Hearth and Home Technologies RCT-MLT-IV Installation And Operating Instructions Manual

This is a DRAFT copy and is subject to change. It is not approved for release. DO NOT COPY!
Operating Control
E474962
INTRODUCTION
The remote control system can be operated thermostati-
cally or manually from the transmitter. The system operates
on radio frequencies (RF) within a 20 foot range. Can be
used with DSI, IPI or Standing Pilot systems.
This remote control kit has a hand held transmitter that
can be used as a remote on/off or as a thermostat. The
transmitter display shows the current room temperature,
target temperature, timer setting, on/off status, low bat-
tery indicator, current time, burner/valve operation and
fan operation. Electrical ratings for the receiver are: 110
VAC, 60 Hz, 6 W.
If pertinent, see additional fireplace wiring diagrams on
pages 9 to 11.
INSTALLATION PRECAUTIONS
This remote control kit is tested and safe when installed in
accordance with this installation manual.
Installation of this kit MUST be done by a qualified
service technician.
NOTE: A manometer MUST be used to set the
manifold pressure on the gas valve.
It is the responsibility of the installer to read all instructions
before starting installation and to follow these instructions
carefully during installation. Modification of the remote
control system or any of its components will void the war-
ranty and may cause a fire hazard.
NOTE: The factory installed junction box in the gas
fireplace must be wired with 110 VAC before installing
this kit. See Installation Instructions section.
CAUTION: All wiring should be done by a qualified electri-
cian and shall be in compliance with local codes and with
the National Electric Code ANSI/NFPA No. 70-current (in
the United States), or with the current CSA C22.1 Canadian
Electric Code (in Canada).
WARNING: DO NOT CONNECT 110-120 VAC WIRING
TO THE GAS CONTROL VALVE OF THIS APPLIANCE.
FCC REQUIREMENTS
WARNING: CHANGES OR MODIFICATIONS TO
THIS UNIT NOT EXPRESSLY APPROVED BY THE
PARTY RESPONSIBLE FOR COMPLIANCE COULD
VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
Hearth & Home Technologies • RCT-MLT-IV Remote Control Instructions • 100-908 Rev. D • 12/19
RCT-MLT-IV Remote Control Kits
- Installation and Operating Instructions -
DRAFT
NOTE: This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio TV technician
for help.
Canadian Equipment Requirements
This digital apparatus does not exceed the (Class A/Class
B)* limits for radio noise emissions from digital apparatus
set out in the Radio Interference Regulations of the Cana-
dian Department of Communications.
This device complies with Industry Canada license - ex-
empt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, includ-
ing interference that may cause undesired operation of
the device.
This device complies with RSS 210 of Industry Canada.
This Class B device meets all the requirements of the Ca-
nadian interference causing equipment regulations.
Le present appareil numerique n'emet pas de bruits ra-
dioelectriques depassant les limites applicables aux ap-
pareils numeriques (de la class A/de la class B)* pres-
crites dans le Reglement sur le brouillage radioelectrique
edicte par le ministere des Communications du Canada.
Cet appareil est conforme aux normes RSS exemptes de
licence d'lndustrie Canada.
Le fonctionnement est soumis aux deux conditions suiv-
antes:
(1) Cet appareil ne doit pas causer d'interférences et
(2) Cet appareil doit accepter toute interférence,
y compris les interférences pouvant entratner un fonc-
tionnement indésirable de l'appareil.
Cet appareil est conforme å la norme RSS 210 d'lndustrie
Canada. Cet appareil de classe B respecte toutes les exi-
gences du réglement canadien sur le matériel brouilleur.
1
