SETUP INSTRUCTIONS
2017
65 SX
Art. no. 3213591en

Advertisement

loading

Related Manuals for KTM 65 SX 2017

Summary of Contents for KTM 65 SX 2017

  • Page 1 SETUP INSTRUCTIONS 2017 65 SX Art. no. 3213591en...
  • Page 3 KTM accepts no liability for delivery options, devi- ations from illustrations and descriptions, misprints, and other errors.

  • Page 4: Means Of Representation

    MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 Mount the footrests with the springs and pins. Secure the pins using the washers and cotter pins. Pliers for footrest spring (58429083000) – Fill up with fuel. ( p. 6) – Prepare the vehicle according to the specifications in the KTM Dealer.net for han- dover to the customer. 800042-10...
  • Page 6 WORK Raising the motorcycle with a lift stand Note Danger of damage The parked vehicle can roll away or fall over. – Park the vehicle on a firm and level surface. – Raise the motorcycle at the frame underneath the engine. Lift stand (78929955100) Neither wheel is in contact with the ground.
  • Page 7 WORK –  Mount and tighten screw Guideline Screw, front wheel spindle 40 Nm Loctite ® 243™ (29.5 lbf ft) – Remove the motorcycle from the lift stand. ( p. 4) V00219-11 – Operate the hand brake lever several times until the brake linings are seated cor- rectly against the brake disc.
  • Page 8 WORK Installing the front fender – Position start number plate on the fender.  The holding lugs of the start number plate engage in drill holes of the fender. V00206-10 –  Position fender on the lower triple clamp, mount and tighten screws Guideline Screw, fender 6 Nm (4.4 lbf ft)
  • Page 9 WORK Opening the filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not refuel the vehicle in the vicinity of open flames or lit cigarettes. –...

  • Page 10: Technical Data

    TECHNICAL DATA chassis tightening torques – Spoke nipple M3.5 3 Nm (2.2 lbf ft) – Remaining nuts, chassis 10 Nm (7.4 lbf ft) – Remaining screws, chassis 10 Nm (7.4 lbf ft) Screw, ball joint of push rod on foot 10 Nm (7.4 lbf ft) Loctite ®...
  • Page 11 SUBSTANCES Engine oil, 2-stroke Standard/classification – JASO FD ( p. 11) Guideline – Only use high grade 2-stroke engine oil of a reputable brand. Fully synthetic Recommended supplier Motorex ® – Cross Power 2T Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification –...

  • Page 12: Auxiliary Substances

    AUXILIARY SUBSTANCES Long-life grease Recommended supplier Motorex ® – Bike Grease 2000...
  • Page 13 STANDARDS JASO FD JASO FD is a classification for a 2-stroke engine oil that was specifically developed for the extreme demands of racing. Thanks to first rate synthetic esters and specially designed additives, superb combustion is achieved even under extreme operating conditions.
  • Page 14 *3213591en* 3213591en 09/2016 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
