Haicom HI-405BT User Manual

Bluetooth gps receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HI-405BT
USER Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HI-405BT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Haicom HI-405BT

Summary of Contents for Haicom HI-405BT

  • Page 1 HI-405BT USER Manual...

  • Page 2: Table Of Contents

    HI-405 Dimension 3. Packaging 3.1 Standard Packaging 3.2 Optional Accessories 4. System Specifications 4.1 Bluetooth Slipper Specifications 4.2 GPS receiver Specifications 5. Get Connected; Installation Guide 5.1 Laptop PC Installations 5.2 PDA Installations 6. GPS Technical Data 6.1 ONE-PULSE-PER-SECOND (1PPS) OUTPUT 6.2 NMEA OUTPUT MESSAGE SPECIFICATIONS...

  • Page 3: Overview

    4. By connecting the optional mini-1394 to PS/II connecting cable, HI-405BT can be used as a regular PS/II GPS receiver. 5. By using the inclusive charger sets, HI-405BT can be charged from DC (car cigarette lighter), AC (home AC power outlet), and the USB port from laptopPC.

  • Page 4: Setting Up

    1.3 Setting up: STEP 1: Unpack the inclusive battery transparent wrap. Put the battery (401-BTT) in the HI-405BT battery cabinet. Tear off the transparent Wrap before using Changeable Battery...
  • Page 5 (stay on) meaning the battery charging. By connecting the Mini-1394 to USB cable (401-USB), HI-405BT can also be charged directly from the laptop PC's USB port. STEP 3: As soon as the battery fully...
  • Page 6 By pressing the power button on the top of HI-405BT (Keep push the power button for 2~3 seconds, the power will turned on), the red light on the side of HI-405BT stay on (the GPS not get 3D fixed yet) and the GPS receiver start searching the satellite data. Please make sure place the HI-405BT outdoor open space without blocking so that it can get the proper satellite signal.
  • Page 7 STEP 5: By the time you press the power button, the blue light in front of HI- 405BT will also blinking (meaning the HI-405BT Bluetooth device is searching the host device and not get paired yet) Please consult the Bluetooth step by step connection guides from this manual section 5.

  • Page 8: Dimensions

    2. Dimensions Top View: Power button Front View Bluetooth Power charging indicator indicator Side View GPS reception status LED Battery cap 29.5 Mini-1394 female connector for power in and GPS signal out Unit: mm Button View: Back View MMCX external antenna plug...

  • Page 9: Packaging

    1. Bluetooth GPS receiver 2. Rechargeable Li-Polymer 3.7V 1600mAh Battery 3. Mini-1394 to USB cable 4. AC Power adaptor with USB female plug 5. Cigarette Lighter Adaptor with USB female plug 6. HI-405BT User Manual 7. Mini CD Model# HI-405BT 401-BTT...

  • Page 11: Optional Accessories

    2. MMCX External Antenna 3. Mini-1394 to PS/II Connecting Cable Model# HOD-001 ATN-MMC PS2-1394 Inside the battery cap, there is a metal plate for using with magnetic car holder to fix HI-405BT on the car front or back windows HOD-001...
  • Page 12 ATN-MMC Under blocking area, the external antenna can extend the signal reception from HI-405BT By connecting to different optional PS2-1394 connecting cables, HI-405BT can be a wired PS/II GPS receiver and used with all kinds of mobile devices.
  • Page 13 By counecting different optional counecting cables, HI-405 can be all kinds of wired GPS receiver solutions.

  • Page 14: System Specifications

    4. System Specifications: 4.1 Bluetooth Slipper Specifications: Bluetooth V1.1 Compliances Frequency Range: Interface: Receiver Sensetivity: Transmitting Power: RF Input Impedance: Frequency hopping: Baseband Crystal OSC: Data Rate: Operating Temperature: Storage Temperature: Supply Voltage: Operation Time: Transmitting Range: Power Consumption: 2.4 ~ 2.4835 GHz unlicensed ISM band USB/UART/SPI -80 dBm @ 0.1% BER...

  • Page 15: Gps Receiver Specifications

    4.2 GPS receiver Specifications: Protocol: Baud Rate: Datum: Channel: Frequency: Hot Start: Warm Start: Cold Start: Reacquisition Time: Position Accuracy: Maximum Altitude: Maximum Velocity: Voltage: Antenna Type: External Antenna Connector: LED Indicator: Operating Temperature: Storage Temperature: Operation Humidity: NMEA0183 GGA, GSA, GSV, RMC, VTG, GLL...

  • Page 16: Get Connected; Installation Guide

    5. Get Connected; Installation Guide 5.1 Laptop PC Installations Run "My Bluetooth Places" and Double Click the "Find Bluetooth Devices " icon Double Click "HAICOM BT GPS" Double Click "SPP on HAICOM BT GPS"...

  • Page 17: Pda Installations

    Key in pin code: “0000” Connected 5.2 PDA Installations Double Click the Bluetooth icon...
  • Page 18 Double click “HAICOM BT GPS” Key in pin code: “0000” Found the host device...
  • Page 19 For Connected with device Start GPS, NMEA message inflow Select the correct com port More satellites info...

  • Page 20: Gps Technical Data

    GPS receiver has valid position fix. The 1PPS output is always generated when the GPS receiver is powered-on. Proper adjustment of the 1PPS output to align with the GPS second requires calculation of the receiver clock offset and clock drift-rate as part of the position-velocity-time (PVT) solution.

  • Page 21: Nmea Output Message Specifications

    SOFTWARE INTERFACE This section describes the details of the serial port commands through which the HI-405BT GPS module is controlled and monitored. The serial port commands allow users to set the receiver parameters, configure output message type, and retrieve status information.
  • Page 22 NMEA Messages The serial interface protocol is based on the National Marine Electronics Association's NMEA 0183 ASCII interface specification. This standard is fully define in "NMEA 0183, Version 3.01" The standard may be obtained from NMEA, www.nmea.org GGA - GPS FIX DATA Time, position and position-fix related data (number of satellites in use, HDOP, etc.).
  • Page 23 Field Example Description 104549.04 UTC time in hhmmss.ss format, 000000.00 ~ 235959.99 2447.2038 Latitude in ddmm.mmmm format Leading zeros transmitted Latitude hemisphere indicator, 'N' = North, 'S' = South 12100.4990 Longitude in dddmm.mmmm format Leading zeros transmitted Longitude hemisphere indicator, 'E' = East, 'W' = West Position fix quality indicator 0: position fix unavailable...
  • Page 24 GLL - LATITUDE AND LONGITUDE, WITH TIME OF POSITION FIX AND STATUS Latitude and longitude of current position, time, and status. Format: $GPGLL,<1>,<2>,<3>,<4>,<5>,<6>,<7>*<8><CR><LF> Example: $GPGLL,2447.2073,N,12100.5022,E,104548.04,A, A*65<CR><LF> Field Example Description 2447.2073 Latitude in ddmm.mmmm format Leading zeros transmitted Latitude hemisphere indicator, 'N' = North, 'S' = South 12100.5022 Longitude in dddmm.mmmm format...
  • Page 25 GSA - GPS DOP AND ACTIVE SATELLITES GPS receiver operating mode, satellites used for navigation, and DOP values. Format: $GPGSA,<1>,<2>,<3>,<3>,<3>,<3>,<3>,<3>,<3>,<3>, <3>,<3>,<3>,<3>,<4>,<5>,<6>*<7><CR><LF> Example: $GPGSA,A,3,26,21,,,09,17,,,,,,,10.8,02.1,10.6*07<CR><LF> Field Example Description Mode, 'M' = Manual, 'A' = Automatic Fix type, 1 = not available, 2 = 2D fix, 3 = 3D fix...
  • Page 26 GSV - GPS SATELLITE IN VIEW Number of satellites in view, PRN number, elevation angle, azimuth angle, and C/No. Only up to four satellite details are transmitted per message. Additional satellite in view information is sent in subsequent GSV messages. Format: $GPGSV,<1>,<2>,<3>,<4>,<5>,<6>,<7>, ...
  • Page 27 RMC - RECOMMANDED MINIMUM SPECIFIC GPS/TRANSIT DATA Time, date, position, course and speed data. Format: $GPRMC,<1>,<2>,<3>,<4>,<5>,<6>,<7>,<8>,<9>,<10>, <11>,<12>*<13><CR><LF> Example: $GPRMC,104549.04,A,2447.2038,N,12100.4990,E, 016.0,221.0,250304,003.3,W,A*22<CR><LF> Field Example Description 104549.04 UTC time in hhmmss.ss format, 000000.00 ~ 235959.99 Status, 'V' = navigation receiver warning, 'A' = valid position 2447.2038 Latitude in dddmm.mmmm format Leading zeros transmitted...
  • Page 28 VTG - COURSE OVER GROUND AND GROUND SPEED Velocity is given as course over ground (COG) and speed over ground (SOG). Format: GPVTG,<1>,T,<2>,M,<3>,N,<4>,K,<5>*<6><CR><LF> Example: $GPVTG,221.0,T,224.3,M,016.0,N,0029.6,K,A*1F<CR><LF> Field Example Description 221.0 True course over ground, 000.0 ~ 359.9 degrees 224.3 Magnetic course over ground, 000.0 ~ 359.9 degrees 016.0 Speed over ground,...
  • Page 29 ZDA TIME AND DATE Format: $GPZDA,<1>,<2>,<3>,<4>,<5>,<6>*<7><CR><LF> Example: $GPZDA,104548.04,25,03,2004,,*6C<CR><LF> Field Example Description 104548.04 UTC time in hhmmss.ss format, 000000.00 ~ 235959.99 UTC time: day (01 ... 31) UTC time: month (01 ... 12) 2004 UTC time: year (4 digit year) Local zone hour Not being output by the receiver (NULL) Local zone minutes Not being output by the receiver (NULL)

  • Page 30: Default Values

    6.3 DEFAULT VALUES The product has the following factory preset default values: Datum: NMEA Enable Switch: Baud Rate: Elevation Mask: DOP Mask: Receiver Operating Mode: The new settings will remain effective on next power-on as long as the on-board rechargeable backup battery is not discharged. After the backup battery is discharged, factory preset default settings will be used.

  • Page 31: Troubleshooting

    Weak or no GPS signal when using HI-405BT indoor or inside the car. Solutions Place the HI-405BT under an open space, then, start GPS again. To try again, go to outdoor and press 'Reset' or connect...
