simalube IMPULSE quick instruction guide for installation, removal,
re ll and disposal
Calculation and preparation of lubrication point
Use „Calculation Pro" to choose correct dispensing
time and lubricator size.
("Calculation Pro" is available at www.simatec.com, in the App Store, and
in the Android Market.)
Install and activate simalube and IMPULSE
Connect hose to
mounting bracket
Write in activation date
simatec ag
Stadthof 2
CH-3380 Wangen a. Aare
All manuals and user guides at all-guides.com
Clean lubrication point
Seal IMPULSE and screw onto
lubrication point
IMPULSE logo must face the front
Insert the battery pack
Tel.: +41 (0)32 636 50 00
Fax.: +41 (0)32 636 50 19
welcome@simatec.com
www.simatec.com
Remove connector nipple and
screw in quick connection
coupling
Cut off plug from lubricator or
remove green plug
Screw on lubricator, device will be activated,
device will be activated,
green LED will blink 2x.
green LED will blink 2x.
The rst pump
The rst pump
cycle will begin within 30 seconds
Connect hose and pre ll
with a grease gun
( ll tubes completely)
Activate calculated dispensing
time with 3 mm Allen key
Check simalube and
IMPULSE regularly
