Summary of Contents for EVS GFS010
- Page 1 INSTALLATION & CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 3GB/S, HD AND SD BASIC FRAME SYNCHRONIZER...
- Page 2 (for manuals on hardware products) or on the EVS website on the following page: http://www.evs.com/contacts. User Manuals on EVS Website The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/ The user manuals for other EVS products can be found at the EVS download center, on the following webpage: https://www.evs.com/en/download-area.
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: EVS warrants their products according to the warranty policy as described in the general terms. That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 Table of Contents Table of Contents Introduction to Synapse An Introduction to Synapse Local Control Panel Remote Control Capabilities Unpacking and Placement Unpacking ... -
Page 5: Example
EVS Broadcast Equipment SA GainA R-GainA G-GainA B-GainA BlackA R-BlackA G-BlackA B-BlackA CVBS-Hue Audio-Phase AudioStatusBits emb_aud_hand_A Audio_Ctrl Audio_Prst_act Audio_Prst_Edit #Emb-AB-Mode #EmbA_Grp #EmbA1_Inp ~ #EmbA4_Inp ... - Page 6 INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 LED Indication Error LED Input_A LED Input_B LED ANC Data LED Reference LED Data Error LED Connection LED Error LED Block Schematic ...
-
Page 7: Introduction To Synapse
Synapse High density, intuitive operation and high quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the EVS Broadcast Equipment SA Website at http://www.evs.com to obtain the latest information on our new products and updates. -
Page 8: Unpacking And Placement
GFS010 – HFS010 – SFS010 2 Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 9: A Quick Start
EVS Broadcast Equipment SA 3 A Quick Start When Powering- On powering up the Synapse frame, the card set will use basic data and default initialisation settings. All LED’s will light during this process. After initialisation, several LED’s will remain lit – the exact number and configuration is dependant upon the number of inputs connected and the status of the inputs. -
Page 10: Example Of Changing Parameters Using Front Panel Control
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 Example of With the display as shown below changing parameters using front panel control RRC18 [Select Card] >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. -
Page 11: Synapse Cortex Software
EVS Broadcast Equipment SA Synapse Cortex can be used to change the settings of Synapse Synapse Cortex modules from a PC, either locally or remotely. The software enables Software communication based on TCP/IP between the Setup PC and Synapse frames/modules. -
Page 12: The Gfs-Hfs-Sfs010 Card
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 4 The GFS-HFS-SFS010 Card Introduction The GFS010, HFS010 and SFS010 are frame synchronizers with 16 channel audio transparency and color correcting capabilities. The GFS010 is compatible with 270Mb/s, 1.5Gb/s and 3Gb/s for full 1080p/50 or 1080p/59.94 use. -
Page 13: Block Schematic
EVS Broadcast Equipment SA Block schematic... -
Page 14: Settings Menu
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 5 Settings Menu Introduction The settings menu displays current state each GFS/HFS/SFS010 setting and allows you to change or adjust it. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or with Cortex. -
Page 15: Io-Map
EVS Broadcast Equipment SA #IO-Map With this setting you can select the 3Gb/s mapping in case the input format is 1080p50 or 1080p60. Can be manually set to Level A or (GFS only) Level B. You can also choose to set it to auto, in which case the GDL will automatically detect whether the input is Level A or Level B. -
Page 16: Ref-Type
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 Ref-Type Sets the type of incoming reference. Can be either Bi-Level or Tri-Level. Default is Bi-Level. P60-P50_Sync With this setting you can choose to synchronize each one frame or each two frames. Default is One Frame. The two-frame- synchronize mode only works for 720p60, 720p50, 1080p50 and 1080p60 standards. -
Page 17: Timecode_Inp
EVS Broadcast Equipment SA INSERTER This card can insert several data values in the VBI of the outputs. With the following settings you can choose what you want to insert. Timecode_Inp With this card it is possible to copy the embedded timecode information of either input SDI-1 or input SDI-2 to the output. -
Page 18: Ins_Prst_Edita
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 Ins_Prst_EditA Here you can select which of the 16 selectable presets you want to edit when in a transparent mode. Changing this will not change the active preset, unless the currently active preset is the same you are going to edit. -
Page 19: Osd-Stylea
EVS Broadcast Equipment SA #OSD-StyleA With this setting you select how the on-screen display text should be displayed. Possible are: Off (no OSD) Transp (transparent text) Masked (OSD displayed in a black box) Blink-Transp (blinking transparent text) ... -
Page 20: Audio-Phase
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 AUDIO PROC AMP Audio-Phase If this setting is set to Align, the card ensures audio-phase alignment between multiple audio channels and audio groups, which is necessary for multi-channel (surround) purposes. If errors... -
Page 21: Audio_Prst_Act
EVS Broadcast Equipment SA Audio_Prst_act With this item you can manually change the currently active audio preset. Can be any preset between 1 and 16. By default it is set to 1. All menu settings that are preceded with a ‘#Emb’-prefix are part of the preset. -
Page 22: Emb-Cd-Mode
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 #Emb-CD-Mode With Emb-AB-Mode you select how the audio in groups C and D should be embedded into the video: overwrite the exsisting audio, or Append. Default is overwrite. #EmbC_Grp With this setting you select in to which audio group (= 4 audio... -
Page 23: Gpi_1 ~ Gpi_5
EVS Broadcast Equipment SA GPI_1 ~ GPI_5 In this card it is possible to make the 5 available GPI triggers part of a GPI pool that can control the various functions in the card separately (all Xx_Ctrl items of the menu). With these items you can select which pool the corresponding GPI is part of and in what way it should trigger. -
Page 24: Status Menu
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 6 Status Menu Introduction The status menu indicates the current status of each item listed below. sInp1 This status item indicates the presence and format of a valid signal in input 1. This is displayed as: ... -
Page 25: Sinp1_Wss-Stnd
EVS Broadcast Equipment SA sInp1_WSS-Stnd This status item displays the detected standard WSS value of input 1. this is displayed as follows: 1_vid 2_vid 3_vid 4_vid 5_vid 6_vid 7_vid 8_vid 1_flm ... -
Page 26: Sinp1_S2016
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 sInp1_S2016 This item displays the detected SMPTE 2016 (AFD) values of input 1. This is displayed as follows: AFD0 AFD1 AFD2 AFD3 AFD4 AFD5 ... -
Page 27: Gpi
EVS Broadcast Equipment SA GPI Displays the currently closed GPI contacts. This is displayed as for instance 1_3_ when contacts 1 and 3 are closed and for instance _234 when contacts 2, 3 and 4 are closed. GPIA Displays the current value of GPI pool A... -
Page 28: Events Menu
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. -
Page 29: The Message String
EVS Broadcast Equipment SA The Message String The message string is defined in the card and is therefore fixed. It may be used in controlling software like Synapse Set-up to show the event. The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. -
Page 30: Led Indication
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 8 LED Indication Error LED The error LED indicates an error if the internal logic of the GFS/HFS/SFS010 card is not configured correctly or has a hardware failure. Input_A LED This LED indicated the presence of a valid SDI video signal on input A. -
Page 31: Block Schematic
EVS Broadcast Equipment SA 9 Block Schematic GFS010 - HFS010- SFS010 3Gb/s, HD, SD OUT 1 3Gb/s. HD, SD OUT 2 3Gb/s, HD, SD IN FRAME COLOR 4 GROUP AUTOPHASER SYNC CORR. EMBEDDING 3Gb/s, HD, SD OUT 3 3Gb/s, HD, SD OUT 4... -
Page 32: 10 Connector Panels
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 10 Connector Panels The GFS/HFS/SFS010 can be used with the BPH17 or the BHX17b. The following table displays the pinout of these backpanels in combination with the card. BPH17 BHX17b HD/SD SDI INPUT A... -
Page 33: Appendix
EVS Broadcast Equipment SA Appendix 1 Card dip-switches for BHX and fiber configuration There are dip-switches on the circuit board of the card itself. With these dip-switches you can change the power-voltages that is put on the backpanel. By default the switches are set to off, putting no power on the backpanel. - Page 34 INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 recovery of processed signals. The ON setting is recommended if the BHX-backpanel is used in combination with synapse cards: which have a short initialization time, or which have a delayed trigger-signal onboard.
-
Page 35: Gpi's Explained
EVS Broadcast Equipment SA Appendix 2 GPI’s explained GPI pools This card has 5 GPI contacts. Since there are several functions you can control by using GPI’s (for instance: outmode and up/down/cross-presets and audio presets) you can add each individual GPI contact to certain GPI pools. Each pool can then be assigned to control a specific setting. - Page 36 INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 Example 2 Let’s say we would like to control the up-converter presets using Pool A (Up_CtrlA set to GPI-A) in binary mode and the audio presets using Pool B (Audio_Ctrl set to GPI-B) in priority mode.
- Page 37 EVS Broadcast Equipment SA Pool A now works as follows: GPI_1 status GPI_2 status Set value Up-conv Preset 1 Up-conv Preset 2 Up-conv Preset 3 Up-conv Preset 3 (because highest gets priority) Pool B now works as follows: GPI_3 status...
-
Page 38: Gnu Public License Version 2
INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 This product contains open‐source software This product contains open‐source software licensed under the GNU Public License (GPL). A copy of the GNU Public License is included below. Under this license you are eligible to receive a copy of the source code of this software including any changes. EVS Broadcast Equipment shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs. This offer is valid up to three years after date of purchase. Please direct your request to the support department of EVS Broadcast Equipment. EVS Broadcast Equipment supports open‐source software by participating in the development of open‐source projects or submitting improvements to these projects. For more information see ftp://opensource.axon.tv. GNU Public License version 2 TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The “Program”, below, refers to any such program or work, and a “work based on the Program” means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifi cations and/or translated into another language. (Hereinafter, translation is included without limitation in the term “modifi cation”.) Each licensee is addressed as “you”. Activities other than copying, distribution and modifi cation are not covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program). Whether that is true depends on what the Program does. ... - Page 39 EVS Broadcast Equipment SA Accompany it with the complete corresponding machine‐readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete machine‐readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in objects code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifi cations to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface defi nition fi les, plus the scripts used to control compilation and installation of the executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code. 4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance. 5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it. 6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients’ exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License. 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent ...
- Page 40 INSTALLATION AND CONFIGURATION MANUAL GFS010 – HFS010 – SFS010 NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
