SETUP INSTRUCTIONS
2011
65 SX
Art. no. 3211682en

Advertisement

loading
Need help?

Need help?

Do you have a question about the 65 SX 2011 and is the answer not in the manual?

Questions and answers

Related Manuals for KTM 65 SX 2011

Summary of Contents for KTM 65 SX 2011

  • Page 1 SETUP INSTRUCTIONS 2011 65 SX Art. no. 3211682en...
  • Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.

  • Page 4: Means Of Representation

    MEANS OF REPRESENTATION Symbols used The symbols used are explained below. Indicates an expected reaction (e.g., to a work step or a function). Indicates an unexpected reaction (e.g., to a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 Mount the footrests with the springs and bolts. Secure the bolts using the washers and pins. Plier for footrest spring (58429083000) – Fill up with fuel. ( p. 6) – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection. 800042-10...
  • Page 6 WORK Raising the motorcycle with a lift stand Note Danger of damage The parked vehicle may roll away or fall over. – Always place the vehicle on a firm and even surface. – Raise the motorcycle at the frame underneath the engine. Lift stand (59229055000) The tires should no longer be in contact with the ground.
  • Page 7 WORK – Operate the hand brake lever several times until the brake linings are in contact with the brake disc. – Loosen screw  – Pull the front wheel brake and push down hard on the fork several times. This aligns the fork legs. –...
  • Page 8 WORK – Position the front fender. Mount and tighten screws  Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) 700414-11 Refueling Danger Fire hazard Fuel is highly flammable. – Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no fuel is spilt, especially on hot vehicle components.

  • Page 9: Technical Data - Chassis Tightening Torques

    TECHNICAL DATA - CHASSIS TIGHTENING TORQUES – Spoke nipple M3.5 3 Nm (2.2 lbf ft) – Remaining nuts, chassis 15 Nm (11.1 lbf ft) – Remaining screws, chassis 10 Nm (7.4 lbf ft) – Screw, ball joint of push rod on foot 10 Nm (7.4 lbf ft) brake cylinder ®...
  • Page 10 2-stroke engine oil According to – JASO FC ( p. 10) Guideline – ® Only use high quality 2-stroke engine oil of a well-known brand. KTM recommends Motorex products. Fully synthetic Supplier ® Motorex – Cross Power 2T Super unleaded gasoline, mixed with 2-stroke engine oil (1:60) According to –...

  • Page 11: Auxiliary Substances

    AUXILIARY SUBSTANCES Long-life grease Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Bike Grease 2000...
  • Page 12 STANDARDS JASO FC JASO FC is a classification for a 2-stroke engine oil that was specifically developed for the extreme demands of racing. Thanks to first rate synthetic esters and specially designed additives, superb combustion is achieved even under extreme operating conditions.
  • Page 13 *3211682en* 3211682en KTM-Sportmotorcycle AG 5230 Mattighofen/Austria http://www.ktm.com...
