Installation - CHINT NQ2 Series User Instruction

NQ2 Series Electromagnetic Starter
3

Installation

1) See Fig. 1-Fig. 4 and Table 4 for the outline and installation size of the starter.
NQ2-15
Model
Maximum
outline size 116×207×127
(A×B×C)
Installation size
60×150
(D×E)
n×Φ
Reference picture
C C
Figure 1 Outline and installation size of
NQ2-15, 15N, 15NB
C
Figure 3 Outline and installation size of
NQ2-33
Table 4 Outline and Installation Size
NQ2-15N NQ2-15NB
176×207×127 176×207×127
130×150 130×150
3× 6 Φ
See Fig. 1
D D
A A
D
A
03
NQ2-15P NQ2-33
116×207×138 167×296×162
60×150 105×205
3× 6 Φ 4× 6.2
See Fig. 2 See Fig. 3
C
Figure 2 Outline and installation size of
NQ2-15P
C
Figure 4 Outline and installation size of
NQ2-33P
Unit: mm
NQ2-33P
167×296×172
105×205
Φ 4× 6.2 Φ
See Fig. 4
n×
D
A
n×
D
A
