Generac Power Systems Transfer Switches and Accessories Product Catalog page 12

Product Specifications
air-Cooled
Model 05526 05528 05530
Rated Power (LPG/NG) 8/7 kW 10/9 kW 14/13 kW
Voltage (Single-Phase) 120/240V 120/240V 120/240V
Amps @ 240V LPG 33.3 41.6 58.3
Amps @ 240V NG 29.2 37.5 54.2
Engine/Alternator RPM 3600/3600 3600/3600 3600/3600
Engine OHVI / 410cc OHVI / 530cc OHVI / 992cc
Fuel Consumption LPG 62 (1.68) 70 (1.93) 84 (2.30)
Fuel Consumption NG 140 156 220
Quiet-Test Low Speed Exercise No No No
db(A) at Exercise 62 63 66
db(A) at Normal Operating Load 62 63 66
Enclosure Steel Steel Steel
Enclosure Color Bisque Bisque Bisque
Dimensions (L" x W" x H") 48 x 24 x 28.25 48 x 24 x 28.25 48 x 24 x 28.25
Generator Weight (lbs.) 336 375 425.5
portable
Series GP1800 GP3250
Model # 5723 5724
Running Watts 1800 Watts 3250 Watts
Starting Watts 2050 Watts 3750 Watts
Engine Size and Type 163cc OHV 206cc OHV
Pressure Lube w/Filter No No
Starting Method Recoil Recoil
Battery Included N/A N/A
Covered Outlets No No
2x5-20R 4x5-20R
Outlets
Hour Meter w/ Maintenance Resets No No
Low-Oil Shutdown Low Level Low Level
Fuel Tank Type and Size Steel, 4.0 Gal Steel, 4.0 Gal
Run Time at 50% 14 Hours 13.5 Hours
Cord Set Included No No
Handles N/A Folding
First Oil Included Yes Yes
Maintenance Kit Included No No
Emission Certified 49 States 49 States
CSA Certified Model Availability 1st Quarter 2009 1st Quarter 2009
Warranty 2 Year Limited 2 Year Limited
Dimensions (L" x W" x H") 23.5 x 17 x 17.5 25.5 x 21 x 19
Product Weight (lbs.) 90.5 101.5
Availability 4th Quarter 2008 4th Quarter 2008
* California Emission Model California models available 4th Quarter 2008 California models available 1st Quarter 2009
1 2
All portable specifications and models subject to change. Please consult factory for availability.
12
05531 05532 05533 Series
3
17/16 kW 17/16 kW 20/18 kW
Rated Power LP
120/240V 120/240V 120/240V
Rated Power NG
70.8 70.8 83.3
Amps @ 240V, 1 Ø LP
66.6 66.6 75
Amps @ 208V, 3 Ø LP
3600/3600 3600/3600 3600/3600
Amps @ 240V, 3 Ø LP 1
OHVI / 992cc OHVI / 992cc OHVI / 999cc
Amps @ 480V, 3 Ø LP
94 (2.57) 94 (2.57) 106 (2.90)
Engine/Alternator RPM
261 262 294
Engine Size
Yes Yes Yes
Cylinder Arrangement
60 60 60
66 66 66 Fuel Consumption LPG
Steel Aluminum Aluminum
Fuel Consumption NG
Bisque Gray Gray
Quiet-Test Low Speed Mode
48 x 24 x 28.25 48 x 24 x 28.25 48 x 24 x 28.25
db(A) at Exercise
445 414 451
db(A) at Normal Operating Load
Transfer Switch Type Needed
Enclosure Material
Enclosure Color
Dimensions (L" x W" x H")
Generator Weight Steel (lbs.)
Generator Weight Aluminum (lbs.)
* California emission compliant model. Must specify with
"Y" at end of typecode when ordered.
** Height does not include measurement of exhaust stack(s).
*** All specifications subject to change without notice.
GP5500 GP6500 GP7000 GP7000E
5736/5737* 5623/5700* 5625
5500 Watts 6500 Watts 7000 Watts 7000 Watts
6875 Watts 8000 Watts 8750 Watts 8750 Watts
389cc OHV 389cc OHV Generac 410cc OHVI Generac 410cc OHVI
No No Yes
Recoil Recoil Recoil Electric/Recoil
N/A N/A N/A
No No No
4x5-20R 4x5-20R 4x5-20R 4x5-20R
1xL14-30R 1xL14-30R 1xL14-30R 1xL14-30R
Yes Yes Yes
Low Level Low Level Low Pressure Low Pressure
Steel, 6.6 Gal Steel, 6.6 Gal Steel, 8.0 Gal Steel, 8.0 Gal
10 Hours 9 Hours 11 Hours 11 Hours
No No No
Fold Down/Locking Fold Down/Locking Fold Down/Locking Fold Down/Locking
Yes Yes Yes
No No No
50 States 50 States 49 States 49 States
1 1
Yes Yes Yes
2 Year Limited 2 Year Limited 2 Year Limited 2 Year Limited
33.5 x 26.5 x 27.5 33.5 x 26.5 x 27.5 33.5 x 26.5 x 27.5 33.5 x 26.5 x 27.5
180 185 190
4th Quarter 2008 Available Now Available Now Available Now
liquid-Cooled
QT02224 QT02516 QT02724 QT03016
22 kW 25 kW 27 kW 30 kW
22 kW 24 kW 25 kW 29 kW
91.6 104.2 112.5 120.8
76 86.8 94 104.2
N/A N/A N/A N/A
N/A N/A N/A N/A
1800/1800 3600/3600 1800/1800 3600/3600
2.4L 1.6L 2.4L 1.6L
In-line 4 In-line 4 In-line 4 In-line 4
120 (3.3) 175 (4.81) 149 (4.1) 209 (5.7)
316 437 359 525
Yes Yes Yes Yes
61 62 61 62
70 74 70 75
RTS RTS RTS RTS
Aluminum Steel Aluminum Steel
Gray Bisque Gray Bisque
62.2 x 29 x 33.5 62.2 x 29 x 33.5 62.2 x 29 x 33.5 62.2 x 29 x 33.5
N/A 875 N/A 935
843 N/A 891 N/A
1 Consult factory for availability
2 California emission compliant model weight
3 See product selection guide to customize your generator
GP8000 GP8000E GP10000E
5626 5680 5681 5739
8000 Watts 8000 Watts 10000 Watts
10000 Watts 10000 Watts 15000 Watts
Generac 410cc OHVI Generac 410cc OHVI Generac 530cc OHVI
Yes Yes Yes Yes
Recoil Electric/Recoil Electric
Yes N/A Yes Yes
No No No No
GFCI 4x5-20R
4x5-20R 4x5-20R 1xL5-30R
1xL14-30R 1xL14-30R 1XL14-30R
1X14-50R
Yes Yes Yes Yes
Low Pressure Low Pressure Low Pressure
Steel, 8.0 Gal Steel, 8.0 Gal Steel, 10.0 Gal
8 Hours 8 Hours 10 Hours
No No No No
Fold Down/Locking Fold Down/Locking Fold Down/Locking
Yes Yes Yes Yes
No No No No
49 States 49 States 49 States
No No Yes No
2 Year Limited 2 Year Limited 2 Year Limited
33.5 x 26.5 33.5 x 26.5
33.5 x 22 x 27.5
x 27.5 x 27.5
195 200 205 300
Available Now Available Now 2nd Quarter 2009
QT03624 QT04524* QT04842* QT06024 QT07068
36 kW 45 kW 48 kW 60 kW 70 kW
35 kW 45 kW 45 kW 60 kW 68 kW
150 187.5 200 250 291.6
125 156.3 167 208.4 243.1
108 135.4 144 180.6 210.7
54 67.7 72 90.3 105.3
1800/1800 3600/3600 1800/1800 3600/3600 1800/1800
2.4L 2.4L 4.2L 2.4L 6.8L
In-line 4 In-line 4 V-6 In-line 4 V-10
199 (5.4) 286 (7.86) 261 (7.2) 332 (9.0) 411 (11.3)
480 720 661 862 1020
Yes Yes Yes Yes Yes
58 61 60 63 61
64 73 65 71 65
RTS RTS RTS RTS HTS
Aluminum Steel Aluminum Steel Steel or Alum
Bisque Bisque Gray Tan Tan
77 x 33.5 x 45 77 x 33.5 x 45 77 x 33.5 x 45 89 x 34 x 48 96.5 x 37 x 48
N/A 1414/1464 2 N/A 1650 2185
1683 N/A 1740/1790 1650 2040
2
GP15000E GP17500E XP4000
5734 5735 5604/5713*
15000 Watts 17500 Watts 4000 Watts
22500 Watts 26250 Watts 5000 Watts
Generac 992cc OHVI Generac 992cc OHVI Generac 220cc OHVI
Yes Yes Yes
Electric Electric Recoil
Yes Yes N/A
No No Yes
2x5-20R 2x5-20R
GFCI 2x5-20R GFCI 2x5-20R
2xL5-30R 2xL5-30R
GFCI 4x5-20R
1xL14-30R 1xL14-30R
1xL14-20R
1x14-50R 1x14-50R
1x10A 12Vdc 1x10A 12Vdc
Yes Yes Yes
Low Pressure Low Pressure Low Pressure
Resin, 16.0 Gal Resin, 16.0 Gal Steel, 5.0 Gal
10 Hours 10 Hours 12 Hours
No No 20' 20A
Fixed, D-Style Fixed, D-Style Fold Down/Locking
Yes Yes Yes
Yes Yes Yes
50 States 50 States 50 States
2
No No Yes
2 Year Limited 2 Year Limited 3 Year Limited
48.5 x 30.75 x 38.5 48.5 x 30.75 x 38.5 29.25 x 23.5 x 26
373 400 195
1st Quarter 2009 1st Quarter 2009 1st Quarter 2009
Product Specifications
QT08046 QT10068* QT13068 QT15068
80 kW 100 kW 130 kW 150 kW
78 kW 97 kW 130 kW 150 kW
333.3 416.6 541.6 625
277.9 347.3 451.5 521
240.8 301 391.3 451.5
120.4 150.5 195.6 225.7
3600/3600 2300/1800 3000/1800 3600/3600
4.6L 6.8L 6.8L 6.8L
V-8 V-10 V-10 V-10
465 (12.78) 507 (13.9) 719.8 (19.56) 830.6 (22.6)
1154 1260 1786 2061
Yes Yes Yes Yes
64 61 65 66
74 72 75 79
HTS HTS HTS HTS
Steel or Alum Steel or Alum Steel or Alum Steel or Alum
Tan Tan Tan Tan
116 x 37 x 55** 116 x 37 x 55** 116 x 37 x 55** 116 x 37 x 55**
2010 2705/2755 2 2873 2666
1836 2531/2581 2699 2492
2
XP8000E XP10000E
5606/5712* 5607
8000 Watts 10000 Watts
12000 Watts 15000 Watts
Generac 410cc OHVI Generac 530cc OHVI
Yes Yes
Electric/Recoil Electric
Yes Yes
Yes No
GFCI 4x5-20R
GFCI 4x5-20R
1xL5-30R
1xL14-30R
1x14-50R
Yes Yes
Low Pressure Low Pressure
Steel, 8.0 Gal Steel, 10.0 Gal
8 Hours 10 Hours
20' 30A No
Fold Down/Locking Fold Down/Locking
Yes Yes
Yes Yes
50 States 49 States
1
Yes Yes
3 Year Limited 3 Year Limited
32.5 x 26 x 29 35 x 28 x 36
255 300
Available Now 1st Quarter 2009
13
