Delem DA-66T Reference Manual page 93

Parameter explanation
Product ID
A unique name to identify a product program. The maximum length is 25 characters.
The product ID may contain letters and numbers.
Product description
A number or description of this program. The maximum length is 25 characters. The
product description may contain letters and numbers.
Angle selection
Selection of the programming mode for the Y-axis.
0 = absolute: program the absolute Y-axis position for a bend.
α:
1 = program the angle to bend. The required Y-axis position is computed.
Depending on this parameter, either the parameter Angle or the parameter Bend
Position will appear in a bend step.
Thickness
Thickness of the sheet.
Material
Selection of one of the programmed materials, which are used to calculate the bending
depths. The control contains 6 pre-programmed materials. In total, 99 materials can be
programmed on the control. The materials can be programmed on the Materials page in
the Settings mode.
1 = Steel
2 = Aluminium
3 = Zinc
4 = Stainless steel
5 = Material 5
6 = Material 6
Blank length
The required length of the original sheet from which the product is bent. If the program
has been processed from a 2D drawing, this value has been calculated.
Connect
The parameter "connect" is to have a possibility to connect certain programs to one
another. This option can be used to produce 3-dimensional products out of two
programs.
The main screen shows the available bends and from this main screen, from every available
bend, specific paremeters can be viewed and edited.
E-MODULE TENSILE
(N/mm²) STRENGTH
(N/mm²)
210.000 400
70.000 200
94.000 200
210.000 700
210.000 400
210.000 400
V0913, 6.3
