JKF8 SeriesSmart Low-Voltage Reactive Power Compensation Controller
Code Definitions Unit
I Current
Voltage
U
Reactive
Q
power
Active
P
power
3

Installation

3.1 Main Features, Outline and Installation Dimensions
+
SET
(120±2)mm
The product is equipped with fire retardant plastic case and digital display. The installation method
of the product is the same as 42L series product. The outline dimensions of the product is 120mm×120
mm×130mm, the installation perforating dimension of the product 113 mm×113mm, the embedding
depth 116 mm.
3.2 Installation Procedure, Method and Product Wiring Diagram
3.2.1 Assembly and fixing of the controller
Table 2 Description of dynamic parameters
Use approximate value when measured value exceeds display range, for
A
example: displays E13 for 1260A.
Displays measured voltage
V
Use approximate value when measured value exceeds display range, for
kvar
example: displays E14 for1360 Kvar
Use approximate value when measured value exceeds display range, for
kW
example: displays E14 for1360 Kvar
-
Figure 1 Outline dimensions of the product
Figure 2 Product installation and fixing
Description
(130±2）mm
03
(109±1)mm
