  • Page 1 Z100 / Z300 Z500 Z700 OWNER’S MANUAL PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW ELLIPTICAL!

  • Page 2: Table Of Contents

    Table of Contents Product Registration Important Safety Instructions Important Electrical Information Important Operation Instructions Assembly Instructions Features Operation of Your New Elliptical Maintenance Manufacturer s Limited Warranty ..14 ..15 FE46 Elliptical...

  • Page 3: Product Registration

    NEW ELLIPTICAL AND WELCOME Thank you for your purchase of this quality elliptical trainer from FUEL. Your new elliptical has been manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available. FUEL will do all we can to make your ownership experience as pleasant as possible for many years to come.

  • Page 4: Important Safety Instructions

    Important Safety Instructions WARNING - Read all instructions before using this appliance. elliptical Do not operate elliptical may result. Keep children away from the areas that can cause harm. Keep hands away from all moving parts. Never operate the elliptical if it has a damaged cord or plug. If the elliptical is not working properly, call your dealer.

  • Page 5: Important Electrical Information

    Important Electrical Information WARNING! NEVER remove any cover without first disconnecting AC power supply. If A.C. voltage varies by ten percent (10%) or more, the performance of your elliptical may be affected. Such conditions are not covered under your warranty. If you suspect the voltage is low, contact your local power company or a licensed electrician for proper testing.

  • Page 6: Assembly Instructions

    Assembly Instructions UNPACKING THE UNIT 1. Using a razor knife (Box Cutter) cut the outside, bottom, edge of box along the dotted Line. Lift box over the unit and unpack. 2. Carefully remove all parts from carton and inspect for any damage or missing parts. If damaged parts are found, or parts are missing, contact your dealer immediately.
  • Page 7 Step 2 #97. 5/16" x 23 x 1.5T Flat Washer (2pcs) Step 3 #71. 5/16 x 32m/m Hex Head Bolt (2 pcs) #98. 5/16" x 20 x 1.5T Flat Washer (2pcs) #70. 5/16" x 15m/m Hex Head Bolt (2pcs) #105. 5/16" x 7T Nylon Nut (2 pcs) #94.
  • Page 8 Step 4 #84. 3.5x12m/m Self Tapping Screw (8pcs) Tools #110. 12m/m Wrench (1pc) #108. Combination M5 Allen Wrench & Phillips Head Screw Driver (1 pc) #111. 13/14m/m Wrench (2pcs) #79. M5 x 15m/m Phillips Head Screw (12pcs) FE46 Elliptical...
  • Page 9 STEP 1: CONSOLE MAST ASSEMBLY 1. Locate the Console Mast (10) and Console Mast Cover (41) and slide the Cover onto the Mast as far as it will go. Make sure the Console Mast Cover (41) is facing the correct way.
  • Page 10 assembly. The rod end bearing should be positioned to the inside of the bracket on the Lower Handle Bars. Install two 5/16" x 32m/m Hex Head Bolts (71) through the left and right Lower Handle Bar brackets and the rod end. Install two 5/16" x 20 x 1.5T Flat Washers (98) and two 5/16"...
  • Page 11 Assembly drawing (FE46) Step 1 FE46 Elliptical...
  • Page 12 Step 2 FE46 Elliptical...
  • Page 13 Step 3 FE46 Elliptical...
  • Page 14 Step 4 FE46 Elliptical...

  • Page 15: Features

    Features Correctly aligned orthopedic foot pads Through research performed with a leading sports scientist and physical rehabilitation expert, FUEL engineering has developed a breakthrough in pedal design. No other elliptical, at any price, offers these unique features. The history of elliptical use over the past few years tells us that many users suffer from numb toes while working out on elliptical trainers.

  • Page 16: Operation Of Your New Elliptical

    Operation of Your Elliptical Getting familiar with the control panel FE46 Console Power up The Elliptical is supplied with an external power supply. When power is connected to the Elliptical, the console will automatically power up. If there is no input to the console for 20 minutes the console will go to stand-by mode.

  • Page 17: Console Operation

    Console Operation Quick Start mode This is the quickest way to start a workout. After the console powers up you just press the Start key to begin, this will initiate the Quick Start mode. In Quick Start the Time will count up from zero and the workload may be adjusted manually by pressing the Up or Down button.
  • Page 18 Entering a program/Changing Settings Press each program key to scroll through the program selections. The profile for each program will be displayed in the dot matrix window. Press the enter key to select a program and begin customizing the settings. If you want to workout without entering new settings then just press the Start key.
  • Page 19 Fat Burn The Fat Burn program is designed, as the name implies, to maximize the burning of fat. There are many schools of thought on the best way to burn fat but most experts agree that a lower exertion level that stays at a steady workload is the best. The absolute best way to burn fat is to keep your heart rate at around 60% to 70% of its maximum potential.
  • Page 20 Custom User Defined Programs The customizable User programs allow you to build and save your own workout. You can build your own custom program by following the instructions below. 1. Select the User program (U1 or U2) then press enter. 2.

  • Page 21: Maintenance

    Maintenance: 1. Wipe down all areas in the sweat path with a damp cloth after each workout. 2. If a squeak, thump, clicking or rough feeling develops the main cause is most likely one of two reasons: The hardware was not sufficiently tightened during assembly. All bolts that were installed during assembly need to be tightened as much as possible.

  • Page 22: Manufacturer S Limited Warranty

    All Other Components 1 Year service company in accordance with instructions provided with the elliptical and with all local electric service companies; FUEL Fitness P.O. Box 2037 Jonesboro, AR 72402-2037 use of parts other than original FUEL parts; 866-545-3835. in the absence of a...
