CHINT JKF8 Series User Instructions page 4

JKF8 SeriesSmart Low-Voltage Reactive Power Compensation Controller
Sampling
overcurrent alarm
Discharge
delay protection
Functions
Circular self-
test function
Safety protection
Installation
method
Sampling and
rated voltage
Overvoltage
threshold setup
Overvoltage
factory preset
Rated frequency
Sampling current
Undercurrent
lock-up
Current
ratio setup
Delay time setup
Technical
Setup mode
parameter
s
Adding
threshold setup
Removing
threshold setup
Circuit number
setup
Operating method
Maximum power
consumption
Tightening torque Terminal screw torque≤2.5N·m
Output contact
capacity
Weight
The overcurrent alarm is triggered when sampling current is bigger than
6.0A.
The switching lock-up time for the same group of capacitors is 3 minutes.
Provides circular self-test function for factory testing of capacitor screen.
IP30
Embedded
380VAC±20%
400V~456V
430V
50Hz±5% or 60Hz±5%
150ｍA~5A, input impedance≤3mΩ
≤150mA
Current ratio setup range for external sampling current transformer: 5~1200, set ratio
(factory preset 60 means 300/5)
5~120 seconds (factory preset 30 seconds)
Full automatic mode (display code 1): no need to set adding threshold and removing
threshold.
Manual setup mode(display code 0): adding threshold and removing threshold need
to be set manually.
Full automatic mode: capacity of the smallest capacitor bank
Manual mode: reactive set value, 1~120kvar(factory preset 10 kvar)
Power factor, 0.85~-0.95 continuously adjustable (factory preset 1.00)
JKF8-6 (1~6 circuits available), JKF8-12(1~12 circuits available)
Automatic circular switching/manual switching
15W
5A/220V (or 3A/380V)
About 1.5Kg
440VAC±20% 220VAC±20%
400V~528V 230V~270V
500V
02
240VAC±20%
240V~300V
250V 270V
≡0
