Hearth and Home Technologies IntelliFire Touch IFT-RC400 Installation Instructions Manual

Remote control & auxiliary control module

Advertisement

IntelliFire Touch
Leave this manual with party responsible for use
and operation.
1. Introduction
The IntelliFire Touch Remote Control (IFT-RC400) is
a hand-held wireless device that is designed to control
the functions of Hearth & Home Technologies products
equipped with IntelliFire™Touch technology.
used to control the flame ON/OFF, flame height, cold cli-
mate and programmable timer functions of a appliance.
The IFT-RC400 is also equipped with a temperature sen-
sor which allows it's use as a thermostat to set the desired
room temperature.
The IntelliFire Touch auxiliary control module (IFT-ACM)
is included in this kit. The ACM is an AC powered device
that controls peripheral devices such as lights, fans and
Power Vents approved for use in Hearth & Home Tech-
nologies products that are equipped with IntelliFire Touch
technology. It is connected to and controlled by the Intel-
liFire Touch Electronic Control Module (IFT-ECM).
2. IFT-RC400 & ACM Installation
A. Precautions
This device is tested and safe when installed in accor-
dance with this installation manual. Do not install any
components that may be damaged.
Do not modify, disassemble, or substitute any of the com-
ponents included with this kit. Installation of this unit must
be done by a qualified service technician.
The location of this device may affect performance. An
assessment of the location should be done prior to instal-
lation for optimum performance.
Hearth & Home Technologies disclaims any responsibility
for, and the warranty will be voided by, the following actions:
• Installation and use of any damaged system component.
• Modification of the system component.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not approved
by Hearth & Home Technologies.
Any such action may cause a fire hazard.
• Read, understand and follow these instructions for safe
installation and operation.
1
Hearth & Home Technologies • IFT-RC400 & IFT-ACM Installation Instructions • 2326-982 Rev. Q • 4/21
IFT-RC400 & IFT-ACM
®
Remote Control & Auxiliary Control Module
Installation Instructions
It can be
B. Determine Location
Determine the location for the IFT-RC400. The selected
location should be in the same space as the gas appliance
with visual sight of the fireplace. The device must be placed
within 30 feet (9.14 m) of the appliance, but should not
be exposed to extreme heat. The IFT-RC400 is approved
for interior installation and should not be used in exterior
applications.
• Keep remote control out of reach of children.
C. Kit Contents
• IFT-RC400 Remote Control (SRV2326-110)
• Radio Frequency Module (IFT-RFM) (SRV2326-120)
• AAA Batteries (4)
• Wall Mount
• 1 inch #6 Screws (2)
• Drywall Anchors (2)
• IntelliFire Touch Auxiliary Control Module (IFT-ACM)
(SRV2326-150)
• Power cable that connects AC receptacle to IFT-ACM
(SRV2326-152)
• 1 inch sq. Piece of Velcro
D. Installation Step
CAUTION! Do not install damaged components. If you
received components that are damaged, contact your
dealer for assistance.
1. Remove the contents from the packaging.
2. Locate the IntelliFire Touch electronic control module
(IFT-ECM) in the control cavity of the appliance and
move the three-position switch to the OFF position.
See Figure 1.
3. Connect the IFT-RFM to the IFT-ECM by aligning the
pins and tabs and pushing the IFT-RFM into the IFT-
ECM until both tabs snap into position. Ensure the two
components are fastened securely to one another.
See Figure 1.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntelliFire Touch IFT-RC400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hearth and Home Technologies IntelliFire Touch IFT-RC400

  • Page 1 IFT-RC400 & IFT-ACM ® IntelliFire Touch Remote Control & Auxiliary Control Module Installation Instructions B. Determine Location Leave this manual with party responsible for use Determine the location for the IFT-RC400. The selected and operation. location should be in the same space as the gas appliance with visual sight of the fireplace.
  • Page 2 ‘OFF’ POSITION ATTACH VELCRO Figure 3 Connecting IFT-ACM and IFT-ECM WARNING! Risk of Shock! DO NOT touch male pins. Figure 1 Connect IFT-RFM to IFT-ECM Leave rubber cap on all ports unless port is being con- 4. Remove protective rubber cap from connector on the nected to an accessory kit.
  • Page 3: Wall Mount Installation (Optional)

    8. Connect the female end of the power cable that came E. Wall Mount Installation (Optional) with the kit into the IFT-ACM. Ensure that power cable is securely and fully inserted into the IFT-ACM. Plug 1. Detach the IFT-RC400 from the wall mount. the three prong male plug into the junction box of the 2.
  • Page 4 F. Brand/Dealer Programming Procedure G. Pairing the IFT-RC400 to the Electronic Con- trol Module (IFT-ECM) This procedure allows the dealer to select the brand input Note: The display will remain illuminated if you hold a and dealer information for the consumer’s use. finger on the screen.
  • Page 5 4. Locate the pairing hole on the IFT-ECM. See Figure 8. b. Re-Pairing existing IFT-RC400 after add- Using a paper clip or similar item, press and release the ing ACM, blower kit, light kit or powervent pairing button. The IFT-ECM will “beep” once and the green LED blink for 14 seconds.
  • Page 6 H. LCD Screen Calibration Procedure This procedure allows the dealer to calibrate the touch screen, in the event that the screen becomes unresponsive to touch commands. Depending on the firmware installed in the RC400, two methods are available to enter screen calibration mode.
  • Page 7 I. Wiring Diagram IntelliFire Touch System Wiring Diagram - without Power Vent FLAME IFT-RC400 IGNITER SENSE REMOTE (OPTIONAL ON SOME CONTROL ADAPTER MODELS ONLY) MODULE RESET WIRE ASSEMBLY SWITCH TO JUNCTION BOX 110-120 IFT-RC150 WIRELESS WALL SWITCH (OPTIONAL) RF MODULE GRN/WHT/BLK FAN 110-120 VAC (OPTIONAL)
  • Page 8 I. Wiring Diagram (continued) IntelliFire Touch System Wiring Diagram - with Power Vent FLAME IGNITER SENSE (OPTIONAL ON SOME ADAPTER MODELS ONLY) MODULE IFT-RC400 RESET REMOTE WIRE ASSEMBLY SWITCH CONTROL TO JUNCTION BOX 110-120 RF MODULE GRN/WHT/BLK FAN 110-120 VAC (OPTIONAL) 6 PIN CONTROL...
  • Page 9 3. Operation Thermostat You can set and maintain your desired room tempera- Introduction ture with the thermostat function. This function automati- This operation section serves as a quick reference to the cally adjusts your appliance to maintain the desired set screen, functions and indicators on your IntelliFire Touch temperature (ST).
  • Page 10 FUNCTIONS FUNCTIONS INDICATORS INDICATORS Timer Temperature Display For your convenience a timer can be set up to 180 min- You can toggle the temperature display between °F and utes to turn off your fireplace. The timer will turn the flame °C by tapping on the Room Temperature area.
  • Page 11 INDICATORS INDICATORS Remote Control Communication Error Your remote control is not able to communicate with your Backup Battery appliance. Verify that you have power to your appliance. If there is a power outage, verify that appliance battery backup is fitted with new batteries. After taking these The battery life indicator is for a backup power source actions, communication can be re-established by pressing located inside your appliance.
  • Page 12: Maintenance

    Maintenance Your appliance will remind you to schedule routine ser- vice after 300 hours of Flame ON time is accumulated. Please contact your dealer for a 300 hour inspection to ensure your appliance is operating at peak performance. To reset the 300-hour maintenance reminder if the RC400 displays the following message: 1.
  • Page 13: Frequently Asked Questions/Troubleshooting

    4. Frequently Asked Questions/Troubleshooting Symptom Possible Cause Corrective Action The appliance does not respond to Install NEW batteries. Batteries are depleted. IFT-RC400 commands from the display does not light up when Batteries are incorrectly Verify batteries are installed in correct orientation as shown on screen is touched.
  • Page 14 Frequently Asked Questions/Troubleshooting (continued) Symptom Possible Cause Corrective Action Ignitor wires (orange) or flame Verify that pilot sense and ignitor leads are not shorted to chas- sense wire (white) is shorted sis ground and the protective covering has not melted or is cut. to chassis ground.
  • Page 15 Frequently Asked Questions/Troubleshooting (continued) Symptom Possible Cause Corrective Action Verify home circuit breaker is on and master reset is on (if No power to Appliance equipped). Check power to appliance or if ECM battery backup is being Power Outage used, install four (4) new AA batteries in backup. IFT-RC400 displays the following message on-screen: Verify selector switch in “Remote”...
  • Page 16 5. IntelliFire Touch Electronic Control Module (IFT-ECM) press and hold the Pilot button for one second and IFT-ECM Detailed Operating Instruction release. The IFT-ECM will flash two green LED blinks, beep twice and light and rectify the pilot flame when 1.
  • Page 17: Risk Of Explosion

    Troubleshooting DANGER With proper installation, operation and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide Risk of Explosion will assist a qualified service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified DO NOT cycle the ON/OFF/REM selector service technician.
  • Page 18 Troubleshooting (continued) Symptom Possible Cause Corrective Action Verify incoming gas line ball valve is ‘Open’. Verify inlet pres- No gas supply. sure is within requirement for gas type used. Contact gas sup- plier. Pilot sparks but does not light, after Verify wiring, check valve harness black wire is securely 90 sec, 3 Red/1 Green Lockout.
  • Page 19: Fcc Compliance Statement

    FCC Compliance Statement: Caution: The Federal Communications Commission warns that changes or modifications not expressly ap- This device complies with part 15 of the FCC Rules. Op- proved by the party responsible for compliance could void eration is subject to the following two conditions: the user’s authority to operate the equipment.
