Using Front Panel Control
EVS Broadcast Equipment SA Example of With the display as shown below changing parameters using front panel control RRC18 [Select Card] >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. -
Page 12: Synapse Cortex Software
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 Changing a setting has an immediate effect. Synapse Cortex can be used to change the settings of Synapse Synapse Cortex modules from a PC, either locally or remotely. The software enables Software communication based on TCP/IP between the Setup PC and Synapse frames/modules. -
Page 13: The 2Gf-2Hf-2Sf100/110 Card
EVS Broadcast Equipment SA 4 The 2GF-2HF-2SF100/110 Card Introduction The 2GF100/110, 2HF100/110 and 2SF100/110 are dual channel frame synchronizers with backup inputs and 8 channel audio transparency and color correcting capabilities. The powerful matrix multiplexer can feed audio from the embedded domain into the Synapse bus to an ADD-ON card like the DIO48. - Page 14 INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 output format for a constant latency operation. 30 Frames delay offset (per channel) 1080i60 1080p24 1080i50 1080p60 1080p30 1080p50 1080p25 60 Frames delay offset (per channel) ...
-
Page 15: Applications
EVS Broadcast Equipment SA Transmission output frame synchronizer with backup input Applications 2GF110, 2HF110 and 2SF110 only: Combining embedded audio channels of 2 inputs into 1 (see image below) Block schematic... -
Page 16: Settings Menu
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 5 Settings Menu Introduction The settings menu displays current state each 2GF/2HF/2SF100-110 setting and allows you to change or adjust it. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or with Cortex. -
Page 17: Cvbs-Frmt
EVS Broadcast Equipment SA #CVBS-frmt With this item you can set the format of the CVBS input. Possible formats to select here are (default is Auto): PAL-M PAL-N NTSC-M NTSC-4.43 NTSC-J SECAM PAL-60 ... -
Page 18: F-Delay
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 switch back when the input fails again. Default is on. #F-delay F-Delay sets the amount of delayed Frames. The available range is from 0 to 250 fields (dependant on the I/O). Default is 0F. The preset master for this is Out-Frmt, hence the ‘#’-prefix. -
Page 19: Lock-Mode
EVS Broadcast Equipment SA Lock-Mode Lock-Mode determines whether the card is locked to his input (input 1), to the reference (Ref1 or Ref2) or freerun (not locked). By default it is set to Ref1. Can also be set to RefAuto. -
Page 20: Patternspeed
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 PatternSpeed Sets the speed of the test-pattern (see settings Inp_SelA and Inp_SelB) animation between 0 (still) and 15 (fast). Default is 1. Input_loss_A Input_loss_A determines what the output of outputs A is in case of lost input: Freeze: a capture of the last good field or frame. -
Page 21: Vitc_Ln_625
EVS Broadcast Equipment SA VITC_Ln_625 When VITC_Ln_Ctrl is set to Manual, with this setting you can select a line between 7 and 22 when the output is SD625. Default is line 19. VITC_Ln_525 When VITC_Ln_Ctrl is set to Manual, with this setting you can select a line between 7 and 22 when the output is SD525. -
Page 22: Wss-Extnda
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 and 8_vid and the settings between 1_flm and 8_flm. Default is 1_vid. #WSS-ExtndA With the #VI-InsertA setting set to on, you can select VI values with this setting, which you want to be inserted in Channel A. possible are all WSS values between 4:3_0 and 4:3_7 and the settings between 16:9_0 and 16:9_7. -
Page 23: Vi-Insertb
EVS Broadcast Equipment SA same you are going to edit. All menu settings that are preceded with a #Ins-prefix are part of the preset. #VI-InsertB You can turn VI insertion on or off for channel B. Default is Off. #VI-DataB With the #VI-InsertB setting set to on, you can select VI values with this setting, which you want to be inserted in Channel B. -
Page 24: Osd-Textb
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 be displayed on outputs B. Possible are: Off (no OSD) Transp (transparent text) Masked (OSD displayed in a black box) Blink-Transp (blinking transparent text) Blink-Masked (blinking text in a black box) #OSD-TextB Here you can set a 10 character long text which should be displayed on-screen on outputs B when the above setting is not set to Off. -
Page 25: R-Blacka
EVS Broadcast Equipment SA R-BlackA R-BlackA controls the Red-Black of channel A. The control range is between –128bits and 127 bits in steps of 1 bit The default setting is 0 bit. G-BlackA G-BlackA controls the Green-Black of channel A. The control range is between –128bits and 127 bits in steps of 1 bit... -
Page 26: Audiostatusbits
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 maintained if this setting is set to Off. Note: This setting can be helpful to solve problems in the field using equipment which doesn’t follow the standards correctly. AudioStatusBits With this setting you select whether the audio status bits should be Transparent (off) (same status bit on the outputs as on the inputs) or to overwrite (on) them with new status bits. -
Page 27: Audio_Prst_Act
EVS Broadcast Equipment SA (GPI, GPI-A, GPI-B or GPI-C), via the SD aspect ratio (SD-AR) or via the HD aspect ratio (S2016). Audio_Prst_act With this item you can manually change the currently active audio preset. Can be any preset between 1 and 16. By default it is set to 1. -
Page 28: Emba1_Inp_Ch ~ #Emba4_Inp_Ch
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 SDI2), the embedder of the active input (Demb-Input, dependant on the current active input), from the ADD-ON bus groups, or to mute the corresponding channel (set to off). Defaults here are Off. -
Page 29: Embc_Grp
EVS Broadcast Equipment SA #EmbC_Grp With this setting you select in to which audio group (= 4 audio channels) of the outputs you want to embed the third group of 4 forwarded audio channels coming from the de-embedders/add-on bus. Can be group1, group2, group3 or group4. You can also choose to not use these 4 audio channels for anything by setting this item to off. -
Page 30: Embd1_Inp_Ch ~ #Embd4_Inp_Ch
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 #EmbD1_Inp_Ch With these settings you can select which Channel of the selected input should be embedded to the corresponding output channel. Can #EmbD4_Inp_Ch be any channel between Ch_1 and Ch_16. Defaults for C1 till C4 are respectively Ch_13 till Ch_16. -
Page 31: Mip0
EVS Broadcast Equipment SA automatically via DHCP, or appoint a manual set IP address. By default this setting is set to Manual. mIP0 When IP_Conf0 is set to manual, you can type in the preferred IP address here. By default it is set to 172.16.1.2 mNM0 With IP_Conf0 set to manual, with this setting you can set a Netmask. -
Page 32: Status Menu
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 6 Status Menu Introduction The status menu indicates the current status of each item listed below. ActiveA This status item indicates which input is active on outputs A1 and A2. Can be SDI-1, SDI-2 or Analog. ActiveB This status item indicates which input is active on outputs B1 and B2. -
Page 33: Sinp1_Wss-Stnd
EVS Broadcast Equipment SA sInp1_WSS-Stnd This status item displays the detected standard WSS value of input 1. this is displayed as follows: 1_vid 2_vid 3_vid 4_vid 5_vid 6_vid 7_vid 8_vid 1_flm ... - Page 34 INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 AFD6 AFD7 AFD8 AFD9 AFD10 AFD11 AFD12 AFD13 AFD14 AFD15 NA (no S2016 detected)
-
Page 35: Sinp1-Map
EVS Broadcast Equipment SA sInp1-Map This item indicates whether the 3Gb/s input on input 1 is Level A or Level B. When the input is not 3Gb/s, NA is indicated. sInp2 This status item indicates the presence and format of a valid signal in input 2. - Page 36 INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 SECAM-525 NA (no input detected)
-
Page 37: Iodelaya
EVS Broadcast Equipment SA IODelayA Displays the total delay in ms of outputs A1 and A2. can be a value between 0ms and 15000ms. SwitchLnA Displays what line is detected the switchline for channel A. Can be any line between 0 and 1125. -
Page 38: Gpia
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 GPIA Displays the current value of GPI pool A GPIB Displays the current value of GPI pool B GPIC Displays the current value of GPI pool C NET STATUS IP_Addr0 This item displays the status of the IP address. It can be manual, DHCP asking, DHCP Leased or DHCP Infin. -
Page 39: Events Menu
EVS Broadcast Equipment SA 7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of... -
Page 40: The Message String
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 The Message String The message string is defined in the card and is therefore fixed. It may be used in controlling software like Synapse Set-up to show the event. The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. -
Page 41: Led Indication
EVS Broadcast Equipment SA 8 LED Indication Error LED The error LED indicates an error if the internal logic of the card is not configured correctly or has a hardware failure. Input_A LED This LED indicated the presence of a valid SDI video signal on input A. -
Page 42: Block Schematic
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 9 Block Schematic... -
Page 43: 10 Connector Panels
EVS Broadcast Equipment SA 10 Connector Panels The 2GF/2HF/2SF100-110 can be used with the BPH17 or the BHX17b. The following table displays the pinout of these backpanels in combination with the card. BPH17 BHX17b HD/SD SDI INPUT A HD/SD-SDI INPUT B... -
Page 44: Appendix
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 Appendix 1 Card dip-switches for BHX and fiber configuration There are dip-switches on the circuit board of the card itself. With these dip-switches you can change the power-voltages that is put on the backpanel. - Page 45 EVS Broadcast Equipment SA as soon as it detects the trigger signal from the connected synapse card. This setting will minimize the bypass time and ensures fast recovery of processed signals. The ON setting is recommended if the BHX-backpanel is used in combination with synapse cards: ...
-
Page 46: Gpi's Explained
INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 Appendix 2 GPI’s explained GPI pools This card has 5 GPI contacts. Since there are several functions you can control by using GPI’s (for instance: outmode and up/down/cross-presets and audio presets) you can add each individual GPI contact to certain GPI pools. - Page 47 EVS Broadcast Equipment SA Example 2 Let’s say we would like to control the up-converter presets using Pool A (Up_CtrlA set to GPI-A) in binary mode and the audio presets using Pool B (Audio_Ctrl set to GPI-B) in priority mode. We could do the following: ...
- Page 48 INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 and GPI 4 in a priority mode, controlling the audio presets. Pool C consists only of GPI 5 (also in priority mode) Pool A now works as follows: GPI_1 status GPI_2 status Set value Up-conv Preset 1 Up-conv Preset 2...
- Page 49 EVS Broadcast Equipment SA This product contains open‐source software This product contains open‐source software licensed under the GNU Public License (GPL). A copy of the GNU Public License is included below. Under this license you are eligible to receive a copy of the source code of this software including any changes. EVS Broadcast Equipment shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs. This offer is valid up to three years after date of purchase. Please direct your request to the support department of EVS Broadcast Equipment. EVS Broadcast Equipment supports open‐source software by participating in the development of open‐source projects or submitting improvements to these projects. For more information see ftp://opensource.axon.tv/. GNU Public License version 2 TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The “Program”, below, refers to any such program or work, and a “work based on the Program” means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term “modification”.) Each licensee is addressed as “you”. Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program). Whether that is true depends on what the Program does. 1. You may copy and distribute verbatim copies of the Program’s source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program. You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee. ...
- Page 50 INSTALLATION AND CONFIGURATION MANUAL – 2GF100/110 – 2HF100/110 2SF100/110 Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete machine‐readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in objects code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition fi les, plus the scripts used to control compilation and installation of the executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code. 4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance. 5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it. 6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients’ exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License. 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from ...
- Page 51 EVS Broadcast Equipment SA NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
