SERVICE MANUAL
RADIO RECEIVER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
U<B>(S/M Code No.09-003-339-0T1)
EZ<B>,LH<B,W>(S/M Code No.09-003-339-0T2).
All manuals and user guides at all-guides.com
FR-A150
S/M Code No. 09-003-339-0R1
U(B),EZ(B),
LH(B,W)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-A150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa FR-A150

Summary of Contents for Aiwa FR-A150

  • Page 1 All manuals and user guides at all-guides.com FR-A150 U(B),EZ(B), LH(B,W) SERVICE MANUAL RADIO RECEIVER This Service Manual is the “Revision Publishing” and replaces “Simple Manual” U<B>(S/M Code No.09-003-339-0T1) EZ<B>,LH<B,W>(S/M Code No.09-003-339-0T2). S/M Code No. 09-003-339-0R1...

  • Page 2: Specification

    All manuals and user guides at all-guides.com SPECIFICATION • Design and specifications are subject to change without notice. ACCESSORIES LIST REF. NO PART NO. KANRI DESCRIPTION 1 8A-RUA-901-010 IB,U(3L)C<U<B>> 1 8A-RUA-904-010 IB,LH(3L)C<LH<B>,LH<W>> 1 8A-RUA-905-010 IB,EZ(EGF)C<EZ<B>> 1 8A-RUA-906-010 IB,EZ(SID)C<EZ<B>> 1 8A-RUA-907-010 IB,EZ(PHNCZ)C<EZ<B>>...

  • Page 3: Electrical Main Parts List

    All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 8A-RUA-623-010 COIL,AM OSC A106 RED 8A-RUA-625-010 COIL,FM ANT4.5*4.5T 8A-RUA-605-010 IC,CXA1619BS 87-003-050-010 CHOKE COIL,47UH 87-A21-201-010 IC,LM8560N 87-003-050-010 CHOKE COIL,47UH 87-003-050-010 CHOKE COIL,47UH TRANSISTOR...

  • Page 4: Schematic Diagram

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-1 <U Model>...
  • Page 5 All manuals and user guides at all-guides.com CIRCUIT BOARD DIAGRAM-1 (MAIN C.B) <U Model> MAIN C. B PVC1 VC-1~VC-4 TC-1~TC-4...
  • Page 6 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-2 <EZ Model>...
  • Page 7 All manuals and user guides at all-guides.com CIRCUIT BOARD DIAGRAM-2 (MAIN C.B) <EZ Model> MAIN C. B PVC1 VC-1~VC-4 TC-1~TC-4...
  • Page 8 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-3 <LH Model>...
  • Page 9 All manuals and user guides at all-guides.com CIRCUIT BOARD DIAGRAM-3 (MAIN C.B) <LH Model> MAIN C. B PVC1 VC-1~VC-4 TC-1~TC-4...
  • Page 10 All manuals and user guides at all-guides.com WIRING...

  • Page 11: Block Diagram

    All manuals and user guides at all-guides.com CIRCUIT BOARD DIAGRAM-4 (FUNCTION, SNOOZE C.B) SNOOZE C. B SW54 FUNCTION C. B SW59 SW57 SW58 SW56 SW55 BLOCK DIAGRAM MAIN C. B FUNCTION C. B SNOOZE C. B...

  • Page 12: Electrical Adjustment

    All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENT MAIN C. B (SP–) (SP+) (GND) (FM IF INPUT) 1. AM IF Adjustment 4. FM IF Adjustment T2 ................. 450 kHz T1 ................107 MHz 2. AM Freq. Range Adjustment <U Model> 5.

  • Page 13: Ic Block Diagram

    All manuals and user guides at all-guides.com IC BLOCK DIAGRAM IC, CXA1619BS IC, LM8560N...

  • Page 14: Mechanical Exploded View

    All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1/1...

  • Page 15: Color Name Table

    All manuals and user guides at all-guides.com MECHANICAL MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 8A-RUA-001-010 CABI,FRONT U B<EXCEPT LH<W>> 12 8A-RUA-040-010 KEY,SNOOZE W<LH<W>> 1 8A-RUA-035-010 CABI,FRONT LH W<LH<W>> 13 8A-RUA-021-010 HLDR,AM ANT 2 8A-RUA-003-010 CABI,REAR U B<U<B>>...
