Artesyn RTM-ATCA-F125 Installation & Use Manual

Rear transition module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RTM-ATCA-F125
Installation and Use
P/N: 6806800K30E
August 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTM-ATCA-F125 and is the answer not in the manual?

Questions and answers

Related Manuals for Artesyn RTM-ATCA-F125

Summary of Contents for Artesyn RTM-ATCA-F125

  • Page 1 RTM-ATCA-F125 Installation and Use P/N: 6806800K30E August 2014...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    4.3.3 SFP Connection ............. . 36 RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 4 Related Documentation ............. . . 45 Artesyn Embedded Technologies - Embedded Computing Documentation ....45 Safety Notes .
  • Page 5 RTM-ATCA-F125 Mechanical Data ........
  • Page 6 List of Tables RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 7 Fabric 10 GB Interconnect ..........37 RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 8 List of Figures RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 9: About This Manual

    RTM and provides some information  on the IPMI functionality of the RTM. Related Documentation lists further Artesyn user manuals that are related to the RTM and  the ATCA-F125. Abbreviations This document uses the following abbreviations:...
  • Page 10 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 11 Chapter 3, Overview, Chapter 4, Functional Description, Safety Notes, Sicherheitshinweise 6806800K30C December 2012 Updated Chapter 1, Standard Compliances, on page 6806800K30D April 2014 Re- branded to Artesyn Template. 6806800K30E August 2014 Updated Declaration of Conformity. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 12 About this Manual About this Manual RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 13: Introduction

    The RTM-ATCA-F125 provides the I/O connection for the ATCA-F125 switch blade towards the back of the system. RTM-ATCA-F125 is directly connected to and powered by the front board. The RTM-ATCA-F125 is a rear transition module (RTM) as defined in PICMG 3.0 Revision 3.0 Advanced TCA Base Specification and PICMG 3.1 Revision 1.0 Specification Ethernet/Fiber...

  • Page 14: Table

    Telcordia GR-63-CORE, NEBS Requirements: Physical Protection. IEC 60950-1 CB Scheme The product complies with IEC 60950-1 CB Scheme including all National Deviations Safety of Information Technology Equipment. Testing shall be by an accredited lab. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 15 The product is designed to comply with the latest version of the Verizon Document VZ.NEBS.TE.NPI.2004.015: NEBS Checklist. To fulfill the requirements of Telcordia GR-1089,R4-14, use Shielded Twisted Pair (STP) cables grounded at both ends to connect to the Ethernet ports. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 16 Guan Road West, Shiqi District, 528400 Zhongshan City Guangdong, PRC Declares that the following product, in accordance with the requirements of 2004/108/EC, 2006/95/EC, 2011/65/EU and their amending directives, Product: ATCA-F125 Series Switch Blade & RTM-ATCA-F125 Series Model Name/Number: ATCA-F125, ATCA-F125-14S, ATCA-F125-14S-C10, ATCA-F125-STD-01-L2, ATCA-F125-STD-02-L2, ATCA-F125-TCLK3, ATCA-F125-TCLK3-C01, RTM-ATCA-F125, RTM-ATCA-F125-C01,...

  • Page 17: Mechanical Data

    Ordering Information The following table lists the blade variants that were available as of the time of writing this manual. Consult your local Artesyn sales representative for the availability of further variants. Table 1-3 Blade Variants - Ordering Information Part Number...
  • Page 18 Introduction RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 19: Hardware Preparation And Installation

    4.4 cfm at 55 °C ambient temperature  Shipment Inspection To inspect the shipment, perform the following steps: 1. Verify that you have received all items of your shipment: Printed Quick Start Guide and Safety Notes Summary  RTM-ATCA-F125  RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 20: Environmental And Power Requirements

    PMC modules, with more restrictive environmental requirements. Operating temperatures refer to the temperature of the air circulating around the blade  and not to the actual component temperature. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 21: Rtm Installation And Removal

    An ATCA RTM shall present less than 0.15 inches water back- pressure at 5 CFM airflow at sea level. RTM Installation and Removal The RTM is fully compatible to the AdvancedTCA standard and is designed to be used in AdvancedTCA shelves. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 22: Installing The Rtm

    In this case it is a purely mechanical installation. Slow down and give blade insertion your full attention! If there are Rear Transition Modules (RTMs) to install, install/secure the RTMs first, then install the front blades. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 23 4. Insert the RTM into the shelf by placing the top and bottom edges of the RTM in the card guides of the shelf. Ensure that the guiding module of the front blade and RTM are aligned properly. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 24 8. Tighten the face plate screws which secure the RTM to the shelf. 9. If the front blade has already been installed (as in step 2), activate the front blade by squeezing its lower lever and latch together and press it back into the face plate. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 25: Removing The Rtm

    The front board blue LED blinks indicating that the blade power-down process is ongoing. Data Loss Removing the blade, with the blue LED still blinking, will cause data loss. Wait until the  blue LED is permanently illuminated, before removing the blade. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 26 4. Unfasten the screws of the RTM face plate until the RTM is detached from the shelf. 5. Unlatch the RTM upper and lower handles and rotate fully outward. Remove the blade from the shelf. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 27: Controls, Leds, And Connectors

    Chapter 3 Controls, LEDs, and Connectors Overview This chapter describes: Face plate connectors  Face plate LEDs  Face Plate Connectors and LEDs The following figure shows the face plate of the RTM. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 28 Controls, LEDs, and Connectors Figure 3-1 Face Plate RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 29: Leds

    Controls, LEDs, and Connectors 3.2.1 LEDs RTM-ATCA-F125 provides four panel-visible LEDs that provide the standard ATCA management LED functions: Red (out of service)  Green (in service)  Blue (hot-swap initializing/ shutting down)  Amber (attention)  RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 30 Controls, LEDs, and Connectors RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 31: Functional Description

    Figure 4-1 Block Diagram Management Resources The RTM-ATCA-F125 does not include its own management controller (MMC) and cannot independently support the ATCA hot-swap protocol. The RTM-ATCA-F125 provides the necessary resources to allow management by the front-blade IPMC. These resources are associated with a dedicated I2C port connected to the front-blade IPMC.

  • Page 32: Fru Serial Eeprom

    4.2.1 FRU Serial EEPROM The RTM-ATCA-F125 provides a 128 Kb (16 K byte) I2C serial EEPROM. This is a 24LC128 type device. The EEPROM resides at I2C address 0xA0. This serial EEPROM is intended to hold FRU data and any additional parameters that are required.
  • Page 33 3.3V. The control for the blue LED is active high. The PROM_SEL signal indicates which bank of FPGA FLASH is currently selected. The FPGA_DONE signal indicates the FPGA load from FLASH is incomplete. The I/O expander resides at I2C address 0x40. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 34: I2C Address Map

    Temperature sensor (top) 0x92 Temperature sensor (middle) 0x94 Temperature sensor (bottom) 0xA0 FRU Serial EEPROM 1 Gbps SFP Ports The RTM-ATCA-F125 provides four 1 Gbps SFP module sites, which are connected to the front- blade base switch. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 35: Connectivity

    The four SFP sites are connected to the front-blade base switch according to the table below.. Table 4-4 Front-Blade Port Mapping RTM Port Front Blade Base Switch Port ETH1 ge20 ETH2 ge21 ETH3 ge22 ETH4 ge23 RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 36: Sfp Connection

    SFP Status Signals The SFP status signals, MOD_ABS, TX_FAULT and LOS, are individually connected to the RTM FPGA to allow monitoring by the service processor. Refer to the Chapter 4, FPGA, on page 40 details. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 37: Sfp Control Signals

    Chapter 4, FPGA, on page 40 details. 10 Gbps SFP+ Ports The RTM-ATCA-F125 provides a total of eight 10 Gbps SFP+ module sites. Six of these connect to the fabric switch on the front-blade and two to the base switch. 4.4.1...

  • Page 38: Front-Blade Port Mapping

    4.4.4 Transmitter Control The TXONOFF signals on each BCM8747 are connected together to the RTM FPGA whichallows them to be driven under software control. This enables software to enable and disable the SFP+ optical outputs. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 39: Bcm8747 Status

    I2C Bus The SFP+ I2C bus signals (I2C_SDA and I2C_SCL) from each SFP+ site are individually connected to the corresponding BCM8747 which includes a mechanism to allow access to the port through the phy management channel. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 40: Sfp+ Status Signals

    The 1PPS, 10MHz, and TOD inputs for connection to an external GPS receiver are not supported at present. FPGA The RTM-ATCA-F125 includes a Xilinx XC3S200A-4 FPGA that which performs the following functions: Access to control and status signals on SFP and SFP+ sites ...

  • Page 41: Front-Blade Interface

    Functional Description 4.6.1 Front-blade Interface The RTM-ATCA-F125 includes an SPI interface between the front-blade service processor and the RTM FPGA. There is also an active low interrupt line to the front-blade to request service. 4.6.2 SFP/SFP+ Control and Status The RTM FPGA provides register access to control the following SFP and SFP+ signals: SFP TX_DISABLE ...

  • Page 42: Sfp I2C Interface

    Register settings allow access to be granted to either BCM8747 and also provide a programming port. 4.6.7 FPGA Register Map Details of the FPGA register map are included in the RTM FPGA section of the ATCA-F125 FPGA design guide. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 43: Fpga Configuration

    +3.3 V management power – one pin  +12 V payload power – four pins  The maximum current draw, which is limited by the pin’s current handling capability, is 0.8A for the management power and 3.2A for the payload power. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 44: Power-Good Indication

    Since this signal comes from the FPGA, it also serves as an indication that the FPGA configuration has completed. 4.8.2 Power Requirements The table below summarizes the power requirements of the RTM-ATCA-F125. Table 4-9 Power Requirements Voltage Maximum Current +3.3V Management...

  • Page 45: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 46 Related Documentation RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 47: Safety Notes

    Artesyn intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 48 Changes or modifications not expressly approved by Artesyn could void the user's authority to operate the equipment. Board products are tested in a representative system to show compliance with the above mentioned requirements.
  • Page 49 Safety Notes Artesyn and our suppliers take significant steps to ensure there are no bent pins on the backplane or connector damage to the blades/RTMs prior to leaving the factory. Bent pins caused by improper installation or by inserting blades with damaged connectors could void the Artesyn warranty for the backplane or blades.
  • Page 50 SFP/SFP+ module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP/SFP+ module. When no cable is connected, cover the port with an optical port plug. RTM-ATCA-F125 Installation and Use (6806800K30E)

  • Page 51: Sicherheitshinweise

    Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die Vollständigkeit der im Handbuch enthaltenen Informationen nicht garantieren. Falls Sie weitere Informationen benötigen sollten, wenden Sie sich bitte an die für Sie zuständige Geschäftsstelle von Artesyn. Das System erfüllt die für die Industrie geforderten Sicherheitsvorschriften und darf ausschließlich für Anwendungen in der Telekommunikationsindustrie und im Zusammenhang...
  • Page 52 Sicherheitshinweise Das Produkt wurde in einem Artesyn Standard system getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten...
  • Page 53 Pins und Stecker von Blades/RTMs vor dem Verlassen der Produktionsstätte in einwandfreiem Zustand befinden. Verbogene Pins, verursacht durch fehlerhafte Installation oder durch Installation von Blades/RTMs mit beschädigten Steckern kann die durch Artesyn gewährte Garantie für Blades und Backplanes erlöschen lassen.
  • Page 54 Die Installation und der Betrieb von SFP/SFP+-Modulen, welche nicht zertifiziert sind und welche nicht den Sicherheitsstandards entsprechen, kann Verletzungen zur Folge haben sowie zur Beschädigung des RTMs und von SFP/SFP+-Modulen führen. Verwenden Sie daher nur SFP/SFP+-Module, die zertifiziert sind und die den Sicherheitsstandards entsprechen. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 55 Die Schutzkappe eines SFP/SFP+-Modules dient dazu, die sensible Optik des SFP/SFP+- Modules gegen Staub und Schmutz zu schützen. Entfernen Sie die Schutzkappe nur dann, wenn Sie beabsichtigen, ein Kabel anzuschließen. Andernfalls belassen Sie die Schutzkappe auf dem SFP/SFP+-Modul. RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 56 Sicherheitshinweise RTM-ATCA-F125 Installation and Use (6806800K30E)
  • Page 58 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2014 Artesyn Embedded Technologies, Inc.
