AJAX SpaceControl Quick Start Manual page 2

Quick Start Guide
Key fob
Model Name: Ajax SpaceControl
Two-way wireless key fob
SpaceControl is a security system control key fob. It can arm and
disarm and can be used as a panic button.
IMPORTANT: This Quick Start Guide contains general
information about the SpaceControl. Before using the
device, we recommend to reviewing the User Manual on the
website:
ajax.systems/support/devices/spacecontrol
FUNCTIONAL ELEMENTS
1 - System arming button.
2 - System disarming button.
3 - Partial arming button.
4 - Panic button (activates the
alarm).
5 - Light indicators.
Assignment of the buttons in
using the key fob with Ajax Hub
and Ajax uartBridge. At the
moment, the feature of
modification of commands of
the fob buttons when using with
the Ajax Hub is not available.
IMPORTANT INFORMATION
This product can be used across all EU member states.
This device in compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU.
All essential radio test suites have been carried out.
CAUTION: RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS
KEY FOB CONNECTION
EN
The key fob is connected and set up via the Ajax Security System
mobile application (the process is supported by prompt
messages). For the key fob to become available for detection, at
the time of adding the device, simultaneously press the arming
button and the panic button
QR is located on the interior side of the device box cover and
inside the body at the battery attachment.
For the pairing to occur, the key fob and the hub should be located
within the same protected object.
To connect the key fob to a third party security central unit using
the Ajax uartBridge or Ajax ocBridge Plus integration module, follow
the recommendations in the user manual of the respective device.
USING THE KEY FOB
SpaceControl operates with a single reciever device only (Hub,
bridge).
The fob has protection against accidental buttons presses. Very
fast pressings are ignored, to operate the button it is necessary to
hold it for a while (less than quarter of a second). The
SpaceControl lights the green light indicator when a hub or
integration module receives a command and red light when
command is not received or not accepted.
For more detailed description of light indication refer to User
Manual.
The fob can:
Set the system to the armed mode - press the button
Set the system to the partially armed mode - press the button
Disarm the system - press the button
Switch on an alarm - press the button
To mute the actuated security system (siren), press the disarming
button on the fob.
COMPLETE SET
1. SpaceControl.
2. Battery CR2032 (pre-installed).
3. Quick Start Guide.
Autogoods "130"
TECH SPECS
Number of buttons
Panic button
.
Frequency band
Maximum RF output
Modulation
Radio signal
Power supply
Service life from
the battery
Operating temperature range
Operating humidity
Overall dimensions
Weight
WARRANTY
Warranty for the Ajax Systems Inc. devices is valid for 2 years
after the purchase and does not apply to the supplied battery.
If the device does not work correctly, you should first contact
.
the support service—in half of the cases, technical issues can
. be solved remotely!
.
The full text of the warranty is available on the website:
.
ajax.systems/ru/warranty
User Agreement:
ajax.systems/end-user-agreement
Technical support:
support@ajax.systems
868.0-868.6 mHz
(any obstacles absent)
1 battery CR2032A, 3 V
Up to 5 years (depending
on the usage frequency)
From -20°С to +50°С
65 х 37 x 10 mm
Manufacturer: Research and Production Enterprise "Ajax" LLC
Address: Sklyarenko 5, Kyiv, 04073, Ukraine
By request of Ajax Systems Inc.
www.ajax.systems
4
Yes
Up to 20 mW
FM
Up to 1,300 m
Up to 90%
13 g
