Yanmar 6LY3 Series Operation Manual
Electronic control system
Hide thumbs
Also See for 6LY3 Series:
- Service manual (390 pages) ,
- Operation manual (136 pages) ,
- Technical manual (87 pages)
Related Manuals for Yanmar 6LY3 Series
Summary of Contents for Yanmar 6LY3 Series
- Page 1 Electronic Control System Operation Manual for 6LY3 Series Engines MANOPLYM01 Revision 2.0 Page 1 Electronic Control System: Operation Manual for 6LY3 Series Engines...
- Page 2 The information contained in this manual is believed to be accurate at the time of going to print but no responsibility, direct or consequential, can be accepted for damage resulting from the use of this information. The manufacturers reserve the right to make changes, without notice, to any of its products. Page 2 Electronic Control System: Operation Manual for 6LY3 Series Engines...
-
Page 3: Table Of Contents
“Unlocking” the Hot Keys ...........................19 User Settings and Factory Settings.......................20 Quad Screen Parameters..........................21 Appendix B: i5601E Menu Navigation ...................22 Appendix C: Default Settings ......................23 Appendix D: Fuses ..........................24 Appendix E: Trouble Codes ......................24 Page 3 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 4: System Overview
Helm Components This dual engine electronic control system consists of the following helm equipment: • Two Yanmar i5601E Digital Displays (one, if single engine) • Dual Shift & Throttle Control Head (single shift & throttle control head, if single engine) Yanmar i5601E Digital Display Note: Displays “Single”... -
Page 5: Start Up
- the light will glow solid. You will have control of the throttle, however, you will NOT have shift control. At this point you must shut the engine off and restart, to return throttle control back to the shift/throttle control head. Page 5 Electronic Control System: Operation Manual for 6LY3 Series Engines... - Page 6 These screens show all of the key engine data and can be accessed by pushing a single button. The right-most button allows the contrast and brightness to be set. Page 6 Electronic Control System: Operation Manual for 6LY3 Series Engines...
- Page 7 The four-left keys can be reconfigured to allow the user to display whatever screens he or she desires. For additional operational details, refer to Appenbdix A and the technical manual. Page 7 Electronic Control System: Operation Manual for 6LY3 Series Engines...
-
Page 8: Shift & Throttle Control Head Functions
4. Return the control handle(s) to the neutral position. 5. Press the Neutral control head button(s). The neutral light(s) will stop flashing and remain continuously lit. Page 8 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 9: Operation
SYNC: Pushing this button engages / disengages the Cruise Synchronization feature when the port and starboard control head levers are set within 10% of each other and are above 20% throttle. Note: Sync is not available on single engine installations. Page 9 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 10: Control Station Selection
(green light on), push the SELECT button and the lamps will dim. If the lamps are still too bright, you can continue pressing the SELECT button to cycle through the lamp intensity choices until you find the desired intensity. Page 10 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 11: Shift Disconnect
Shift Disconnect mode is disengaged and the transmission(s) will now respond to lever commands. Shift Disconnect mode (dual control head) Shift Disconnect mode (single control head) Page 11 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 12: Cruise Synchronization
• Press SYNC button. (Red lamp flashes.) • Match control handle positions within 10% of each other. (Red lamp goes off when levers match — power train sync is now disengaged.) Page 12 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 13: Split Range Throttle
Idle) and again press the N (Neutral) button next to the lever on the control head. The N (Neutral) lamp will stop flashing, indicating that Split Range Throttle has been disengaged.. Page 13 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 14: Trolling Mode (Option)
Trolling switch. Control Lever Range of Operation Trolling Switch ��� Trolling Switch ��� ��� �������� ���� ������� Note: While engaged in Trolling mode, Split Range Throttle (SRT) is not operational. Page 14 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 15: I5601E Digital Display Alarms/Diagnostic Code Screens
HOT KEY Mode, as a dedicated hot key is not required to view these screens. User can hold Right most key down go into the menu mode and then via this menu access the desired screen. Page 15 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 16: Engine Alarms
After an additional 250 hours of operation the maintenance warning will be displayed again, and every 250 hours thereafter. This a reminder that periodic maintenance must be performed at these intervals. Page 16 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 17: Diagnostics
On multi-engine boats the following actions occur on Power Reduction. Condition Engine with Power Reduction Action Sync OFF Either Engines operate independently Sync ON Master Slave slowly matches master Sync ON Slave Master normal, slave slows Page 17 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 18: Appendix A: I5601E Digital Display Setup
The function of a particular softkey changes from screen to screen to whatever is most appropriate for the given screen. Keys NOTE: Any changes to the setup menus may require reconfiguring the i5601E HOT KEY SETUP. Page 18 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 19: Unlocking" The Hot Keys
Pushing the key immediately brings up the selected screen. This mode will not display the right arrow over key 5. Thus the screens are locked when this is selected. This is the factory default setting. Page 19 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 20: User Settings And Factory Settings
Data in NMEA 2000® format must be on the CANBus from an appropriate sensor to allow display of this information. The i5601E display has the capability of displaying additional information as other devices with NMEA 2000® communication capabilities are added to the vessel. Page 20 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 21: Quad Screen Parameters
Data in NMEA 2000® format may be added to the CANBus system from a compatible device which feeds the optional parameters listed above. The i5601E display has the capability of displaying additional information as other devices with NMEA 2000® communication capabilities are added to the vessel. Page 21 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 22: Appendix B: I5601E Menu Navigation
With no pop-up menu showing, briefly press to display the Lighting & Contrast menu. With no pop-up menu showing, press and HOLD to display the MAIN MENU. Page 22 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 23: Appendix C: Default Settings
Note: A system reset may be needed for some changes to take effect. *Only shows when Sync is set to Power Train **Troll Mode functions are not displayed until Troll Mode is selected. Page 23 Electronic Control System: Operation Manual for 6LY3 Series Engines... -
Page 24: Appendix D: Fuses
Throttle Position Sensor Y0033 System Voltage Y0048 Communication Link Y0059 Redundant Throttle Y0070-Y0073 Rack Position Control Y0074 Injection Timing Control Y0088 Control Module Error Y0098 Voltage Supply Y0099 ECU Temperature Page 24 Electronic Control System: Operation Manual for 6LY3 Series Engines...
