- Page 1 Embrace Owners Manual Cool Mist Humidifier | VUL900 Series VUL900 SERIES...
-
Page 2: Important Safety Instructions
17. DO NOT add any essential oils or medications cian. DO NOT attempt to defeat this safety feature. (e.g. Vicks VapoSteam®) into the Water Reservoir or CAUTION: To avoid fire or risk of electrical shock Water Tank. Doing so could damage the humidifier hazard, plug the humidifier directly into a 120V AC and void the warranty. -
Page 3: How Your Humidifier Works
How Your Humidifier Works The Vicks Embrace Ultrasonic Cool Mist Humidifier is designed to quietly provide visible cool mist and comforting cough and cold relief. This filter free humidifier has a built-in nebulizer that quietly vibrates the water at an ultrasonic frequency, breaking the water droplets into a fine, cool mist that you can see and feel. The mist helps reduce respiratory and dry air discomforts by increasing humidity levels to help you breathe better and sleep more comfortably. VUL900 SERIES... -
Page 4: Product Description
Product Description Components Mist Outlet Tank Handle Chimney Water Tank Water Reservoir Power Recess Base VapoPad Door Nebulizer Humidity Display Panel Light ON/OFF Timer Humidity Control Mist Control Power Air Filter Door NOTE: The lights on the control panel will illuminate when you touch the panel. After you finish interacting with the panel, the lights will automatically dim within a few seconds. VUL900 SERIES... -
Page 5: Setting Up Your Humidifier
Setting Up Your Humidifier 1. Remove packaging materials. 2. Remove twist tie and extend power cord. 3. P lace on a firm, level, and water-resistant surface, 12 inche s (30cm) a minimum of 12 inches (30cm) from any walls. VUL900 SERIES... - Page 6 Water Tank: under the faucet at the sink, or with a pitcher of water at the humidifier. 1. I f filling at the sink, turn the humidifier off, then open Tank lid to reveal the handle, remove Tank from Base, carry to sink and fill. I f filling at the humidifier, ensure Tank is securely seated on Base. Open Tank lid and fill using a water pitcher. NOTE: Fill Tank with cool water. DO NOT fill with warm or hot water. DO NOT ADD ESSENTIAL OILS, MEDICATIONS, OR INHALANT LIQUIDS, such as Vicks VapoSteam, to the Tank. Doing so could cause damage to the humidifier and void the warranty. 2. Close the Tank lid. 3. If filled at the sink, carry the full Tank back using two hands and place back in the Water Reservoir on the Base. For proper placement, line up the chimney and nozzle to the VICKS logo. NOTE: When taking your Tank to and from the sink, carry the Tank using two hands. Manufacturer/Distributor will not accept responsibility for property damage caused by water spillage.
-
Page 7: Operating The Humidifier
Operating the Humidifier Power: Plug the humidifier into a polarized 120V outlet. Auto Mode: Your humidifier is equipped with an Press the Power Recess to turn the humidifier on. Auto Mode that allows for effortless humidification. The Power icon will illuminate white when the device When first powered ON, the humidifier will start in the is on. Auto Mode. The humidifier will automatically set the humidity output level based on the ambient relative CAUTION: TO AVOID ELECTRIC SHOCK DO NOT humidity in the room. When the humidity level is low, PLUG HUMIDIFIER INTO OUTLET WITH WET HANDS. the humidifier will add more moisture to the air at a faster rate by automatically using the Turbo Mist feature. If the Power icon turns an amber color, this indicates The target humidity level in the Auto Mode is 60%. that the Reservoir water level is low or the Tank is not Once the humidity reaches 60%, the humidifier will stop set in place. Check the water level and fill if necessary, producing mist while continuing to monitor the humidity and ensure the Tank is properly seated. level around the device. NOTE: If the Tank is refilled at the humidifier when the Power icon is amber, it will need to be reset. Either power OFF then ON or remove and replace the Tank. This will activate the water flow to the Reservoir and turn the Power icon white to indicate normal operation. - Page 8 Operating the Humidifier (Cont.) Humidity Level Setting: As an alternative to using The timer is ON when the indicator above the the Auto Mode, you can set your preferred humidity Timer icon is illuminated in white. To turn the timer level manually. Select the Low, Medium or High mist OFF, touch and hold the Timer icon for 2 seconds, level, then use the Humidity Control arrows to set or use the Humidity Control arrows to decrease the your desired humidity level. You can set the humidity time setting to level from 30% to 69%. For personal comfort, the NOTE: While the timer is running, the humidifier will continue recommended humidity level is between 40-60%. to cycle ON and OFF to maintain the set humidity level. At the end of the timed cycle, the humidifier will power OFF, I f the humidity level in your space drops below regardless of the humidity setting. If the humidifier is manually 30%, the Display will show turned off by pressing the power button or by unplugging the humidifier, the timer will reset to OFF. I f the humidity level rises above 69%, the Display will show Adjust the humidity level up or down as desired. Panel Lights: To turn the panel lights OFF, press the Panel Light icon . The Power icon will remain illuminated as a reminder that the device is still on. Humidity Reached Icon: When the desired humidity To turn the panel lights back ON, touch the panel.
- Page 9 Using Vicks VapoPads Your humidifier can be used with Vicks VapoPads to provide up to 8 hours of soothing vapors. One free sample of the menthol VapoPad is included with your humidifier. To use VapoPads with your humidifier: 1. Press and release the VapoPad door on the humidifier base to open. 2. O pen the VapoPad packaging by tearing the notch. DO NOT touch the pad with your hands. If you touch the pad, simply wash your hands. Avoid rubbing your face or eyes as the oils may cause irritation. 3. I nsert the Vicks VapoPad angled-end first. Up to 2 VapoPads can be inserted. Close the door. 4. After 8 hours, discard the VapoPad(s). VapoPads Recommended Usage CAUTION: Contact with exposed pad may cause eye irritation. In case of contact with eyes, flush with water immediately. If eye irritation persists, consult a doctor. DO NOT touch exposed pad with skin. In case of contact with skin, wash area immediately with plenty of water. DO NOT add any liquids to the pad or use more than one pad per slot at a time. For scent only, pad is not to be taken internally. WARNING: DO NOT ADD LIQUID INHALANTS, WARNING: Pad may present a choking hazard.
-
Page 10: Care And Cleaning
Care and Cleaning Before Cleaning For best results, use fresh clean water every day. 1. Turn OFF and unplug the humidifier. Remove When the humidifier is not in use, it is recommended any accessories. that you empty the Tank and Water Reservoir and let 2. R emove the Tank from the Base. Empty water them air dry. from Tank and Water Reservoir. To keep your humidifier running efficiently, clean it regularly. Weekly cleaning is recommended. Prefer a short video instruction? To properly clean your humidifier, it is recommended Scan here for cleaning videos: to follow the separate processes of Scale Removal and Disinfecting (next page). - Page 11 Care and Cleaning (Cont.) Instructions for Scale Removal 1. P our 2 cups of undiluted, distilled white vinegar into the Water Reservoir. 2. Pour 1 cup of undiluted, distilled white vinegar into the Water Tank, to cover the bottom of the Tank. Gently swish vinegar around in the Tank. Place Tank on Base. 3. A llow the vinegar to remain in Water Reservoir and Tank for 20 minutes. The vinegar will loosen mineral buildup on the Nebulizer, Water Reservoir and underside of the Tank. 4. A fter soaking, remove the Tank and empty vinegar from the Water Reservoir and Tank into the sink. With a soft cloth, wipe the Nebulizer, Water Reservoir and the underside of the Tank to remove mineral buildup. 5. R inse Water Reservoir, inside of Tank and underside of Tank with water until the smell of vinegar is gone. When rinsing Reservoir, avoid getting water into any other openings on the Base. CAUTION: DO NOT submerge Base in water. Doing so will damage the humidifier and void the warranty.
- Page 12 Care and Cleaning (Cont.) Instructions for Disinfecting 1 tsp. Bleach Before beginning disinfection, follow Steps 1-2 in “Before Cleaning” section (previous page). 1 Gallon Water NOTE: Bleach may stain clothes. It is recommended that you wear rubber gloves during the disinfection process to protect your hands. 1. A dd 1 tsp. of bleach to 1 gallon (3.8L) of water. Fill the Water Reservoir with part of the solution, about 2 cups. Pour the rest of the solution into Tank. Close Tank lid. Gently swish solution around in Tank. Place Appr ox. Rest of 2 cups of Solution Tank on Base. Solution NOTE: DO NOT use more than 1 tsp. of bleach per gallon of water; using more bleach may result in damage to your humidifier. 2. A llow the bleach solution to remain in Tank and Water Reservoir for 20 minutes.
-
Page 13: Air Filter Cleaning
Air Filter Cleaning It is recommended that when you disinfect your unit, you also inspect the Air Filter and clean if needed using the following instructions: 1. Turn OFF and unplug the humidifier. 2. R emove the Air Filter door by pushing the locking tab on the right side of the door toward the center of the unit and gently pulling outward. 3. R emove black Air Filter by lifting it out from the door. 4. Rinse Air Filter under cold water. 5. B lot Air Filter dry with a paper towel. Ensure Air Filter is completely dry before reinstalling. If it is damp, it will affect the humidity sensor. 6. W hen returning Air Filter to door, ensure filter is full seated. 7. R eattach Air Filter door by placing the alignment-tabs first, and then snapping the locking tab in place as the door closes. VUL900 SERIES... -
Page 14: Troubleshooting
Troubleshooting If your humidifier is not working properly, try the following solutions: Problem Possible Cause Solution Power Light remains • Humidifier not plugged in • P lug humidifier in OFF after pressing the • No power at outlet • C heck home circuits, fuses; Power button test outlet Power is ON and light is • Mineral deposits in Water • Clean Humidifier white but little or no mist is Reservoir •... -
Page 15: Accessories (Not Included)
Vicks VapoPads Protec Antimicrobial ® Cleaning Products (One menthol VapoPad sample included) Use Vicks VapoPads with your humidifier for soothing vapors. These products feature an antimicrobial, Aquastat ® Enjoy up to 8 hours of soothing comfort per pad. which helps keep your humidifier cleaner, longer. -
Page 16: Year Limited Warranty
2 Year Limited Warranty Read all instructions before attempting to B. A t its option, KAZ will repair or replace this use this product. product if it is found to be defective in material or workmanship. C. T his warranty does not cover damage resulting from A. T his 2 year limited warranty applies to repair or any unauthorized attempts to repair or from any use replacement of product found to be defective in not in accordance with the instruction manual. material or workmanship. This warranty does not apply to damage resulting from commercial, D. T his warranty does not cover the filters, pre-filters, abusive, unreasonable use or supplemental damage. UV bulbs or other accessories (if included) except for Defects that are the result of normal wear and material or workmanship defects. tear will not be considered manufacturing defects under this warranty. Call us toll-free at 1-800-827-6712 or send us a KAZ IS NOT LIABLE FOR INCIDENTAL OR message on our Contact Us page, CONSEQUENTIAL DAMAGES OF ANY NATURE. - Page 17 Compliance and Ratings This device complies with Part 18 Electrical Ratings of the FCC rules. Capacity: 1.2 gallons (4.5 L) Electrical Rating: 120V, 60 Hz. 0.4A. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply within the limits for Consumer ISM equipment, pursuant to Part 18 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference with radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna.
-
Page 18: Contact Information
Contact Information Consumer Relations For questions, technical support or to order replacement parts, contact Consumer Relations. Call us toll-free at: 1-800-VAPOR-1-2 (1-800-827-6712) Hours: Mon-Fri 8:00AM-6:00PM EST www.VicksHumidifiers.com/Contact-Us Please be sure to specify model number VUL900. © 2021 All Rights Reserved. Manufactured by: KAZ USA, Inc., a Helen of Troy Company 400 Donald Lynch Blvd., Suite 300 Marlborough, MA 01752 Certain trademarks used under license from The Procter & Gamble Company or its affiliates. Protec is a registered trademark owned by ® Helen of Troy Limited. Aquastat is a registered trademark of ® K2 Concepts Inc., Atlanta GA. Made in China For responsible recycling, please visit: www.RecycleNation.com VUL900 SERIES...
